- Page 1 Refrigerator KI81FH.. Information for Use Register your product on My Siemens and discover exclusive services and offers. siemens-home.bsh-group.com/welcome The future moving in. Siemens Home Appliances...
-
Page 2: Table Of Contents
Table of contents 1 Safety .......... 4 7 Basic operation ...... 15 1.1 General information.... 4 7.1 Switching on the appliance .. 15 1.2 Intended use....... 4 7.2 Operating tips...... 15 1.3 Restriction on user group... 4 7.3 Switching off the appliance .. 15 1.4 Safe transport ...... 4 7.4 Setting the temperature.... 15 1.5 Safe installation ...... 5... - Page 3 15 Troubleshooting....... 24 15.1 Conducting an appliance self-test ........ 26 16 Storage and disposal.... 26 16.1 Taking the appliance out of operation ........ 26 16.2 Disposing of old appliance .. 26 17 Customer Service..... 27 17.1 Product number (E-Nr.) and production number (FD).. 28 18 Technical data ......
-
Page 4: Safety
en Safety 1 Safety Observe the following safety instructions. 1.1 General information ¡ Read this instruction manual carefully. ¡ Keep the instruction manual and the product information safe for future reference or for the next owner. ¡ Do not connect the appliance if it has been damaged in transit. 1.2 Intended use This appliance is only intended to be fully fitted in a kitchen. -
Page 5: Safe Installation
Safety en 1.5 Safe installation WARNING ‒ Risk of electric shock! Incorrect installation is dangerous. ▶ Connect and operate the appliance only in accordance with the specifications on the rating plate. ▶ Connect the appliance to a power supply with alternating cur- rent only via a properly installed socket with earthing. ▶... -
Page 6: Safe Use
en Safety Portable multiple socket strips or portable power supply units may overheat and cause a fire. ▶ Do not place portable multiple socket strips or power supply units on the back of the appliance. 1.6 Safe use WARNING ‒ Risk of electric shock! An ingress of moisture can cause an electric shock. -
Page 7: Damaged Appliance
Safety en WARNING ‒ Risk of fire! Electrical devices within the appliance may cause a fire, e.g. heat- ers or electric ice makers. ▶ Do not operate electrical devices within the appliance. WARNING ‒ Risk of injury! Containers that contain carbonated drinks may burst. ▶ Do not store containers that contain carbonated drinks in the cool-fresh compartment. - Page 8 en Safety ▶ Never pull on the power cord to unplug the appliance. Always unplug the appliance at the mains. ▶ If the appliance or the power cord is damaged, immediately un- plug the power cord or switch off the fuse in the fuse box. ▶...
-
Page 9: Preventing Material Damage
Preventing material damage en – Maintain a 30 mm clearance to 2 Preventing material electric or gas cookers. – Maintain a 300 mm clearance to damage oil or solid-fuel cookers. ¡ Use a niche depth of 560 mm. ATTENTION! ¡ Never cover or block the external Using the base, runners or appliance ventilation openings. -
Page 10: Criteria For The Installation Location
en Installation and connection ¡ Equipment and accessories Niche dimensions ¡ Installation material Observe the niche dimensions if you ¡ Installation instructions install your appliance in the niche. If ¡ User manual this is not the case, problems may ¡ Customer service directory occur when installing the appliance. -
Page 11: Connecting The Appliance To The Electricity Supply
Installation and connection en 4.5 Connecting the appliance to the electricity supply Insert the mains plug of the appli- ance's power cable in a socket nearby. The connection data of the appli- ance can be found on the rating plate. → "Appliance", Fig. Page 13 Check the mains plug is inserted properly. - Page 12 en Familiarising yourself with your appliance 5 Familiarising yourself with your appliance 5.1 Appliance You can find an overview of the parts of your appliance here. Refrigerator compartment Control panel → Page 13 → Page 18 Variable shelf → Page 14 Cool-fresh compartment → Page 19 Extendable shelf → Page 14...
-
Page 13: Familiarising Yourself With
Familiarising yourself with your appliance en Partition with humidity control- Butter and cheese compart- ler → Page 14 ment → Page 15 Fruit and vegetable container Door storage compartment → Page 14 for large bottles → Page 15 Cool-fresh container Note: Deviations between your appli- → Page 15 ance and the diagrams may differ with regard to their features and size. -
Page 14: Features
en Features You can adjust the humidity in the 6 Features fruit and vegetable container via the humidity controller on the partition The features of your appliance de- and a special seal. pend on the model. 6.1 Shelf To vary the shelf as required, you can remove the shelf and re-insert it elsewhere. -
Page 15: Cool-Fresh Container
operation en 6.5 Cool-fresh container operation 7 Basic operation Use the lower temperatures in the operation cool-fresh container to store highly 7.1 Switching on the appli- perishable food, e.g. fish, meat and sausages. ance Press 6.6 Butter and cheese com- a The appliance begins to cool. partment Set the required temperature. -
Page 16: Additional Functions
en Additional functions Setting the cool-fresh Switching off Super cooling compartment temperature Press ▶ Note: The standard setting of the a The previously set temperature is cool-fresh compartment is preset at displayed. 0. Setting 0 corresponds to a temper- ature of around 0 °C. You can set the temperature in the cool-fresh 9 Alarm compartment to 3 settings warmer or... -
Page 17: Home Connect
Home Connect en The Home Connect app guides you 10.2 Installing updates for the through the entire login process. Fol- Home Connect software low the instructions in the Home Con- nect app to configure the settings. The appliance searches for updates to the Home Connect software at reg- Tips ular intervals. -
Page 18: Data Protection
en Refrigerator compartment Press 11 Refrigerator compart- a The temperature display shows an ment animation for 15 seconds. a The temperature display shows You can keep dairy products, eggs, a The Home Connect settings have prepared meals, pastries, open pre- been reset. serves and hard cheese in the refri- gerator compartment. -
Page 19: Cool-Fresh Compartment
Cool-fresh compartment en Tip: Store highly perishable food Food Storage such as fish, sausages and meat in time the cool-fresh compartment. Smoked fish, broccoli up to 14 → "Cool-fresh compartment", days Page 19 Salad greens, fennel, up to 21 Warmest zone apricots, plums days The warmest zone is at the very top Soft cheese, yoghurt, up to... -
Page 20: Cleaning The Appliance
en Cleaning and servicing Unplug the appliance from the Prepare the appliance for cleaning. mains or switch off the circuit → Page 19 breaker in the fuse box. Clean the appliance, the fittings, Take out all of the food and store it the accessories, the components in a cool place. -
Page 21: Removing Appliance Components
Cleaning and servicing en Removing the extendable shelf Removing the fruit and vegetable container Firmly pull out the extendable shelf until the locking catch is released. Tilt the fruit and vegetable con- ▶ tainer forwards and remove it . Lower the shelf and swing it out to the side. - Page 22 en Cleaning and servicing Insert the partition. Removing the partition Remove the glass plate from the partition. Place the glass plate on the parti- tion. Remove the fruit and vegetable Telescopic rails container. You can remove the telescopic rails Press the lever on the underside in order to clean them thoroughly.
- Page 23 Cleaning and servicing en Push in the telescopic rail. Push the telescopic rail backwards above the rear pin and disen- gage . Installing telescopic rails Place the extended telescopic rail on the front pin and pull it for- wards slightly to lock in place ...
-
Page 24: Troubleshooting
en Troubleshooting 15 Troubleshooting You can rectify minor faults on your appliance yourself. Read the troubleshoot- ing information before contacting after-sales service. This will avoid unneces- sary costs. WARNING Risk of electric shock! Incorrect repairs are dangerous. Repairs to the appliance should only be carried out by trained specialist ▶... - Page 25 Troubleshooting en Fault Cause and troubleshooting The temperature dif- Different causes are possible. fers greatly from the Switch off the appliance. → Page 15 setting. Switch the appliance back on after five minutes. → Page 15 If the temperature is too warm, check the temper- ‒ ature again after a couple of hours.
-
Page 26: Conducting An Appliance Self-Test
en Storage and disposal To guarantee the ventilation inside 15.1 Conducting an appliance the appliance, leave the appliance self-test open. Your appliance has an appliance self- 16.2 Disposing of old appli- test which displays faults that can be eliminated by your customer service. ance Switch off the appliance. - Page 27 ¡ Consult the retailer Helpline no.: 1800-209-1850 about appliance take (Monday to Saturday – 8 am to back schemes. 8 pm) Don’ts Email ID: service.in@siemens- ¡ The product should home.BSH-Group.com not be opened by the user himself/herself, but only by authorized service personnel.
-
Page 28: Product Number (E-Nr.) And Production Number (Fd)
A detailed RED Declaration of Con- You can find the product number (E- formity can be found online at Nr.) and the production number (FD) siemens-home.bsh-group.com on the appliance's rating plate. among the additional documents on the product page for your appliance. - Page 32 BSH Hausgeräte GmbH Carl-Wery-Straße 34 81739 München, GERMANY siemens-home.bsh-group.com Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG *9001715346* 9001715346 (020707)
