Summary of Contents for Smeg FD260PS
- Page 1 Instructions for use Refrigerator-freezer...
-
Page 2: Table Of Contents
We thank you for the confi dence you have shown by purchasing our appliance. We wish you a lot of pleasure using the appliance. The refrigerator-freezer is intended for use in households. The lower part is the refrigerator compartment intended for storing fresh food at temperatures above 0°C. -
Page 3: Important Warnings
Important warnings • This appliance is manufactured in compliance with relevant safety standards. However, it is still advisable it is not used without due supervision by persons with diminished physical, motoric, or mental capabilities or persons with inadequate experience or knowledge. The same recommendation applies to minors using the appliance. -
Page 4: A Few Tips On How To Save Power With Your Refrigerator-Freezer Combo
• Warning! Do not use mechanical devices or tools to defrost the refrigerator, nor any other methods except for those recommended by the manufacturer. • Warning! When installing, cleaning, or removing the appliance, make sure the insulation on the refrigeration system parts is not damaged. Thus you will also prevent damage to the environment. •... -
Page 5: Appliance Description
Appliance description A Refrigerator compartment B Freezer compartment 1 Control unit 2 Interior illumination lamp 3 Shelf (height adjustable) 4 Water discharge groove/gutter 5 Fruit and vegetables bin / drawer 6 Refrigerator door shelf (deep and shallow version) 7 Bottle shelf 8 Freezer shelf (height adjustable) 9 Freezer door shelf* 10 Foot... -
Page 6: Installation And Connection
Installation and connection Selecting the room Installing the appliance • The appliance should be installed in a dry and well ventilated room. The appliance will operate correctly if the environment temperature is within the ranges listed in the table below. The appliance class is indicated on the label with the basic information on the appliance. - Page 7 Connecting the appliance • Use the power cord to connect the appliance to the power mains. The wall outlet should be fi tted with a ground contact (safety socket). Nominal voltage and frequency are indicated on the label with basic information on the appliance. •...
-
Page 8: Changing The Door Opening Direction
Changing the door opening direction Appliance: HZZS3067/ HZZS3067F Tools required: ring spanner (box-end wrench) No. 8, screwdriver, torx25, fl athead screwdriver 1. Use a fl athead screwdriver to remove the hole plugs/covers A and B1. 2. Unscrew and remove – one by one, in the specifi ed order from top to bottom – the hinges (C, D, and E1) and the door (F, G). - Page 9 Appliance: HZZS2767 / HZZS2767F Tools required: socket wrench / spanner Nr. 8, slot and cross screwdriver 1. Use the slot screwdriver to remove the covers A and B. 2. Undo / remove the hinges (C, D, E1) and the door (F, G), starting from the top and working your way down.
-
Page 10: Appliance Operation
Appliance operation A Temperature setting and on/off knob B Super Freeze switch Turning the appliance on/off CONTROL UNIT I Turn on: rotate the thermostat knob clockwise towards position 7. Turn off: rotate the knob back to position STOP (0). Setting the temperature •... - Page 11 Model without fan Model with fan A Temperature setting and on/off knob B Fan on/off switch (only with some models) Turning the appliance on/off CONTROL UNIT II Turn on: rotate the thermostat knob clockwise towards position 7.
- Page 12 (only with some models) Turn off: rotate the knob back to position STOP (0) Setting the temperature • Higher settings (towards 7) selected with the knob correspond to lower (cooler) temperatures. The temperature in the refrigerator interior may drop below 0°C. Only use higher settings when a lower temperature is desired and recommended or when environment temperature is lower than 16°C.
-
Page 13: Recommended Food Arrangement In The Appliance
Recommended food arrangement in the appliance Recommended food arrangement in the appliance Refrigerator compartment areas: - upper area: canned / preserved food, bread, wine, pastry, etc. - medium area: dairy products, ready-to-eat meals, deserts, juices, beer, cooked food, etc. - lower area: meat, meat produce, delicatessen, etc. - vegetable drawer / bin: fresh fruit, vegetables, salads, root vegetables, potatoes, onions, garlic, tomatoes, tropical fruit, sauerkraut, turnips, etc. -
Page 14: Storing Food In The Refrigerator
Storing food in the refrigerator Important warnings on food storage Refrigerator interior equipment Appropriate use of the appliance, appropriate food packaging, maintaining the appropriate temperature and observing the hygienic guidelines will affect decisively the quality of food storage. Observe the best before dates indicated on the product packaging. -
Page 15: Freezing Fresh Food And Storing Frozen Food
Food storage time Freezing fresh food and storing frozen food Freezer interior equipment Freezing process SUPER FREEZE ACTIVATED SUPER FREEZE DEACTIVATED Recommended storage time for the refrigerator Foodsmoked eggs, marinated meat, smoked meat cheese root vegetables butter deserts, fruit, ready-to-eat dishes, raw meat chunks fi... - Page 16 Important warnings on freezing fresh food Storing pre-frozen food Storage times for frozen food Defrosting frozen food The freezer should only be used for freezing food that is appropriate for freezing. The food should always be fresh and of adequate quality. Choose an appropriate packaging for the food and package it correctly.
-
Page 17: Defrosting The Appliance
Defrosting the appliance Automatic refrigerator defrosting Defrosting the freezer The refrigerator does not require defrosting, as ice accumulated on the back wall of the refrigerator compartment interior is melted automatically. The accumulated ice is thawed when the compressor is not operating. - Page 18 Control unit I: • Before returning the food into the freezer, turn on the appliance, rotate the A knob back to the desired setting and deactivate the super freeze function. Control unit II: • Before putting the food back into the freezer, connect the appliance to the power mains and rotate the A knob back to the desired setting.
-
Page 19: Cleaning The Appliance
Cleaning the appliance Before cleaning, disconnect the appliance from the power mains – rotate the thermostat knob A to the STOP (0) position and unplug the power cord from the wall outlet. • Use a soft cloth to clean all surfaces. Cleaners containing abrasive particles, acids, or solvents, are not appropriate as they will damage the surface! Clean the appliance exterior with water or a mild solution of... -
Page 20: Troubleshooting
Troubleshooting Problem: After connecting to the power mains, the appliance does not operate: Cooling system has been working continuously for a long period of time: Excessive build-up of ice on the back wall of refrigerator interior may result form the following: Water is dripping from the refrigerator: Door won’t open easily:... -
Page 21: Information On Appliance Noise
Information on appliance noise Cooling in the refrigerators-freezers is enabled by a cooling system with a compressor (with some appliances also a fan), which emits a certain level of noise during operation. The level of noise depends on installation, proper use, and appliance age. - Page 24 TOP MOUNT BASIC en (03-12)
