TP-Link RE655BE Quick Installation Manual

Quick Installation Guide
Range Extender
* Images may differ from your actual product.
Set Up
Method 1: Via the WPS Button
1. Activate the WPS function on your router by
pressing the WPS button.
Note: If you don't know how to do, refer to your router's
user manual, or you can use other methods to set it up.
The WPS button might
look like one of these:
2. Within 2 minutes, press the WPS button on the
extender for 1 second, and the
blinking. Wait for the LED, 2.4GHz LED, and
5GHz LED to turn solid blue, indicating a
successful connection.
Notes:
1. lf only the 2.4GHz or 5GHz LED is solid blue, check to see
if the router has both 2.4GHz and 5GHz turned on. If both
are turned on, try WPS again or use other methods.
2. WPA3 required for 6 GHz bands does not allow WPS
connection. To connect to a router's 6 GHz band, please
connect via the Tether app or web browser.
Blinking Solid On
3. Done. You can connect to the extender's Wi-Fi.
Extended Network Names:
Router's network name with _EXT at the end
or
Same as your EasyMesh router (see back for EasyMesh
details)
Passwords:
Same as your router
Relocate
1. Plug in the extender about halfway between your router and the Wi-Fi dead zone. The
location you choose must be within the range of your router.
2. Wait for about 2 minutes until the
extender closer to the router to achieve better signal quality.
Tip: To place the extender for optimal Wi-Fi performance, access extender settings via the
Tether app and go to find Location Assistant, or simply scan the QR code to visit
https://www.tp-link.com/support/faq/3103/.
Enjoy!
· Connect your devices to the extender wirelessly or via an Ethernet cable, then enjoy the
internet. The passwords of your extended networks are the same as your main router.
· You can also change the extender to Access Point Mode to transform your existing wired
network to a wireless one. For details, see Access Point Mode (AP Mode) on the back page.
Method 2: Via the Tether App
1. Get the up-to-date Tether app from the Apple App
Store or Google Play, or simply scan the QR code.
2. Launch the Tether app and log in with your TP-Link
ID. If you don't have an account, create one first.
LED starts
3. Tap the
Notes:
1. If you cannot find your device, please refer to FAQ > Q1.
2. Due to Tether app updates, your actual user interface
and pathway may differ from those depicted here.
4. Follow app instructions to complete the setup.
The LED should turn solid on, indicating
successful connection to your router.
Note: If the LED does not turn solid on, please refer
to FAQ > Q2.
LED turns solid blue. If it doesn't, relocate the
Power On
Plug the extender into a power outlet next to your router. Wait until
its Power LED turns solid on after blinking for a while.
Note: For safety, only plug the extender in the direction as shown below.
Router
or
Scan for Tether Tether
button and select Range Extender.
My Devices
No devices found.
Choose Your Device Type
Wireless Router
Gaming Router
Range Extender
Router
Next to
Method 3: Via a Web Browser
1. Connect your computer or smartphone to
the extender's network TP-Link_Extender.
TP-Link_Extender
2. Visit http://www.tplinkrepeater.net or
http://192.168.0.254 in a web browser.
Create a password to log in.
http://www.tplinkrepeater.net
Create Password
Low Middle High
Confirm Password
Start
3. Follow web instructions to complete the setup.
Solid On
Blue: Suitable location
Red: Too far from router
Router Devices
Halfway
Smartphone Tablet
Connect to
2.5Gbps
Ethernet Port
Smart TV Game Console
Solid On
Laptop
Desktop
