- Page 1 Baby Monitor Hero2 User Manual...
-
Page 2: Safety Instructions
Congratulation! Thanks for your patronage of our products and welcome to nannio Baby Caring World! You can start to take care your baby whenever and wherever you want. This user manual has all the feature operations and troubleshooting necessary to install and operate your nannio Baby monitor. Please review this manual thoroughly to insure proper installation and operation of this product. - Page 3 WARNING: STRANGULATION HAZARD. Children have STRANGLED in cords. Keep this cord out of the reach of children (more than 3.5 feet (1 meter) away). Do not remove the tag. Please make sure you have the following in the packing. 1 x Parent unit 1 x Baby unit 2 x Power Adapter 1 x Wall-Mount Kit...
-
Page 4: Baby Unit
Baby unit Camera Power on light Lullaby on/off button Antenna On/off slide Microphone Speaker Socket for power adapter Parent unit Display Link Battery status VOX light Speaker Antenna On/off button Mode button Talk-back Lullaby button Socket for power adapter VOX button Control button Microphone 13 14... - Page 5 Power on the baby monitor Baby unit Parent unit Connect the power adapter with Connect the power adaptor with the the baby unit. parent unit. Note: The parent unit is built-in a rechargeable Li-ion battery. There are 3 battery status indicators: Green light : The battery is fully charged Orange light : The appliance is charging Red light : The battery is almost empty and...
- Page 6 Connect parent unit and baby unit Push the on/off switch on the baby Press the on/off button on the parent unit to the ON position. unit to turn on the unit. Note: When the baby unit is turned on, the power indicator always lights up in green Automatic connection When the parent unit is turned on, it starts to search for the baby...
- Page 7 Placement of baby monitor >2.5m/8.2ft >1-1.5m/3-3.5ft Place the parent unit within the Make sure that the distance between operating range of the baby unit. Make the baby unit and baby is more than sure it is at least 2.5 meters/8.2 feet 1-1.5 meters/3-3.5 feet, because of away from the baby unit to avoid potential strangulation hazards.
-
Page 8: Features And Settings
Features and settings Volume You can adjust the speaker volume of the parent unit to the level you like. Press the top or bottom part of the control button to adjust the volume. The volume icon appears on the display to show the selected volume. -
Page 9: Operation Modes
Operation modes Video•Audio•VOX With the baby monitor turned on, you can choose 3 different modes by pressing the mode button on the side of the parent unit. Video Mode Press the mode button on the side of the parent unit to select the VIDEO mode. - Page 10 VOX Mode Press the mode button on the side of the parent unit to select VOX mode. When the VOX mode is activated, the display and sound of the parent unit turned off. And the VOX light becomes green When sound is picked up by the baby unit, the display and sound of the parent unit turned on immediately.
-
Page 11: Two-Way-Talk
Lullaby volume 1. Press the lullaby button on the parent unit to open the menu for lullabies. Press the left part of the control button and then press the bottom of the control button to select the volume options of the lullaby menu. Press the right part of the control button to access the lullaby volume levels. - Page 12 Voice activation (sensitivity) Voice Activation The sensitivity level of the baby unit defines what you hear through the parent unit. When the level is set high, you will hear many sounds, including soft background sounds. When the sensitivity level is set low, you will hear only the louder sounds.
-
Page 13: Technical Specifications
Technical specifications Baby unit Auto Infrared Night Vision Auto Out of Range Warning Temperature Sensor Lullabies Yes, 5x Manual Pan-Tilt Auto Infrared Night Vision Auto Out of Range Warning Parent unit LCD Screen 2.7" Talkback Function Vibration Mode Voice Activation Screen Yes, VOX mode Auto Out of Range Warning Battery Low Indicator... -
Page 14: Wall Mount
Wall mount Printing instructions: Print this page in scale 100 % and use the template to accurately mark the position of the holes for the screws on the wall. Version1.1.0...
