- Page 1 VIDEO INTERCOM DOOR STATION (HYU-558) Quick Start Guide...
- Page 2 Video Intercom Door Station·Quick Start Guide Quick Start Guide This quick start guide is intended for users of the HYU-558 door station. Disclaimer REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. OUR COMPANY SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS;...
- Page 3 Video Intercom Door Station·Quick Start Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 4 Video Intercom Door Station·Quick Start Guide 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg).
- Page 5 Video Intercom Door Station·Quick Start Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death. Cautions: Neglecting any of the cautions may cause injury or equipment damage.
- Page 6 Video Intercom Door Station·Quick Start Guide Model Manufacturer Standard DSA-12PFG-12 FUK 120100 Dee Van Electronics Co., Ltd. DSA-12PFG-12 FAU 120100 Dee Van Electronics Co., Ltd. Cautions Do not drop the device or subject it to physical shock, and do not expose it to high electromagnetism radiation.
-
Page 7: Table Of Contents
Video Intercom Door Station·Quick Start Guide Table of Contents 1 Appearance ....................1 1.1 Appearance of Type I Model ..................1 1.2 Appearance of Type II Model ................... 2 2 Terminal and Wiring ..................4 2.1 Terminal Description ....................4 2.2 Wiring Description .................... -
Page 8: Appearance
1 Appearance 1.1 Appearance of Type I Model For type I HYU-558 door station, there are three sub types according to the amount of call button. These three sub types have 1 call button, 2 call buttons, and 4 call buttons respectively. -
Page 9: Appearance Of Type Ii Model
Video Intercom Door Station·Quick Start Guide You need not customize the Room No. for the sub type V series door station with 1 call button only. Default settings of call button: when you press the call button, it calls the resident; and when you hold down the call button, it calls the center. - Page 10 Video Intercom Door Station·Quick Start Guide Default settings of call button: when you press the call button, it calls the resident; and when you hold down the call button, it calls the center. You can change the calling mode of the call button via Batch Configuration Tool or iVMS-4200 client software.
-
Page 11: Terminal And Wiring
Video Intercom Door Station·Quick Start Guide 2 Terminal and Wiring 2.1 Terminal Description Please refer to the following figure for terminals and interfaces of door station. Figure 2-1 Terminals and Interfaces Table 2-1 Descriptions of Terminals and Interfaces Terminals and Interfaces Name Color Description... -
Page 12: Wiring Description
Video Intercom Door Station·Quick Start Guide 4 I/O Input terminals (ALARM_1~ALARM_4) can be set as door magnetic input or door switch key input, and terminal ALARM_GND is for grounding connection. 1 I/O Output terminal can be enabled for controlling electric lock or disabled. 2.2 Wiring Description 2.2.1 Door Lock Wiring Figure 2-2 Door Lock Wiring... -
Page 13: Door Magnetic Wiring
Video Intercom Door Station·Quick Start Guide 2.2.2 Door Magnetic Wiring Figure 2-3 Door Magnetic Wiring To connect door magnetic, it is required to set the input of one alarm in terminal (ALARM_1, ALARM_2, ALARM_3, or ALARM_4) to be door magnetic with Batch Configuration Tool or iVMS-4200 client software. -
Page 14: Alarm Device Input Wiring
Video Intercom Door Station·Quick Start Guide To connect exit button, it is required to set the input of one alarm in terminal (ALARM_1, ALARM_2, ALARM_3, or ALARM_4) to be exit button with Batch Configuration Tool or iVMS-4200 client software. 2.2.4 Alarm Device Input Wiring Figure 2-5 Alarm Device Input Wiring To connect other alarm devices, it is required to set the input of one alarm in terminal (ALARM_1, ALARM_2, ALARM_3, or ALARM_4) to be custom with Batch Configuration... -
Page 15: Rs-485 Card Reader Wiring
Video Intercom Door Station·Quick Start Guide 2.2.5 RS-485 Card Reader Wiring Figure 2-6 RS-485 Card Reader Wiring... -
Page 16: Installation
Video Intercom Door Station·Quick Start Guide 3 Installation 3.1 Installation of Type I Model To install the door station onto the wall, you are required to utilize a matched gang box. 3.1.1 Gang Box for Type I Model Please refer to the following figures for the dimensions of gang box for type I door station. -
Page 17: Wall Mounting With Gang Box Of Type I Model
Video Intercom Door Station·Quick Start Guide 3.1.2 Wall Mounting with Gang Box of Type I Model 1. Take the gang box and screws from the packing box. 2. Chisel a hole in the wall for inserting the gang box. The size of the hole should be 90 (width) ×170 (length) ×... -
Page 18: Installation Of Type Ii Model
Video Intercom Door Station·Quick Start Guide M4 Screw Figure 3-4 Secure the Door Station (Type I) 3.2 Installation of Type II Model 3.2.1 Installation Plate for Type II Model To install type II model onto the wall, an installation plate and a gang box are required. Hollow Area 41.48 72.7... -
Page 19: Wall Mounting With Gang Box Of Type Ii Model
Video Intercom Door Station·Quick Start Guide The dimension of gang box for type II door station is: 75 (width) × 75 (length) × 50 (depth) mm. The dimensions above are theoretical. The actual size can be slightly different from the theoretical dimension. 3.2.2 Wall Mounting with Gang Box of Type II Model 1. - Page 20 Video Intercom Door Station·Quick Start Guide 6. After installing the installation plate, install the door station by inserting the rear component into the hollow area of the installation plate. While inserting the door station into the installation plate, incline the device by 5~10°, as shown in the figure below.
-
Page 21: Remote Operation Via Batch Configuration Tool
Video Intercom Door Station·Quick Start Guide 4 Remote Operation via Batch Configuration Tool 4.1 Activating Device Remotely You are required to activate the device first by setting a strong password for it before you can use the device. Activation via Batch Configuration Tool, and Activation via iVMS-4200 are supported. Here take activation via Batch Configuration Tool as example to introduce the device activation. -
Page 22: Editing Network Parameters
Video Intercom Door Station·Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the security of your product. -
Page 23: Adding Device
Video Intercom Door Station·Quick Start Guide Figure 4-4 Editing Network Parameters The default port No. is 8000. After editing the network parameters of device, you should add the devices to the device list again. 4.3 Adding Device For batch configuration tool and iVMS-4200 software, you should add device to the software so as to configure the device remotely. -
Page 24: Adding By Ip Address
Video Intercom Door Station·Quick Start Guide Figure 4-6 Login Dialog Box 3. Enter the user name and password. 4. Click the OK button to save the settings. Only devices successfully logged in will be added to the device list for configuration. If you add devices in batch, please make sure selected devices have the same user name and password. - Page 25 Video Intercom Door Station·Quick Start Guide Figure 4-8 Adding by IP Address 4. Click the OK button to add the device to the device list. You cannot add the device(s) to the device list if the user name and password are not identical.
-
Page 26: Local Operation
5.1 Calling Resident 5.1.1 Calling Resident (Type I) You can call the resident by pressing the call button. For type I HYU-558 door station, there are three sub types according to the amount of call button. These three sub types have 1 call button, 2 call buttons, and 4 call buttons respectively. -
Page 27: Calling Resident (Type Ii)
5.1.2 Calling Resident (Type II) You can call the resident by pressing the call button. For type II HYU-558 door station, there is only 1 call button. -
Page 28: Issuing Card
Video Intercom Door Station·Quick Start Guide When the video intercom between you and the resident is realized, you can speak to the resident, and the live view of door station will be displayed on the connected indoor station. When the door station is calling resident, the door station will detect the brightness of video automatically. -
Page 29: Unlocking Door
Video Intercom Door Station·Quick Start Guide 5.3 Unlocking Door After issuing cards, you can unlock the door by swiping the issued card. 1. Swipe the card on the card induction area. 2. Hear a voice prompt of the device: Door is open. You cannot unlock the door by swiping the main card. -
Page 30: Appendix
Video Intercom Door Station·Quick Start Guide Appendix Installation Notice While installing the door station, please make sure that the distance between any two devices is far as possible to avoid the howling and echo. The distance between two devices is recommended to be longer than 10 meters. Devices here refer to indoor station, door station, doorphone and master station. - Page 31 Licensed by HYUNDAI Corporation, Korea...
