Delta C500 Installation Manual

Delta C500 Installation Manual

Exposed roller shower door 5/16 inch glass 8 mm
Hide thumbs

Advertisement

Quick Links

Download this manual
C500
Exposed Roller
Shower Door
5/16 inch glass (8 mm)
Rodillo expuesto
Puertas para ducha
Vidrio de 5/16 pulg. (8 mm)
INSTALLATION GUIDE / GUÍA DE INSTALACIÓN
CAUTION identifies a potentially hazardous situation which,
if not avoided, may result in minor or moderate injury and/or
property/product damage.
IMPORTANT identifies information critical to installation,
operation, or maintenance.
NOTE indicates helpful advice to make installation, operation, or
maintenance proceed well.
CAUTION: To reduce the risk of breakage, keep corner protectors on glass while installing. Avoid contact between
shower door and metal parts and/or hard surfaces. Always ensure glass panels are placed on padded surfaces.
PRECAUCIÓN: Durante la instalación, coloque vidrio o protectores de esquinas para reducir el riesgo de romperse. Evite el
contacto entre la puerta de la ducha y las piezas metálicas y/o superficies duras. Asegúrese siempre de que los paneles de
vidrio estén colocados sobre superficies acolchadas.
NOTE: Installation widths: 60" Tub/shower: 55-3/8"minimum – 59-3/8" maximum,
48" Shower: 43-3/8" minimum – 47-3/8" maximum.
NOTA: Anchos de instalación: para ducha/bañera de 60" (152,40 cm): mínimo 55,375" (140,65 cm) – máximo 59,375"
(150,8 cm), ducha de 48" (121,92 cm): mínimo 43,375 (110,72 cm) – máximo 47,375" (120,33 cm).
Minimum Required Clearance Heights for Installation:
For Shower: 72 Inches (182.9 cm)
For Tub: 61 Inches (154.9 cm)
Minimum Required Installation Wall Heights
for Installation:
For Shower: 69-3/8 Inches (176.2 cm)
For Tub: 61 Inches (154.9 cm)
Minimum Sill Depth
Requirements:
2-7/8" (7.1 cm)
CP6067583
• BEFORE BEGINNING, READ ALL INSTRUCTIONS WITH PARTICULAR
ATTENTION TO SAFETY INFORMATION AND TO ENSURE YOU HAVE ALL
PARTS, TOOLS AND PROTECTIVE EQUIPMENT NEEDED TO SAFELY INSTALL
YOUR UNIT.
• PLEASE DO NOT CONTACT STORE FOR REPLACEMENT PARTS
• PLEASE CONTACT 1-800-964-4850 FOR ASSISTANCE
• ANTES DE COMENZAR, LEA TODAS LAS INSTRUCCIONES PRESTANDO
ATENCIÓN ESPECIAL A LA INFORMACIÓN DE SEGURIDAD Y ASEGÚRESE DE
TENER TODAS LAS PIEZAS, HERRAMIENTAS Y EQUIPOS DE PROTECCIÓN
NECESARIOS PARA INSTALAR SU UNIDAD DE FORMA SEGURA.
• POR FAVOR, NO CONTACTE A LA TIENDA PARA SOLICITAR PIEZAS DE
REPUESTO
• POR FAVOR LLAME AL 1-800-964-4850 PARA RECIBIR ASISTENCIA
ADVERTENCIA identifica situaciones potencialmente peligrosas
que, de no evitarse, podrían provocar lesiones leves o
moderadas y/o daños a la propiedad/producto.
IMPORTANTE identifica información esencial para la instalación,
funcionamiento, o mantenimiento.
NOTA indica consejos útiles para una correcta instalación,
funcionamiento o mantenimiento.
Alturas mínimas de separación necesarias para la instalación:
Para la ducha: 72 pulgadas (182,9 cm)
Para la bañera: 61 pulgadas (154,9 cm)
Alturas mínimas de la pared necesarias para la instalación:
Para la ducha: 59,375 pulgadas (170,08 cm)
Para la bañera: 61 pulgadas (154,9 cm)
Requisitos mínimos
de profundidad del
bordillo: 2, 875"
(7,1 cm)
1
DESIGNED AND DISTRIBUTED BY LIBERTY HARDWARE MANUFACTURING CORPORATION
STOP
PARE
JULY 2021
