  • Page 1 LWR9816O5X User Manual Washer Dryer USER MANUAL...

  • Page 2: Table Of Contents

    13. DAILY USE - WASHING & DRYING..............36 14. DAILY USE - DRYING ONLY................38 15. FLUFF IN THE FABRICS..................39 16. HINTS AND TIPS....................39 17. CARE AND CLEANING..................42 18. TROUBLESHOOTING..................50 19. CONSUMPTION VALUES................55 20. ENVIRONMENTAL CONCERNS..............58 My AEG Care app...

  • Page 3: Safety Information

    ENGLISH FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
  • Page 4 Children between 3 and 8 years of age and persons • with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised.
  • Page 5 ENGLISH Do not install the appliance behind a lockable door, a • sliding door or a door with a hinge on the opposite side, that would prevent the appliance door from being fully open. Connect the mains plug to the mains socket only at •...
  • Page 6 Items that have been soiled with substances such as • vegetable or mineral oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed separately with an extra amount of detergent before being dried in the washer dryer.

  • Page 7: Safety Instructions

    ENGLISH 2. SAFETY INSTRUCTIONS 2.1 Installation to a grounding connection in the building. The installation must comply • Always use a correctly installed with relevant national shockproof socket. regulations. • Do not use multi-plug adapters and extension cables. • Follow the installation instructions •...
  • Page 8 • Do not touch the glass door while a has been discontinued: motor and programme operates. The glass can motor brushes, transmission between get hot. motor and drum, pumps, shock • Do not dry damaged (torn, frayed) absorbers and springs, washing drum, items that contain padding or fillings.

  • Page 9: Product Description

    ENGLISH 3. PRODUCT DESCRIPTION 3.1 Appliance overview 13 14 Worktop Airflow slots Detergent dispenser Water drain hose Air filter(s) Water inlet valve Control panel Mains cable Door handle Transit bolts Rating plate Hose supports Drain pump filter Feet for levelling the appliance The rating plate reports: A.

  • Page 10: Installation

    Electrical connection Voltage 230 V Overall power 2200 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles IPX4 and moisture ensured by the protective cover, ex‐ cept where the low voltage equipment has no pro‐...
  • Page 11 ENGLISH 7. Remove the polystyrene protection from the bottom. 3. Remove the internal film. 8. Pull up the appliance in vertical position. 4. Open the door and remove the polystyrene piece from the door seal and all the items from the drum. 9.
  • Page 12 11. Pull out the plastic spacers. We recommend that you 12. Put the plastic caps, that you find in keep the packaging and the the user manual bag, in the holes. transit bolts for any movement of the appliance.
  • Page 13 ENGLISH A correct adjustment of the appliance level prevents the vibration, noise and the movement of the appliance when in operation. When the appliance is installed on a plinth, use the accessory described in chapter 'Accessories'. Read carefully the instructions WARNING! supplied with the appliance The inlet water shall not...
  • Page 14 You can extend the drain hose to maximum 400 cm. Contact the authorized service centre to buy the other drain hose and the extension. It is possible to connect the drain hose in different ways: min.600 mm max.1000 mm •...

  • Page 15: Control Panel

    ENGLISH The rating plate and the 'Technical Data' The power supply cable must be easily chapter indicate the necessary electrical accessible after installing the appliance. ratings. Make sure that they are For any electrical work required to install compatible with the mains power supply. this appliance, contact our Authorised Check that your domestic electrical Service Centre.
  • Page 16 On/Off push button (On/Off) Temperature touch button (Temp.°C) 6.2 Display Laundry weight indicator. The icon flashes during laundry load esti‐ mation (refer to "ProSense load detection" paragraph). Maximum laundry indicator. It flashes when the laundry load exceeds the maximum declared load of the selected programme.

  • Page 17: Dial And Buttons

    ENGLISH The permanent Extra Rinse option: • - one additional rinse. • - two additional rinses. Spin and drain phase indicator. It flashes during spin and drain phase. Steam phase indicator. Drying phase indicator. Indicator for the cleaning of air filters. Iron drying indicator.
  • Page 18 7.2 Introduction Touch Inicio/Pausa button: the appliance performs the spinning The options/functions are phase and drains the water. not selectable with all • Activate the Extra silent option. washing programmes. All spinning phases (intermediate spin Check the compatibility and final spin) are suppressed and...
  • Page 19 ENGLISH This option is recommended for This option can increase the heavily soiled laundry, especially if programme duration. containing sand, dust , mud and other solid particles. By touching any button the anti-crease movements stop and the door unlocks. This option can increase the programme duration.

  • Page 20: Programmes

    7.12 Inicio/Pausa • Only washing : Lavar indicator is on. • Washing and drying : Lavar and Touch the Inicio/Pausa button to start, Secar indicators are on. pause the appliance or interrupt a • Only drying : Secar indicator is on.
  • Page 21 ENGLISH Programme Reference Maxi‐ Programme description Default temperature spin speed Temperature range Spin speed load range Delicate fabrics such as acrylics, vis‐ 1200 rpm cose and mixed fabrics requiring gen‐ Delicados 1200 rpm - 400 2.0 kg tler washing. Normal soil. 30 °C 40 °C - Cold Machine washable wool, hand washa‐...
  • Page 22 Programme Reference Maxi‐ Programme description Default temperature spin speed Temperature range Spin speed load range Cotton, synthetic and mixed items. Special steam cycle without washing Vapor that can be used to prepare your dried laundry for ironing or refreshing gar‐...
  • Page 23 ENGLISH Programme Reference Maxi‐ Programme description Default temperature spin speed Temperature range Spin speed load range 1600 rpm To spin the laundry and to drain the 1600 rpm - water in the drum. All fabrics, except 10.0 kg Centrif./Drenar woollens and delicate fabrics. 1) According to Commission Regulation EU 2019/2023.
  • Page 24 Options ■ ■ ■ ■ ■ ■ ■ Aclarado/Enxag. Extra ■ ■ ■ Pré-lavado ■ ■ ■ Manchas ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Inicio diferido ■ ■ ■ ■ ■ Rápido ■ ■ ■...
  • Page 25 The fragrance is available on Hang items out for a few AEG web shop or by minutes. authorised dealer. The fragrance (AEG Steam Fragrance) The AEG Steam Fragrance allows you to refresh even your delicate clothes,...
  • Page 26 8.3 Automatic drying Initial cycle times for programmes with Seca. Auto‐ mátic. option are only estimates, the actual drying time may slightly differ from the time displayed. Dryness Level Type of fabric Load Cottons and Linen up to 6 kg...
  • Page 27 ENGLISH 8.4 Timed drying Dryness Level Type of fabric Load Spin Suggested (kg) spee duration (mins) (rpm) Extra Dry Cottons and Linen 1600 280 - 300 For towelling (bathrobes, bath towels, etc) 1600 170- 190 materials 1600 120 - 130 Cupboard Dry Cottons and Linen 1600...

  • Page 28: Wi-Fi - Connectivity Setup

    1. Go to the App Store on your smart see 'QR device or scan QR code ( code on rating plate' paragraph ). 2. Download and install the My AEG Mod. xxxxxxxxx Prod.No. 910000000 00 Care App.
  • Page 29 The access point will be open for about 3 possible to start a washing minutes. programme remotely. This 5. Configure the My AEG Care app on function is deactivates when your smart device and follow the door is open. instructions to connect the appliance to your Wi-Fi network.

  • Page 30: Before First Use

    Press and hold the Tiempo/Tempo sec. The appliance will usable again at the and the Auto Dry buttons simultaneously end of the update, without any notification about successful update. for a few seconds. The indicator appears on the display and the door is If an error occurs, the appliance shows locked.

  • Page 31: Daily Use

    ENGLISH programme dial are deactivated Inicio diferido buttons simultaneously for (except On/Off button ). about 6 seconds. • Before you touch the Inicio/Pausa If you deactivate the button: the appliance cannot start. acoustic signals, they The appliance keeps the selection of this continue operate when the option after you switch it off.
  • Page 32 The display shows the symbol of the set This data is indicative and refers to the option and/or the digit shows the delayed detergent dosage recommended for a time. maximum load on the detergent package. 12.4 Loading the laundry...
  • Page 33 ENGLISH After a washing cycle, if necessary, remove any detergent residue from the detergent dispenser. 12.6 Check the position of the flap 1. Pull out the detergent dispenser until it stops. 2. Press the lever down to remove the dispenser. With the flap in the position DOWN: •...
  • Page 34 12.9 The ProSense System In the display, the indicator of the operating phase starts flashing and the load detection detergent percentage indicator goes off. The programme starts, the door is After touching the Inicio/Pausa button: locked. The display shows the indicator 1.
  • Page 35 ENGLISH 12.11 Interrupting a The programme or the delay start continues. programme and changing the 4. The door can be opened when the options programme is complete. You may also set a spinning or draining When the programme is running, you programme/option and than press can change only some options: Inicio/Pausa button.

  • Page 36: Daily Use - Washing & Drying

    • The display shows the indicator , the In any case, the appliance empties the water out option indicator and the automatically after door locked indicator . The approximately 18 hours. indicator of the running phase flashes. 12.16 Stand-by option •...
  • Page 37 ENGLISH 2. Turn the programme dial to the desired washing programme. The Cupboard dry: for display shows the default cotton and synthetic items; temperature and spin. If necessary, change them according to your laundry. The display also shows the Extra dry: for cotton maximum recommended load for items.

  • Page 38: Daily Use - Drying Only

    1. Remove the laundry from the • In the display comes on. appliance. • The indicator of button Inicio/Pausa 2. Make sure that the drum is empty. goes off. The door locked goes After drying phase, clean the drum, the seal and the inside •...

  • Page 39: Fluff In The Fabrics

    ENGLISH time value (see the "Timed drying" • The indicator of button Inicio/Pausa table the "Programmes" chapter). goes off. The door locked goes The drying level indicator goes off and the indicator comes on. • Press the button On/Off for some The minimum timed drying is 15 minutes.
  • Page 40 • Follow the washing instructions on the laundry care labels. • Do not wash white and coloured items together. • Some coloured items can discolour with the first wash. We recommend that you wash them separately for the first couple of times.
  • Page 41 ENGLISH (60 °C max) for all types of fabric, and check the water hardness of you or special ones for woollens only. domestic system. Refer to 'Water • The choice and quantity of detergent hardness'. will depend on: type of fabric •...

  • Page 42: Care And Cleaning

    16.11 General Tips • = The drying cycle is at high temperature Refer to the «Timed drying» table to find • = The drying cycle is at reduced the average drying times. temperature Experience will help you to dry the laundry better.
  • Page 43 ENGLISH 17.2 Removing foreign Always follow the objects instructions that you find on the packaging of the Make sure that pockets are product. empty and all loose elements are tied up before 17.5 Maintenance wash running your cycle. Refer to "The laundry load"...
  • Page 44 17.7 Cleaning the drum Regularly examine the drum to prevent unwanted deposits. Rust deposits in the drum may occur due to rusting foreign body in the washing or tap water containing iron. Clean the drum with special products for stainless steel.
  • Page 45 ENGLISH 3. Open the primary air filter cover by pulling it upwards. 17.9 Cleaning the air filters The air filters collect the fluff. The fluff normally occurs when the clothes are dried in a washer-dryer. • At the end of each drying cycle in the display the indicator is on to advise 4.
  • Page 46 7. Clean the secondary air filter with WARNING! your hand and, if necessary, with a The primary air filter recess vacuum cleaner. Throw the lint in a must not be blocked by any dustbin. object. If you only wash the laundry...
  • Page 47 ENGLISH Proceed as follows to clean the pump: 6. Repeat the steps 4 and 5 until the water stops to flow out. 1. Open the pump cover. 7. Turn the filter anti-clockwise to remove it. 2. Place a suitable bowl below the drain pump access to collect the water that 8.
  • Page 48 When you drain the water with the emergency drain procedure, you must activate the drain system again: a. Put 2 litres of water in the main wash compartment of the detergent dispenser. b. Start the programme to drain the water.
  • Page 49 ENGLISH • Remove the inlet hose behind the appliance. • Clean the filter in the valve with a stiff brush or a towel. • Install again the inlet hose. Make sure that the couplings are tight to prevent leakages. • Open the water tap.

  • Page 50: Troubleshooting

    WARNING! Make sure that the temperature is higher than 5 °C and the water is flowing from the tap before you use the appliance again. The manufacturer is not responsible for damages caused by low temperatures. 18. TROUBLESHOOTING WARNING! Refer to Safety chapters.
  • Page 51 ENGLISH • Make sure that the water tap is open. • Make sure that the pressure of the water supply is not too low. The appliance does For this information, contact your local water authority. not fill with water prop‐ •...
  • Page 52 Problem Possible solution • Make sure that the mains plug is connected to the mains socket. • Make sure that the appliance door is closed. • Make sure that there is no damaged fuse in the fuse box. The programme does •...
  • Page 53 ENGLISH Problem Possible solution • Check the wireless signal. • Check if your smart device is connected to the wireless net‐ work. • Check your home network and router. The App cannot con‐ • Restart the router. nect to the appliance. •...
  • Page 54 Problem Possible solution The drum is empty and • Press the On/Off button to deactivate the appliance and acti‐ the display shows vate it again to set a tare. there is some weight • You loaded the laundry before activating the appliance. Press The drum is full but the the On/Off button to deactivate the appliance.

  • Page 55: Consumption Values

    ENGLISH 3. Open the filter flap. CAUTION! 4. Pull the emergency unlock trigger Risk of injury! Make sure downward once. Pull it downward that the drum is not once again, keep it tensed and, in the rotating. If necessary, wait meanwhile, open the appliance door.
  • Page 56 Remaining moisture at the end of the cycle. The higher is the spin speed, the higher is the noise and the lower is the remaining moisture at the end of washing cycle. Values and programme duration may differ depending on different conditions (e.g.
  • Page 57 ENGLISH 19.4 Common programmes - Washing only These values are indicative only. Programme Litres hh:mm °C Algod. 10.0 2.900 90.0 04:05 44.00 85.0 1600 95°C Algod. 10.0 1.700 85.0 03:50 44.00 55.0 1600 60°C Algod. 10.0 0.350 85.0 03:00 44.00 20.0 1600 20°C...

  • Page 58: Environmental Concerns

    20. ENVIRONMENTAL CONCERNS appliances marked with the symbol Recycle materials with the symbol with the household waste. Return the Put the packaging in relevant containers product to your local recycling facility or to recycle it. Help protect the contact your municipal office.
  • Page 60 My AEG Care app The software in this product contains components that are based on free and open source software. AEG gratefully acknowledges the contributions of the open software and robotics communities to the development project. To access the source code of these free and open source software components whose license conditions require publishing, and to see their full copyright information and applicable license terms, please visit: http://aeg.opensoftwarerepository.com (folder NIUX)
