Page 1: Table Of Contents
Document Number 6351-A2-GN10-20 February 2004 Contents Software and Firmware License Agreement Product Documentation Online Hotwire 6351 ReachDSL Router Overview Getting Started Installing the Hotwire 6351 ReachDSL Router Power-On ... 12 Troubleshooting ... 13 Configuration Setup ... 14 Graphical User Interface...
Page 2 The terms and conditions of this License Agreement (the “Agreement”) will apply to the software and/or firmware (individually or collectively the “Software”) incorporated into the Paradyne product (the “Product”) purchased by you and any derivatives obtained from the Software, including any copy of either. If you have executed a separate written agreement covering the Software supplied to you under this purchase, such separate written agreement shall govern.
Page 3: Product Documentation Online
System that interoperates with Hotwire 8312 and 8314 ReachDSL cards in the Digital Subscriber Line Access Multiplexer (DSLAM) system. The ReachDSL Router operates as an IP router, connecting a DSL link to an Ethernet network to provide high-speed Internet or corporate LAN access over traditional twisted-pair copper telephone wiring.
Page 4 The ReachDSL Router does not require a POTS splitter at the demarcation point to support line sharing by data and voice services. Standard phone wiring is used for connection to the router. Central Office (CO) Local Loop Network Service Provider...
Page 5 Phone Filters For optimum performance, if the wiring for the router is also used for voice (POTS), a phone filter should be installed on each voice line with a phone, modem, fax machine, or other telecommunications device attached. One Hotwire phone filter can be used with multiple telecommunications devices (for example, a phone and a fax machine can be supported using a single filter), provided a multiple line adapter is used.
Page 6: Getting Started
7 to install cables. — Refer to Cables and Connectors Optional Cable and Adapters The Hotwire 6351 ReachDSL Router is typically configured remotely by the service provider. The following optional cable and adapters are only used when configuring the router locally: ❑...
Page 7: Installing The Hotwire 6351 Reachdsl Router
Installing the Hotwire 6351 ReachDSL Router Place the ReachDSL router on a flat surface, with clearance for the rear connectors. For router cable pin assignments, refer to Connecting the DSL Line in a Home Environment (Phone and Router in the Same Location) Use the supplied RJ11 6-pin cable for the DSL connection.
Page 8 Connecting the DSL Line in All Other Environments Use the supplied RJ11 6-pin cable for the DSL connection. Procedure 1. Insert one end of the cable into the DSL jack on the router. 2. Insert the other end of the cable into the wall jack. Wall...
Page 9 — Insert one end of the straight-through cable into the ETHERNET jack on the router and connect the other end to an Ethernet hub. Do not connect it to the hub’s optional Uplink connection; the Uplink connection requires an Ethernet crossover cable.
Page 10 VT100 terminal or a PC running a terminal emulation program. It is an optional connection that is only used for local configuration of the router. To set up the VT100 terminal or PC for local configuration and to access the router, refer Configuration Setup Procedure 1.
Page 11: Connecting Power
Connecting Power Procedure 1. Insert the supplied power cord’s round end into the POWER jack on the router. 2. Plug the transformer into an AC outlet. Power Jack 18 VDC 800 MA Transformer Installation of the hardware is now complete. When the power cord is installed, the router goes through a power-on self-test.
Page 12: Power-On
Power-On When power is applied, the router performs self-diagnostics and the PWR LED is on. The self-diagnostics include a power-on self-test. During the power-on self-test, all of the LEDs turn on for one second. Power – green Hotwire 6351 ReachDSL...
Page 13: Troubleshooting
PWR LED is off. TST LED is on. Action If the LEDs remain on for more than ten minutes, the router is not functional. Contact the service provider. The power-on self-test may have failed. Unplug the router and reapply power. If the alarm LED is still on, contact the service provider.
Page 14: Configuration Setup
Increasing the Number of End-User Systems A single PC is attached to the router by using an Ethernet crossover cable. The router can support differing numbers of end-user systems, depending on the functions that are enabled and traffic loading. Typical configurations provide support for up to 32, 64, or 256 hosts (end-user systems).
Page 15: Graphical User Interface
If your hardware or version of Linux requires a different JRE, you need to locate and install one. Run the setuplinux.bin file on the distribution CD to install the ReachDSL 6351 GUI and, if necessary, the JRE. Start the GUI by clicking on ReachDSL_6351_GUI in the Programs menu.
Page 16 Installation of the GUI on a Mac requires Mac OS X and Java 1.4.x for Mac OS X to be previously installed. Java 1.4.x is available at: http://www.apple.com/java/ Run the setupmac.command file on the distribution CD to install the ReachDSL 6351 GUI. Start the GUI by clicking on the ReachDSL_6351_GUI icon on the desktop.
Page 17: Cables And Connectors
Click on: „ System View to view information about the router, such serial number, firmware levels, and Wan and LAN addresses. „ Quick Config to configure RFC 1483 Encapsulation, the address of the Ethernet port, PPP username and password, and DNS name servers.
Page 18 Console Interface The Console connector uses 8-pin, non-keyed modular plugs and a DB9 adapter. RJ45 8-Pin Connector Pin # Circuit Not used 4 & 5 Signal Ground Not used 8-Pin Modular to DB9 Adapter Plug Modular Pin # Circuit 4 & 5 Signal Ground Console Port Direction...
Page 19 10/100BaseT RX D– 7 & 8 Not used – or – „ To connect the router to a PC with an Ethernet NIC card, use an Ethernet crossover cable. 8-Pin Ethernet Crossover Cable Function 10/100BaseT TX D+ 10/100BaseT TX D–...
Page 20: Optional Wall Placement
Optional Wall Placement The Hotwire 6351 ReachDSL Router is designed for tabletop placement. The router can also be mounted on a wall. To mount the router, you will need: ❑ Three #6 pan-head screws with anchors (for example, molly bolts, plastic or lead anchors) ❑...
Page 21 ReachDSL Router Hardware Template 5.43" Front (LEDs) 7.55" To Bottom Hole 98-16171...
Page 22: Reachdsl Router Technical Specifications
ReachDSL Router Technical Specifications Item Height x Width x Depth With Feet Without Feet Weight External Power Supply Class 2 Transformer normal service input voltage range Unit Power Consumption Approvals FCC Part 15 CISPR 22 Safety Certifications Physical Environment Operating temperature...
Page 23: Important Safety Instructions
Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these slots and openings must not be blocked or covered.
Page 24: Government Requirements
(REN) for this equipment. The label is located on the bottom of your RTU. 2. The Hotwire 6351 ReachDSL Router connects to the Public Switched Telephone Network (PSTN) using the Universal Service Order Code (USOC) RJ11C or RJ14C.
Page 25 — Internet: Visit the Paradyne World Wide Web site at www.paradyne.com. — Telephone: Call our automated system to receive current information via fax or to speak with a company representative. Within the U.S.A., call 1-800-870-2221 Outside the U.S.A., call 1-727-530-2340 If the trouble is causing harm to the telephone network, the telephone company may request that you remove the equipment from the network until the problem is resolved.
Page 26: Declaration Of Conformity
Trade Name: Hotwire Model Number: 6351-A3-200 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 27 Japan – Notices This is a Class B product based on the standard of the Voluntary Control Council for Interference from Information Technology Equipment (VCCI). If this is used near a radio or television receiver in a domestic environment, it may cause radio interference. Install and use the equipment according to the instruction manual.
Page 28: Warranty, Sales, Service, And Training Information
Hotwire is a registered trademark of Paradyne Corporation. ReachDSL is a trademark of Paradyne Corporation. All other products and services mentioned herein are the trademarks, service marks, registered trademarks, or registered service marks of their respective owners. Copyright © 2004 Paradyne Corporation. Printed in U.S.A. " *6351-A2-GN10-20*...
