USB2.0 1-Port Multi-Functional Printer Server
Section 1
This Quick Installation Guide only provides basic instructions. For detailed
information on using this product, please refer to the User's Manual on the
WARNING:
Only a USB printer may be connected to the USB port of the
Printer Server. Connecting any other USB device to the Printer Server may
damage the Printer Server.
Note: Before connecting the Printer Server, you must install the printer driver
on each computer you plan to use with the printer. Make sure that you are able
to print, scan, and fax from each with your multi-functional printer directly
connected to your computer(s).
Step 1
Power down the printer and the printer server.
Step 2
Connect one end of a networking cable to your router, then connect the
other end to the Ethernet port on the back of the print server.
Step 3
Connect the USB cable coming from your printer into the USB port on
the printer server.
Quick Installation Guide
Model # AMPS230

Connecting the Printer Server

Package Content:
•
•
•
•
•
supplied CD.
1-Port MFP Server
Power Adapter
Ethernet Cable
Driver & Utility CD
Quick Installation Guide
Ver. 1A

Advertisement

Table of Contents
loading

Related Manuals for Airlink101 AMPS230

Summary of Contents for Airlink101 AMPS230

  • Page 1: Connecting The Printer Server

    Ethernet port on the back of the print server. Step 3 Connect the USB cable coming from your printer into the USB port on the printer server. Model # AMPS230 Package Content: • 1-Port MFP Server •...

  • Page 2: Installing The Ps Software

    Step 4 Turn on the printer. Once the printer is powered on, connect the print server’s power adapter to an electrical outlet. Section 2 Installing the PS Software Note: The PS Software must be installed on all computers you plan to use with the print server.
  • Page 3 Note: If the autorun window does not appear automatically, go to Start -> Run and type D:\Utility\Setup.exe (where D is the letter of your CD-ROM drive) and click OK. Step 2 Select your setup language and click OK. Step 3 Click Next at the welcome screen.
  • Page 4 Step 4 Click Next at the Choose Destination Location screen. Step 5 Click Next at the Select Program Folder.

  • Page 5: Configuring The Printer Server

    Step 6 Once the installation is complete, make sure that the Launch PS-Link box is checked and click Finish. Section 3 Configuring the Printer Server Note: The following steps only need to be performed one time from one computer. Step 1 Click the Discover button and your printer should show up under Server Name.
  • Page 6 Step 2 Once the printer server appears in the Server Name box, click on it. You should see your printer next to Device name. Click on the Setup Wizard button to configure the printer server. Step 3 A password box will appear. The default password is admin. Enter it and click OK.
  • Page 7 Step 4 Click Next at the welcome screen. Step 5 At the System screen you can change the Server Name, Port Name, and Password. Click Next after making the desired changes. If you do not have a specific Server Name, Port Name, or Password that you would like to use, click Next to accept the default settings.
  • Page 8 Step 6 If you have a specific IP address you would like to assign to the print server, select Manually Assign and enter your custom settings. Otherwise, select DHCP Assign Automatically and click Next. Step 7 If your network uses a workgroup name other than WORKGROUP, you can enter it here, or accept the default settings, and click Next.
  • Page 9 Step 8 If you have specific AppleTalk settings, you can enter them here or accept the default settings, and click Next. Step 9 Click Save to save the changes to your print server.

  • Page 10: Adding The Printer To The Computer

    Section 4 Adding the Printer to the Computer Note: The following steps must be completed on all computers you plan to use with the print server. Step 1 Double click on the PS-Link icon in the system tray to open the PS-Link software.
  • Page 11 Step 3 Select your print server from the Server Name box and click the Link button. Step 4 Click OK at the Link Successfully screen. You will see notices appearing in the bottom right-hand corner of your screen while Windows configures the printer.
  • Page 12 Step 6 In Printers and Faxes (or Printers) you will see a copy of your printer. Right click on the copy and click Set as Default Printer. Congratulations, the configuration is now complete. Remember to repeat all steps in Section 4 on each of the computers you plan to use with the print server.

  • Page 13: Technical Support

    Toll Free: 1-888-746-3238 Website: www.airlink101.com *Printer server may not support all printers. Go to the AirLink101 website to view the printer compatibility list *Actual data throughput will vary. Network conditions and environmental factors lower actual data throughput rate. Specifications are subject to change without notice. All products and trademarks...
