OWNER'S MANUAL
WASHING MACHINE
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
F2WR709S** / F2WR708S**
MFL72000563
Rev.00_110123
Copyright © 2023 LG Electronics Inc. All Rights Reserved.
www.lg.com

Advertisement

Table of Contents
loading

Related Manuals for LG F2WR709S Series

Summary of Contents for LG F2WR709S Series

  • Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH F2WR709S** / F2WR708S** www.lg.com MFL72000563 Rev.00_110123 Copyright © 2023 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    Control Panel ....................20 Preparing the Wash Load ................23 Adding Detergents and Softeners ..............24 Programme Table ....................26 Extra Options and Functions ................32 SMART FUNCTIONS LG ThinQ Application ..................35 Smart Diagnosis ....................38 MAINTENANCE Cleaning After Every Wash................39 Cleaning the Appliance Periodically ..............39 TROUBLESHOOTING...

  • Page 3: Caring For The Environment

    CARING FOR THE ENVIRONMENT CARING FOR THE ENVIRONMENT Environmental and Economical Tips Energy and water consumption • Water consumption and energy usage can be affected by the weight of the load. To make the best use of your appliance, load the maximum amount of dry clothes for the particular programme.
  • Page 4 CARING FOR THE ENVIRONMENT Selecting Extra Options and Functions • Select the water temperature suitable for the type of load you are washing. Follow the garment fabric care labels for best results. • The Pre Wash option is recommended for washing a heavily soiled load.

  • Page 5: Safety Instructions

    SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk.
  • Page 6 SAFETY INSTRUCTIONS appliance. Cleaning and user maintenance shall not be made by children without supervision. • Children of less than 3 years should be kept away unless continuously supervised. • If the power cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
  • Page 7 SAFETY INSTRUCTIONS • Do not modify the power plug provided with the appliance. If it does not fit the power outlet, have a proper outlet installed by a qualified electrician. • This appliance is equipped with a power cord having an equipment- earthing / grounding conductor (earthing pin) and a grounding power plug.
  • Page 8 • Do not touch the door during a high temperature programme. • In case of a water leak from the appliance or flood, disconnect the power plug and contact the LG Electronics customer information centre. • Turn off water taps to relieve pressure on hoses and valves and to minimize leakage if a break or rupture should occur.
  • Page 9 • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.

  • Page 10: Installation Parts And Specifications

    INSTALLATION INSTALLATION Parts and Specifications NOTE • Appearance and specifications may change without notice to improve the quality of the appliance. Front View Rear View Control Panel Power Plug Detergent Dispenser Drawer Transit Bolts Drum Drain Hose Door Cover Cap Drain Plug Drain Pump Filter Levelling Feet...
  • Page 11 INSTALLATION Specifications Model F2WR709S** / F2WR708S** Power Supply 220‒240 V~, 50 Hz Product Weight 59 kg Dimension(mm) D’’ D’ 1015...
  • Page 12 INSTALLATION Accessories Cold Supply Hose Anti–slip Sheets*1 Spanner Elbow Bracket for Securing Drain Hose Caps for Covering Transit Bolt Holes Tie Strap*1 *1 The included accessories vary depending on the model you purchased.

  • Page 13: Installation Place Requirements

    INSTALLATION Installation Place Index Clearance (mm) Requirements Before installing the appliance, check the following information to make sure that the appliance should be installed in a correct place. WARNING Installation Location • This appliance must only be used for domestic household purposes and should not be used in •...

  • Page 14: Unpacking The Appliance

    INSTALLATION grounded/earthed in accordance with all local NOTE codes and ordinances. • You can purchase rubber cups (part No. 4620ER4002B) from the LG service centre. Unpacking the Appliance Ventilation Lifting the Appliance Off the Foam Base • Make sure that air circulation around the...

  • Page 15: Levelling The Appliance

    INSTALLATION Levelling the Appliance Starting with the bottom two transit bolts use the spanner (included) to fully loosen all Checking the Level transit bolts by turning them counterclockwise. When pushing down the edges of the top plate diagonally, the appliance should not move up and down at all (check both directions).
  • Page 16 • Do not install the washing machine on a plinth, Failure to do so may cause vibration or noise. stand or elevated surface unless it is manufactured by LG Electronics for use with this model. Using Anti-Slip Sheets This feature may vary depending on the model Check if the appliance is perfectly level using a purchased.

  • Page 17: Connecting The Water Supply Hose

    • Do not attach the adhesive side of anti- slip sheets to the feet of the appliance. NOTE • Additional anti-slip sheets are available at LG Electronics service centre. Connecting the Hose to the Water Tap Connecting Screw-Type Hose to Tap with Thread...

  • Page 18: Installing The Drain Hose

    INSTALLATION • Securing the drain hose correctly will protect the NOTE floor from damage due to water leakage. • After connecting the water inlet hose to the water tap, turn on the water tap to flush out foreign substances (dirt, sand, sawdust, and etc.) in the water lines.

  • Page 19: Operation Operation Overview

    OPERATION OPERATION Operation Overview Add cleaning products or detergent and softener. Using the Appliance • Add the proper amount of detergent to the detergent dispenser. If desired, add bleach Before the first wash, select the Cotton wash or fabric softener to the appropriate areas of programme and add a half amount of the the dispenser.

  • Page 20: Control Panel

    • This allows you to select an additional programmes and will light when selected. Remote Start With the LG ThinQ app, you can use a smartphone to control your appliance remotely. • In order to use this function, refer to SMART FUNCTIONS.
  • Page 21 OPERATION Description Customizing Washing Programme Buttons Use these buttons to adjust the water temperature or spin speed settings for the selected programme. • The current settings are shown in the display. • Press the button for that option to select other settings. Display •...
  • Page 22 OPERATION Description lights up when the beep is off. lights up when the Rinse+ option is activated. lights up when the Intensive option is activated. lights up when the appliance is connected to Wi-Fi network at home. lights up when the programme starts and the door is locked.

  • Page 23: Preparing The Wash Load

    OPERATION Preparing the Wash Load NOTE Sort the wash load for best washing results, and • For general information about the washing then prepare the clothes according to the symbols symbols on textile care labels, visit the Ginetex on their care labels. site (www.ginetex.ch).

  • Page 24: Adding Detergents And Softeners

    OPERATION • Pre-treat dirt and stains by brushing a small - For better washing results of white and pale amount of detergent dissolved water onto stains garments, use powdered detergent with to help lift dirt. bleach. - Detergent is flushed from the dispenser at the beginning of the wash cycle.
  • Page 25 OPERATION Adding Detergent Tablets • Slamming the drawer closed may result in the detergent overflowing into another compartment or dispensing into the drum Detergent tablets can also be used when washing. earlier than programmed. Open the door and put detergent tablets into •...

  • Page 26: Programme Table

    OPERATION Programme Table Washing Programme AI Wash 40 °C (Cold to 60 °C) Max. Load: 3 kg Description AI Wash provides the appropriate drum rotation actions after load sensing is completed. • It washes softly for waterproof fabrics, and strongly for water permeable fabrics. NOTE •...
  • Page 27 OPERATION Delicates 20 °C (Cold to 40 °C) Max. Load: 1.5 kg Description Washes machine-washable lingerie, sheer and lacy clothes. Hand/Wool 30 °C (Cold to 40 °C) Max. Load: 2 kg Description Washes hand-washable and machine-washable delicate clothes such as washable wool, lingerie, dresses etc.
  • Page 28 OPERATION Extra Options NOTE • Rinse+, Delay End and Add Item options can be selected for every washing programme in this table. Programme Steam TurboWash Pre Wash Intensive AI Wash Cotton Eco 40-60 TurboWash 39 Mixed Fabric Easy Care Allergy Care Delicates Hand/Wool Sportswear...
  • Page 29 OPERATION Spin Speed Programme Default Available Easy Care 1200 rpm Allergy Care 1200 rpm Delicates 800 rpm Up to 800 rpm Hand/Wool 800 rpm Up to 800 rpm Sportswear 800 rpm Up to 800 rpm Speed 14 400 rpm Duvet 1000 rpm Up to 1000 rpm NOTE...
  • Page 30 OPERATION Programme h:mm ℃ Litres Cotton 40 ℃ + 2:57 0.287 62.0 1150 55.7 Intensive 3:48 0.770 73.0 1160 53.0 Eco 40-60 (Full) 2:54 0.370 51.0 1160 52.0 Eco 40-60 (Half) Eco 40-60 2:20 0.200 30.0 1160 56.0 (Quarter) Model: F2WR708S** Programme h:mm ℃...
  • Page 31 OPERATION • To find the same information in EPREL, visit https://eprel.ec.europa.eu and search using the model name. (Valid from 1st March 2021) • Actual maximum spin speed may vary depending on the load conditions.

  • Page 32: Extra Options And Functions

    OPERATION Extra Options and Press the Power button. Functions You can use the extra options and functions to Add detergent. customize the programmes. Customizing a Washing Select a washing programme. Programme Each programme has default settings that are Customize the washing programme (Temp., selected automatically.
  • Page 33 OPERATION TurboWash Select a washing programme. Adding this option reduces the programme time but the similar washing results will be provided. Follow the next steps to use a special Press the Start/Pause button. option. Press the Add Item button as necessary. Press the Power button.
  • Page 34 OPERATION Press and hold the Delay End and Add Item NOTE buttons at the same time for 3 seconds to • The delay time is the time to the end of the deactivate this function. programme, not the start. The actual running Beep On/Off time may vary due to water temperature, clothes This appliance plays a melody when it starts and...

  • Page 35: Smart Functions

    SMART FUNCTIONS SMART FUNCTIONS LG ThinQ Application notifications on a smartphone. The notifications are triggered even if the LG ThinQ application is off. The LG ThinQ application allows you to communicate with the appliance using a smartphone. NOTE LG ThinQ Application Features •...
  • Page 36 SMART FUNCTIONS • Smartphone user interface (UI) may vary Run the LG ThinQ application and sign in with depending on the mobile operating system (OS) your existing account or create an LG account and the manufacturer. to sign in. • If the security protocol of the router is set to WEP, you may fail to set up the network.
  • Page 37 Output Power IEEE 802.11 b: 17.59 dBm (Max.) IEEE 802.11 g: 17.39 dBm Start a cycle from the LG ThinQ application on IEEE 802.11 n (HT20): 16.64 your smartphone. IEEE 802.11 n (HT40): 17.05 NOTE •...

  • Page 38: Smart Diagnosis

    SMART FUNCTIONS LG Electronics will also provide open source code to Press the Power button to turn on the you on CD-ROM for a charge covering the cost of appliance. performing such distribution (such as the cost of • Do not press any other buttons.

  • Page 39: Maintenance

    MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, electric shock, or death. • Never use harsh chemicals, abrasive cleaners, or solvents to clean the appliance. They may damage the finish.
  • Page 40 MAINTENANCE Cleaning the Water Inlet Filter Run this function once a month (or more often if needed) to reduce build-up of detergent and The water inlet filter collects lime or any sediment softener and other residue. that may be in water that is supplied to the •...
  • Page 41 MAINTENANCE Allow the water to cool before cleaning the drain Unscrew the drain pump filter slowly to drain pump filter. Open the door in an emergency or the remaining water and then proceed to perform an emergency water evacuation. remove any debris or objects from the filter. Unplug the appliance.
  • Page 42 MAINTENANCE check for build-up of cleaning products once or twice a month. Remove the detergent dispenser drawer by pulling the drawer straight out until the drawer stops. • Then gently pull the drawer outward while pressing hard the disengage button. Remove the build-up of detergent and softener.

  • Page 43: Troubleshooting

    Operation of your appliance can lead to errors and malfunctions. The following tables contain possible causes and notes for resolving an error message or malfunction. It is recommended to read the tables carefully below in order to save your time and money that may cost for calling to LG Electronics service centre.
  • Page 44 • Check and clean the drain filter. Door sensor malfunctions. dE dE1 dEz dE4 DOOR ERROR • Please call LG service centre. You can find your local LG service centre phone number in the warranty card. This is a control error. CONTROL ERROR •...
  • Page 45 TROUBLESHOOTING Symptoms Possible Cause & Solution Thumping sound The clothes may be out of balance. • Pause the programme and redistribute the clothes after the door unlocks. Vibrating noise Package materials are not removed. • Remove package materials. The clothes may be unevenly distributed in the drum. •...
  • Page 46 TROUBLESHOOTING Symptoms Possible Cause & Solution Appliance does not Circuit breaker/fuse is tripped/blown. operate. • Check house circuit breakers/fuses. Replace fuses or reset breaker. The appliance should be on a dedicated branch circuit. The appliance will resume the programme where it stopped once power is restored. Control needs to be reset.
  • Page 47 TROUBLESHOOTING Symptoms Possible Cause & Solution Appliance does not Drain located higher than 1 m above the floor. drain water. • Make sure that the drain hose is no higher than 1 m above the bottom of the appliance. Detergent is not Too much detergent is used.
  • Page 48 • Find the Wi-Fi network connected to your smartphone and remove it, then not connected to the register your appliance on LG ThinQ. Wi-Fi network. Mobile data for your smartphone is turned on. • Turn off the Mobile data of your smartphone and register the appliance...
  • Page 49 Customer Care and Service Contact an LG Electronics customer information centre. • To find an LG Electronics authorised service personnel, visit our website at www.lg.com and follow the instructions found there. • Self-repair is not recommended as it could further damage the device and void the guarantee.
  • Page 50 Memo...
  • Page 51 Memo...
