- Page 1 INSTALLATION MANUAL Ubiquity Cloud Building Manager QD2040 2800 Laura Lane • Middleton, WI 53562 800.288.9383 www.tcsbasys.com 202403...
-
Page 2: Table Of Contents
Contents Installation ......................3 Introduction ............................3 Material List.............................3 Mounting ..............................3 Input Connections ..........................3 QD2040 Power and Communication Connections ................4 RS485 Network Wiring .........................4 Three-Wire Network Wiring ............................5 Two-Wire Network Wiring ............................. 6 Startup ..............................7 Troubleshooting ............................ 7 Power LED Does Not Light Up ............................7 No Communications with Controllers on the Network .................. -
Page 3: Installation
• Two 120 Ω terminating resistors for RS485 networks Mounting The QD2040 is designed to be hung on a wall via the mounting screw holes in each unit. It may also be set on a shelf or table. If mounting on a wall, do not allow the mounting screws to touch the circuit board inside the enclosure. -
Page 4: Qd2040 Power And Communication Connections
A 120Ω terminating resistor should be placed at each of the two ends of the network directly across the “A” and “B” wires. • If the QD2040 will be at one end of the network, hard-wire a 120 Ω terminating resistor across the “A” and “B” termi- nals of the QD2040 (See “Three-Wire Network Wiring”... -
Page 5: Three-Wire Network Wiring
Last in Daisy Chain Earth Ground Only at one end Three-Wire Diagram Shielded, twisted three-conductor QD2040 at end of the network. NOTES: communications wiring with one end If using more than 64 controllers, earth grounded. (120 Ω terminating use the second RS485 port or resistors provided.) -
Page 6: Two-Wire Network Wiring
Last in Daisy Chain Earth Ground Only at one end Two-wire diagram Shielded, twisted two-conductor QD2040 at end of the network. NOTES: communications wiring with one end earth grounded. (120 Ω terminating If using more than 64 controllers, resistors provided.) use the second RS485 port or additional QD1010 adapters. -
Page 7: Startup
No Communications with Controllers on the Network Make sure the baud rate selection for the QD2040 is set to match the baud rate of all the controllers on each port network (the default communication speed of the serial bus is 9600). All controllers on the network must have a unique address, excluding the reserved address ‘248’. -
Page 8: No Communication With Rs485 Ports (Com 1 And 2), Ubiquity Time-Out, Or No Data
RS485 lines. A set of LEDs on each of the RS485 ports on the QD2040 allow the building occupant to view operational status of the serial communication integrated board: •... -
Page 9: Configuration
The Software Status section contains software/application-related information that identifies the level of patching of the unit. The Site Time is used by the local network and the QD2040 until the Ubiquity Cloud Server performs a time synchronization with the site. - Page 10 Application Options You must select a Network Polling Cycle Time for the QD2040. This is the time interval that the unit will poll the entire network of controllers on all ports. You must select whether to allow caching the host name via DNS. Typically, this is left unchecked.
- Page 11 Network Information The QD2040 has two Ethernet ports, Ethernet Cloud Port 1 and Ethernet Local Port 2. By default, Ethernet Cloud Port 1 is used to connect the QD2040 to the Ethernet. Ethernet Local Port 2 is configured as a local management port; however, it can be configured as a fail-over Ethernet port (see “Appendix D: Configuring Local Management Port as a Failover Port”...
- Page 12 When you are finished entering information in this section, click the Update Communication Info button. Security Information This section contains settings which control the security of the device within the QD2040 and whether it can be accessed through the web interface.
- Page 13 You can access a separate page containing various commissioning tools by clicking the “Commissioning Tools” button at the bottom of the Security Information page. These tools provide you with access to managing the communication status of the QD2040 and the controller network connected to it. 2800 Laura Lane •...
- Page 14 Commissioning Tools Ubiquity Cloud Connection Status This section displays the status of the connection between the QD2040 and the Ubiquity Cloud Server. You have three options for the message that will appear here: 1. Error - No Route to Host: The unit does not currently have an Ethernet connection.
-
Page 15: Gateway Configuration Via Cli
System Commands This section describes how to set up system flags for the QD2040. “Reboot Unit” sets a flag which will shut off and restart the QD2040 within a five-minute cycle. “Check for Update” contacts the Ubiquity Cloud Server for any updates relevant to its particular model number and software version. - Page 16 Configuration Command Line Interface Command Line Interface 2800 Laura Lane • Middleton, WI 53562 800.288.9383 www.tcsbasys.com...
-
Page 17: Appendices
Appendices Appendix A: Local Management Port The QD2040 can be configured locally at the device using a laptop computer. If using this method of configuration, you will need: 1. Laptop with a hardwired Network Interface Card (NIC). 2. Ethernet cable. - Page 18 Appendices Change adapter options 3. On the Network Connections panel locate the Ethernet interface that is connected to the cable. Right click on the item and select “Properties.” Properties 4. On the Ethernet Properties panel locate the “Internet Protocol Version 4 (TCP/IPv4)”. Select that option, then click on the “Properties”...
- Page 19 Appendices TCP/IPv4 2800 Laura Lane • Middleton, WI 53562 800.288.9383 www.tcsbasys.com...
- Page 20 Appendices 5. On the Internet Protocol Version 4 (TCP/IPv4) Properties change the IP schema to: • IP Address: 10.248.248.2 • Subnet Mask: 255.0.0.0 • Default Gateway: 10.248.248.2 • DNS: Blank 6. Click on the “OK” button and close the window. Port to static settings 2800 Laura Lane •...
- Page 21 Appendices 7. Launch any web browser and type in the following address: https://10.248.248.1. Device address 8. Depending on your browser’s configuration, you may get the following screen: Privacy Error Warning Screen 9. Click on the “Advanced” button in the Privacy Error Warning screen. 2800 Laura Lane •...
- Page 22 Appendices 10. Click on the “Proceed” link to take you to the next screen. Proceed Screen 11. Enter the Login user name and password. Login Screen 12. Configure the Gateway as needed. (See “Gateway Configuration Via Laptop” on page 2800 Laura Lane •...
-
Page 23: Appendix B: Revert Back To Dhcp Settings
Appendices Appendix B: Revert Back to DHCP Settings If you have changed your laptop’s network configuration (See “Appendix A: Local Management Port” on page and wish to revert back to its previous configuration, follow the steps below: Windows 10: 1. Search for Ethernet Settings and click the “Open” link. Ethernet Settings 2. - Page 24 Appendices Properties 4. On the Ethernet Properties panel locate the “Internet Protocol Version 4 (TCP/IPv4)”. Select that option, then click on the “Properties” button. TCP/IPv4 2800 Laura Lane • Middleton, WI 53562 800.288.9383 www.tcsbasys.com...
- Page 25 Appendices 5. On the Internet Protocol Version 4 (TCP/IPv4) Properties “General” tab: 6. Click on the “Obtain an IP address automatically” radio button 7. Click on the “Obtain DNS server automatically” radio button 8. Click on the “OK” button. Revert back to DHCP settings 2800 Laura Lane •...
-
Page 26: Appendix C: Monitor And Keyboard
4.) Power on the monitor and switch to the proper input, based on the cable used. 2. Plug the USB cable into a free USB port on the QD2040. Test keyboard connectivity by pressing Caps Lock to see if the LED on the keyboard illuminates. -
Page 27: Appendix D: Configuring Local Management Port As A Failover Port
Appendix D: Configuring Local Management Port as a Failover Port The QD2040 has two Ethernet ports: Cloud Ethernet 1 and Local Ethernet 2. By default, Cloud Ethernet 1 is used to connect the QD2040 to the Ethernet, and Local Ethernet 2 is configured as a local management port; however, Local Ethernet 2 can be configured as a fail-over Ethernet port in the event of an Internet interruption on Cloud Ethernet 1. - Page 28 Failover Options Section Failover Options Section The Failover Options section contains several default settings that should be adequate in most situations. TCS strongly recommends contacting your IT department before making any changes to the default settings. Click on the green Update Application Info button beneath the RS485 Network Port Configuration section to save the failover server location and other settings.
-
Page 29: Failover Port Configuration Via Cli
6. Skip to the Local Ethernet 2 fields. Enter the failover network information provided by your IT department. 7. Exit the CLI to save settings. Disconnect the monitor and keyboard. Do not reboot the QD2040. Changes made via the CLI will take about five minutes to execute. - Page 30 Appendices Failover URL Settings E-Port 2 Mode Settings 2800 Laura Lane • Middleton, WI 53562 800.288.9383 www.tcsbasys.com...
