Hotwirer 6301/6302 IDSL Routers
Installation Instructions
Document Number 6301-A2-GN10-00
July 2000
Contents
Product Documentation on the World Wide Web
We provide complete product documentation online. This lets you search the
documentation for specific topics and print only what you need, reducing the waste of
surplus printing. It also helps us maintain competitive prices for our products.
Complete documentation for this product is available at www.paradyne.com.
Select Library
Select the following document:
6371-A2-GB20
Hotwire DSL Routers User's Guide
To order a paper copy of a Paradyne document:
H
Within the U.S.A., call 1-800-PARADYNE (1-800-727-2396)
H
Outside the U.S.A., call 1-727-530-8623
Product-Related Documents
Document Number Document Title
8000-A2-GB26
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Manuals
Hotwire MVL, RADSL, IDSL, and SDSL Cards, Models
8310/8312/8314, 8510/8373/8374, 8303/8304, and
8343/8344, User's Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
Hotwire DSL and MVL Systems.
1
2
3
4
5
6
10
12
18
Advertisement
Table of Contents
Related Manuals for Paradyne Hotwire 6301
Summary of Contents for Paradyne Hotwire 6301
-
Page 1: Table Of Contents
Installing the DSL Access Wiring Connecting to the DSL Access Wiring Installing the Hotwire 6301/6302 IDSL Router Troubleshooting ........... -
Page 2: Hotwire 6301/6302 Idsl Routers Overview
Hotwire 6301 IDSL Router with one Ethernet port Hotwire 6302 IDSL Router with a 4-port Ethernet hub Both the Hotwire 6301 and the Hotwire 6302 IDSL Routers operate as an IP router connecting a DSL link to an Ethernet network. The Hotwire IDSL packet-based system provides high-speed Internet or corporate LAN access over a combination of traditional twisted-pair copper telephone wiring and ISDN transport, such as T1 or fiber. -
Page 3: Wiring And Cables Needed
CAT5 wiring must meet EIA/TIA-568 specifications with 24 AWG (.5 mm) or 26 AWG (.4 mm). A straight-through or crossover Ethernet cable is used. Refer to Installing the Hotwire 6301/6302 IDSL Router on page 6 for cabling details. Customer Premises (CP) -
Page 4: Installing The Dsl Access Wiring
Optional Cable The Hotwire 6301/6302 IDSL Routers are typically configured remotely by the service provider. The following optional cabling and adapter are only used with this product to configure the router locally: Console cabling: Straight-through cable with 8-pin non-keyed modular plugs (Part No. -
Page 5: Connecting To The Dsl Access Wiring
NID or punchdown block. Attach the wiring that will be connected to the DSL jack. Connecting to the DSL Access Wiring The Hotwire 6301 or 6302 IDSL Router connects to the local loop via wiring from the demarcation point to an RJ11 wall jack. The DSL twisted-pair wiring from the local loop terminates at a new or existing wall jack. -
Page 6: Installing The Hotwire 6301/6302 Idsl Router
Installing the Hotwire 6301/6302 IDSL Router Place the Hotwire 6301/6302 IDSL Router on a flat surface with clearance for the rear connectors. NOTE: The following illustrations show the Hotwire 6302 IDSL Router with a 4-port Ethernet hub. The Hotwire 6301 IDSL Router is identical except that it has one Ethernet port. - Page 7 If you are installing the Hotwire 6302 IDSL Router, go to page 8. For a 6301 IDSL Router, use a straight-through cable to connect the other end to an Ethernet hub. (To connect to a hub’s Uplink connection, use an Ethernet crossover cable).
- Page 8 If you are installing the Hotwire 6301 IDSL Router, go to page 7. For a 6302 IDSL Router, use a straight-through cable to connect the other end to a PC with an Ethernet Network Interface Card (NIC) installed. -and/or- Use an Ethernet crossover cable to connect the other end to an external hub.
- Page 9 800 MA Transformer 00-16764 The Hotwire 6301/6302 IDSL Router hardware installation is now complete. When the power cord is installed, the IDSL router goes through a power-on self-test. Power-On When power is applied, the Hotwire 6301/6302 IDSL Router performs self-diagnostics and the PWR LED is on.
-
Page 10: Troubleshooting
Unplug the unit and reapply power. If the DSL LED is still off, contact the service provider. DSL LED continues The IDSL router is attempting to establish the DSL link. If the to blink after the DSL LED continues to blink for more than ten minutes, contact power-on self-test. - Page 11 PC is connected and powered on. Verify that the correct straight-through or crossover cable is installed. Refer to Installing the Hotwire 6301/6302 IDSL Router on page 6. PWR LED is off. Check that the power cord is securely installed on both ends.
-
Page 12: Cables & Connectors
Increasing the Number of End-User Systems The Hotwire 6301/6302 IDSL Router can support differing numbers of end-user systems depending on the functions that are enabled and traffic loading. Typical configurations will provide support for up to 32, 64, or 256 hosts (end-user systems). - Page 13 The Ethernet interface connector uses an 8-pin, non-keyed modular plug. Use shielded twisted-pair CAT5 or better cables. — To connect a Hotwire 6301 IDSL Router to an Ethernet hub or a Hotwire 6302 IDSL Router to a PC with an Ethernet NIC card installed, use the straight-through connection.
- Page 14 The Console connector uses 8-pin non-keyed modular plugs and a DB9 adapter. See Hotwire 6301/6302 IDSL Router Configuration Setup on page 11. RJ45 8-Pin Connector Pin # Circuit Not used 4 & 5 Signal Ground Not used 8-Pin Modular to DB9 Adapter Plug...
- Page 15 Optional Hotwire 6301/6302 IDSL Router Wall Placement The Hotwire 6301/6302 IDSL Router is designed for tabletop placement. The IDSL router can also be mounted on a wall. To mount the IDSL router, you will need: Three slotted-head #6 self-threading screws with molly bolts...
- Page 16 IDSL Router Hardware Template 5.43" Front (LEDs) 7.55" To Bottom Hole 98-16171...
- Page 17 Hotwire 6301/6302 IDSL Router Technical Specifications Item Height x Width x Depth Weight External Power Supply Class 2 Transformer normal service input voltage range Unit Power Consumption Approvals FCC Part 15 Safety Certifications Physical Environment Operating temperature Storage temperature Relative humidity...
-
Page 18: Important Safety Instructions
Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these slots and openings must not be blocked or covered. -
Page 19: Declaration Of Conformity
Trade Name: Hotwire Model Numbers: 6301-A1-200 & 6302-A1-200 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 20: Document Feedback
Hotwire is a registered trademark of Paradyne Corporation. MVL is a trademark of Paradyne Corporation. All other products and services mentioned herein are the trademarks, service marks, registered trademarks, or registered service marks of their respective owners. *6301-A2-GN10-00* Copyright E 2000 Paradyne Corporation. Printed in U.S.A. *6301–A2–GN10–00*...
