- Page 1 CI_FFH-986(ENG)-A065V Installation and Operating Guide Machine Number | F-986 (Main Unit : FFH-986A, Speakers : F-986S) | HIGH PERFORMANCE MINI COMPOMENT...
-
Page 2: Precautions
Precautions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER(OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSON- NEL. Explanation Graphical Symbols: The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclo-... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANU- AL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. -
Page 4: Table Of Contents
Connections ......8 Speaker System Connection ....8 Antenna (Aerial) Connections. -
Page 5: Before Use
Before Use Safety Precautions Handling the unit When shipping the unit The original shipping carton and packing materials come in handy. For maximum protection, re-pack the unit as it was originally packed at the factory. To keep the surface clean Do not use volatile liquids, such as insecticide spray, near the unit. -
Page 6: Front Panel/Rear Panel
Front Panel/Rear Panel POWER (STANDBY/ON) button • PLAY MODE button • DEMO button • CD SYNC. button • NORMAL DUBBING button HIGH DUBBING button RECORD/ RECORD PAUSE ( FUNCTION SELECT buttons (TUNER, TAPE, CD, AUX) • TUNING DOWN button • PRESET DOWN button •... -
Page 7: Remote Control
Remote Control TAPE-A APE-A TAPE-B APE-B Display Window 1 2 3 PLAY/ PAUSE indicator PROGRAM indicator REPEAT indicator SLEEP indicator TIMER indicator FM STEREO RECEIVING indicator CD SYNC. indicator MEMORY indicator CD TRACK indicator 10. CD TRACK OVER indicator 11. AUTO TUNE RECEIVING indicator XDSS button POWER button TUNER/BAND button... -
Page 8: Connections
Connections Speaker System Connection Connect the speakers using the supplied speaker cords by matching the colors of the terminals and those of the cords. To obtain the best possible surround sound, adjust the speaker parameters (distance, level, etc.). Right speaker Notes •... -
Page 9: Setting The Clock
Setting the CLOCK Press CLOCK. (If the clock is requires setting, press and hold CLOCK for more than 2 seconds.) - The hours begin to blink. Select a 24 hour cycle or 12 hour cycle by turning MULTI JOG SHUTTLE. (12HR) Press SET to confirm the selected hour cycle. -
Page 10: Timer Function
Timer Function With the TIMER function you can have the radio reception and recording, CD play, tape play or auxiliary source play and recording turned on and off at the time desired. Press CLOCK to check the current time. Press “TIMER” to enter the timer setting mode. -
Page 11: Audio Adjustment
Audio Adjustment Volume Adjustment • Turn VOLUME DOWN/UP knob clockwise to increase the sound level, or counterclockwise to decrease it. • Press VOLUME CONTROL ( ) to increase the sound level, or press the VOLUME CONTROL ( decrease it on the remote control. Sound Quality Adjustment •... -
Page 12: Presetting The Radio Stations
Presetting the radio stations You can preset 30 stations for FM and AM. Before tuning, make sure that you have turned down the volume to the minimum. POWER TUNER MEMO TAPE-A TAPE-B • TUNING DOWN/UP • PRESET DOWN/UP • STOP ( )/ CLEAR Press POWER to turn on the unit. -
Page 13: Listening To The Radio
Listening to the radio Preset radio stations in the units memory first (see “Presetting radio stations” on the previous page). POWER TUNER TAPE-A TAPE-B •TUNING DOWN/UP •PRESET DOWN/UP Press TUNER or TUNER/BAND until AM or FM appears in the display window. The last received station is tuned in. -
Page 14: Tape Playback
Tape Playback PLAY MODE NOR./Hi DUBB TAPE TAPE-A • • PLAY ( • STOP ( Basic Playback Press TAPE repeatedly or TAPE-A/B to select TAPE A or TAPE B. (“NO TAPE” appears in the display window.) Open cassette TAPE A (or B) by pushing PUSH OPEN position. -
Page 15: Recording
Recording Wind the tape to the point recording starts. Use only normal tapes. You can record from cassette deck B only. PLAY MODE CD SYNC. TUNER TAPE-A TAPE-B Basic Setting Press CD or TUNER/BAND. Open the cassette TAPE B and insert a blank cassette into the cassette compartment. -
Page 16: Cd Playback
CD Playback DISC SKIP DISC 1,2,3 POWER TAPE-A TAPE-B Basic Playback Press POWER to turn on the unit. Press the CD button to enter the CD mode. If no disc is entered in the disc drawer, the “NO DISC” indicator is displayed. Press CD OPEN/CLOSE(CD ) and place the disc into the disc tray. -
Page 17: To Replace Discs During Playback
CD Playback (Cont’d) TAPE-A TAPE-B To Replace discs during Playback You can open the disc tray during playing a disc to check what discs are to be played next and replace discs without interrupting playback of the current disc. Press the CD OPEN/CLOSE (CD The disc tray is opened. -
Page 18: To Program Play
CD Playback DISC 1,2,3 PROG. TAPE-A TAPE-B To Program Play You can arrange the order of the tracks on the discs and create your own program. The program can contain up to 20 tracks. Press PROG. (or PROGRAM on the remote control) on the stop mode. -
Page 19: Troubleshooting
Troubleshooting Check the following guide for the possible cause of a problem before contacting service. Symptom No power. • The power cord is disconnected. • The audio cables are not connected No sound. securely. • The power of the external source equip- ment is switched off. -
Page 20: Specifications
Specifications Power supply Power consumption Mass External dimensions (W x H x D) Frequency response Signal-to-noise ratio Dynamic range Tuning Range Intermediate Frequency Signal to Noise Ratio Frequency Response Tuning Range Intermediate Frequency Signal to Noise Ratio Frequency Response Output Power T.H.D Frequency Response Signal-to-noise ratio...
