Summary of Contents for Jabra Elite 25h
- Page 1 Jabra Elite 25h User manual...
-
Page 2: Technical Specifications
1. WELCOME ........3 2. WHAT’S IN THE BOX ....4 3. HOW TO WEAR ......5 3.1 HEIGHT ADJUSTMENT 4. HOW TO CHARGE ....6 4.1 BATTERY STATUS 5. HOW TO CONNECT ....7 5.1 BLUETOOTH CONNECT TO A NEW OR SECOND MOBILE DEVICE 5.2 CONNECT TO 3.5 MM JACK CONNECTOR 6. - Page 3 1. WELCOME Thank you for purchasing the Jabra Elite 25h. We hope you will enjoy it! JABRA ELITE 25H FEATURES ƒ Premium wireless sound experience - amplifies without distortion. Brings out the depth and clarity of your music ƒ Seals the sound - angled earcups allow you to hear all the music ƒ...
-
Page 4: What's In The Box
2. WHAT’S IN THE BOX Adjustable Volume Headband up button On/Off/ Multi-function Pairing button switch Battery and Connec- tion Status Volume Lights down button 3.5 mm Jack Micro-USB Port Connector (charging only) Audio cable Micro-USB cable... -
Page 5: How To Wear
3. HOW TO WEAR 3.1 HEIGHT ADJUSTMENT Get the perfect fit by adjusting the headband, as illustrated. -
Page 6: How To Charge
4. HOW TO CHARGE Plug the headphones into any available USB port on your PC using any micro-USB cable. 4.1 BATTERY STATUS Tap the Multi-function button when not on a call to see the battery status. It takes 1-2 hours to fully charge the headphones. -
Page 7: How To Connect
5. HOW TO CONNECT The Jabra Elite 25h will automatically attempt to Bluetooth connect to a mobile device whenever it is powered on (unless already connected to a Bluetooth device). Simply follow voice-guided connection instructions. 5.1 BLUETOOTH CONNECT TO A NEW OR SECOND MOBILE DEVICE 1. - Page 8 NOTE: If two mobile phones have been connected to the Jabra Elite 25h, you may need to select which phone will be used for calls/music. Simply open the Bluetooth menu on the mobile phone you wish to use for calls/music and select the Jabra Elite 25h from the list of devices.
-
Page 9: How To Use
6. HOW TO USE Volume up button Multi-func- Off/ tion button Pairing switch Volume down button... - Page 10 6.1 MUSIC & CHAT The buttons on the headphones enable you to control your music and phone calls. FUNCTION HOW TO DO IT Multi-function Tap the Pause/play music button Volume up Tap the Adjust volume Volume down button Press and hold either the Volume up Volume Skip track...
-
Page 11: Multiple Call Handling
6.2 TURN HEADPHONES ON/OFF Slide the On/Off/Pairing switch to On or Off. 6.3 MULTIPLE CALL HANDLING The headphones can accept and handle multiple calls simultaneously. FUNCTION HOW TO DO IT Put current call on Multi- Press (2 secs) the hold and answer function button incoming call... -
Page 12: How To Care For Your Headphones
7. SUPPORT 7.1 FAQ View the full FAQ at jabra.com/help/elite25h 7.2 FACTORY RESET To factory reset the headphones and clear the pairing list, press and hold (5 secs) both the Volume up button and the Multi-function button at the same time. - Page 13 8. TECHNICAL SPECIFICATIONS JABRA ELITE 25H SPECIFICATION Weight: 150 grams H 172 mm x W 146.1 mm x L 59 Dimensions: 4 mm Omni-directional Microphone: microphone Speaker: 40 mm dynamic speaker Operating range: Up to 10 meters (33 feet) Bluetooth version:...
