OPERATOR'S MANUAL
3000
TRACTOR
Model 3165
IMPORTANT: READ SAFETY RULES AND INSTRUCTIONS CAREFULLY
Warning
: This unit is equipped with an internal combustion engine and should not be used on or
near any unimproved forest-covered, brush-covered or grass-covered land unless the engine's
exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any). If a
spark arrester is used, it should be maintained in effective working order by the operator. In the State
of California the above is required by law (Section 4442 of the California Public Resources Code).
Other states may have similar laws. Federal laws apply on federal lands. A spark arrester for the
muffler is available through your nearest engine authorized service dealer or contact the service
department, P.O. Box 368023 Cleveland, Ohio 44136-9723.
CUB CADET P.O. BOX 368023 CLEVELAND, OHIO 44136-9723
FORM NO. 770-0834B
(9/98)
Advertisement
Table of Contents
Related Manuals for Cub Cadet 3165
Summary of Contents for Cub Cadet 3165
- Page 1 Other states may have similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 368023 Cleveland, Ohio 44136-9723. CUB CADET P.O. BOX 368023 CLEVELAND, OHIO 44136-9723 FORM NO. 770-0834B (9/98)
-
Page 2: Table Of Contents
As with any type of power equipment, carelessness or error on the part of the operator can result in serious injury. This lawn mower is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury or death. - Page 3 • Clear the area of objects such as rocks, toys, wire, etc., which could be picked up and thrown by the blade. A small object may have been overlooked and could be accidentally thrown by the mower in any direction and cause injury to you or a bystander.
- Page 4 2. SLOPE OPERATION Slopes are a major factor related to loss of control and tip-over accidents which can result in severe injury or death. All slopes require extra caution. If you cannot back up the slope or if you feel uneasy on it, do not mow it. For your safety, use the slope gauge included as part of this manual to measure slopes before operating this...
- Page 5 • Remove key when machine is unattended to prevent unauthorized operation. 4. SERVICE • Use extreme care handling gasoline and other fuels. They are extremely flammable and the vapors are explosive. • Use only an approved container. • Never remove fuel cap or add fuel with the engine running.
-
Page 6: Calling Service Information
Manual. The information on the model plate is very important if you need help from your dealer or the Cub Cadet customer support department. • Every tractor has a model plate. The model plate is located on the right frame rail behind the right front tire. -
Page 7: Safety Labels Found On Your Unit
SECTION 5: SAFETY LABELS FOUND ON YOUR UNIT IGNITION STOP ST ARTING INSTRUCTIONS 1. BE FAMILIAR WITH CONTROLS BEFORE STARTING ENGINE AND OPERATING. 2. SET CHOKE, MOVE THROTTLE TO MID POSITION AND DEPRESS BRAKE PEDAL. 3. TURN KEY TO THE START POSITION. -
Page 8: Controls
SECTION 6: CONTROLS Parking Brake Lever PTO Switch Brake Pedal Reverse Pedal Forward Pedal Ignition/Light Switch Center Lift Height Indicator Transmission Release Rod Transmission Oil Fill/Dipstick * Steering Wheel and Seat Removed For Clarity (Not Shown) Figure 3 Fuel Fill Cap Cup Holder Hydraulic Lift Lever Steering Wheel Tilt Lock... - Page 9 NOTE: References to LEFT and RIGHT indicate that side of the tractor when facing forward while seated in the drivers seat. Reference to FRONT indicates the grille end of the tractor; to REAR, the drawbar end. Steering Wheel The steering wheel is centered on the dash panel.
- Page 10 Ignition / Light Switch To prevent accidental starting and/or battery discharge, remove the key from the ignition switch when the tractor is not in use. The combination lights and ignition switch has four positions. Figure description of each position. On/Lights Start Figure 8 Center Lift Height Indicator...
- Page 11 If the oil level is within the operating range, and the light remains on, contact your Cub Cadet dealer. Low Fuel Indicator The Low Fuel indicator is part of the indicator light pod on the dash panel.
-
Page 12: Operation
This tractor is equipped with a safety interlock system for the protection of the operator. If the interlock system should ever malfunction, operate the tractor. Contact your authorized Cub Cadet Dealer. The safety interlock system prevents the engine from cranking starting unless brake pedal depressed, and the PTO is “OFF”. - Page 13 • Place the PTO switch in the “OFF” position. Move the throttle control lever to the “MID” position. Then turn the ignition key to the “OFF” position. • Remove the key from the ignition switch. Driving The Tractor WARNING: Avoid sudden starts, excessive speed and sudden stops.
- Page 14 See Figure 11. Hitch Hole Drawbar Figure 11 Mowing This tractor can be equipped with one of Cub Cadet’s high quality mowing decks. The following information will be helpful when using a Cub Cadet mowing deck with your tractor.
-
Page 15: Adjustments
WARNING: To avoid possi- ble injury, do not allow anyone in the area opposite the dis- charge chute while mowing. Although the area has been supposedly cleared of foreign objects, small objects may be picked up and discharged by the mower. WARNING: Never direct the discharge of material... - Page 16 Steering Wheel Tilt Adjustment WARNING: Do not adjust the steering wheel when the tractor is moving. Adjusting the steering wheel while the tractor moving could cause the operator to lose control of the tractor. To allow for the comfort of the operator, easy operate...
-
Page 17: Maintenance
This tractor is equipped with power assisted steering which is set at the factory. The turning radius should be equal for both left and right hand turns. If adjustment is necessary please con- tact your authorized Cub Cadet dealer. • • • •... -
Page 18: Lubrication Illustration
SECTION 10: LUBRICATION ILLUSTRATION Cub Cadet 251H EP Grease or equivalent No. 2 lithium grease Engine Oil: See Figure 24 on page 28 Transmission Oil-See your Cub Cadet Dealer Oil Can (High quality lubricating oil) - Page 19 Accessing Engine Compartment The engine compartment can be accessed by lifting the hood upward from the recessed notches of the side panels and tipping the hood forward. If greater access is required, the tractor is equipped with quick release side Lift Hood Here Turn Flip up...
- Page 20 Battery Removal The battery is located under the dash panel in the frame pedestal. To remove the battery: • Open the tractor hood by lifting it at the notches in the side panels. • Remove the upper baffle of the bulkhead from the front of the dash panel by lifting upward on the locking tab on each side of the...
- Page 21 • Lift the hood to expose the back side of the headlight assembly. • Pull both locking tabs away from light bulb and pull wire harness away. See Figure 17. • Remove the light bulb from the reflector turning counterclockwise. The light bulb will be free of the reflector when the notches in thereflector and the tabs on the bulb are aligned.
- Page 22 Check the oil level of the transmission case before each use to see that it is filled to the correct level. Before checking the transmission oil level, clean the area around the Transmis- sion Oil Fill/Dipstick to prevent debris from entering the transmission case. Always keep the oil level between the “FULL”...
- Page 23 NOTE: Do not reuse the transmission oil. Contaminated transmission oil can damage the hydro transmission. Please dispose of used oil appropriate recycling centers. • Clean around the base of the transmission oil filter and remove filter turning counterclockwise. • Apply a light coating of clean transmission oil to the gasket of the new filter.
- Page 24 Voltage Indicator Module Open Relay 25 Amp Open Fuses Figure 20 Fuse Fuses are installed to protect the tractor’s electrical system damage caused excessive amperage. Always use the same capacity fuse for replacement. Refer Specifications Chart. If the electrical system does not function, check the fuses.
-
Page 25: Engine Information
SECTION 11: ENGINE INFORMATION BRIGGS & STRATTON CORP., FEDERAL (U.S. EPA) AND CALIFORNIA EMISSION CONTROL SYSTEMS WARRANTY (Owner’s Defect Warranty Rights and Obligations) In the interest of the environment, Briggs & Stratton engines that meet strict emission requirements are labeled, “This engine conforms to 1995 - 1998 California emission regulations for ULGE engines and U.S. -
Page 26: Cleaning The Engine
Miscellaneous Items Used in Above Systems - Vacuum, temperature, position, time sensitive valves and switches - Connectors and assemblies Length Coverage — engine manufacturer warrants to the initial owner and each subsequent purchaser that the Warranted Parts shall be free from defects in materials and workmanship which caused the failure of the Warranted Parts for a period of two years from the date the engine... - Page 27 Before checking the oil level, clean the area around the oil level dipstick to prevent debris from entering the crankcase. See Figure 23. Always keep the oil level between the “FULL” and the “ADD” marks on the dipstick. See Figure 22. When checking the oil level, the engine must be cold, the dipstick must be withdrawn and wiped clean, then...
- Page 28 See (Figure 24), VISCOSITY CHART, below for the proper type of oil. Above +40° F SAE 30W 0° to 40° F SAE 5W30 SAE 10W30 Below 0° F SAE 5W20 SAE 5W30 Figure 24 The oil filter is located behind the left side panel and is mounted on the engine.
- Page 29 To remove the spark plugs, always use a spark plug wrench. Check the gap after every 100 hours of operation. Replace a defective plug with a new plug. Set the spark plug gap at .030 inch. Tighten the plug to 10-15 ft-lbs. See your authorized dealer for the correct replacement plug.
- Page 30 • Remove the foam precleaner by sliding it up off the paper element. • Lift out the paper air filter element. • Do not wash the paper element or use pressurized air, as this will damage the element. Replace a dirty, bent or damaged element.
-
Page 31: Trouble Shooting
SECTION 12: TROUBLE SHOOTING Possible Cause Hard To Start No fuel in fuel tank or carburetor Fuel ine or carburetor clogged Fuel filter plugged Water in fuel Choked improperly. Flooded engine Defective ignition or loose wiring Defective battery Spark plug dirty or improperly gapped Engine Operates Irregularly or Knocks Engine incorrectly timed Spark plug dirty;... -
Page 32: Optional Equipment
However, later you may wish to obtain optional equipment or accessories. These items and other allied equipment can be purchased from, and installed by, your authorized Cub Cadet dealer. This tractor can be used for many different types of work, and because it is called on to operate under many different conditions, a variety or equipment is available to adapt it to the requirements of the user. -
Page 33: Specifications
Transmission ........Hydrostatic Transmission Oil ....See your local Cub Cadet Dealer Transmission Oil Capacity . -
Page 34: Quick Reference Parts
SECTION 15: QUICK REFERENCE PARTS Description Engine Oil Air Filter CARTRIDGE Engine Oil Filter Spark Plug Transmission Oil Transmission Oil Filter Mower Deck Blades Mower Deck Belts PTO Belt (set of 2) Part Number 737-3029 (SAE 30) 737-3030A (10W30) 737-3049 (5W30) BS-394018 FOAM BS-272490... -
Page 35: Slope Gauge
SECTION 16: SLOPE GAUGE WARNING: Do not mow on inclines with a slope in excess of degrees (a rise of approximately 2-1/2 feet every 10 feet). A riding mower could overturn and cause serious injury. If operating a walk- behind mower on such a slope, it is extremely difficult to maintain your footing and you could slip, resulting in serious injury. -
Page 36: Limited Warranty
This limited warranty for residential users, covers any defect in materials or workmanship in your Cub Cadet equipment for two years from the date of purchase for the first user purchaser. We will replace or repair any part or parts without charge through your authorized Cub Cadet dealer.
