- Page 1 BUILT-IN OVEN MINIMAL OB24SMPTDG1, OB24SMPTNG1, OB24SMPTDB1, OB24SMPTNB1, OB24SM16PLG1 & OB24SM16PLB1 CONTEMPORARY OB24SDPTDX2, OB24SD16PLX1 & OB24SD11PLX1 INSTALLATION GUIDE US CA...
-
Page 2: Safety And Warnings
SAFETY AND WARNINGS WARNING! WARNING! To avoid hazard, follow these instructions carefully before installing or using this appliance. Electric Shock Hazard Please make this information available to the person installing the appliance—doing so could Failure to follow this advice may result in reduce your installation costs. -
Page 3: Prior To Installation
PRIOR TO INSTALLATION INSTALLATION MILESTONES Ensure that: Milestone indicator • The countertop and oven cavity are square and level, and are the required dimensions. These milestones represent areas throughout • The installation will comply with all clearance requirements and applicable standards and that are pivotal to an optimal installation regulations. - Page 4 COMPONENTS PARTS TOOLS Supplied Not supplied Screws (2) Metal side shelves Powered driver Cross-head screwdriver fixing nut (2)
-
Page 5: Product Dimensions
PRODUCT DIMENSIONS POWER OUTLET LOCATION Product Dimensions inches a Overall height of oven 23 9/16 B Overall width of oven 23 7/16 c Depth of front frame (excludes dial, handle and front 13/16 stainless trim) DATUM : FRONT OF CHASSIS d Depth of oven chassis and front frame (excludes dial, 22 1/4 handle and front stainless trim) -
Page 6: Cabinetry Dimensions
CABINETRY DIMENSIONS PROUD INSTALL 5/8 -13/16" (16 -20mm) PROFILE PLAN FLUSH INSTALL 5/8 -13/16" (16 -20mm) CABINETRY DIMENSIONS INCHES A Minimum inside width of cavity 22 1/16 B Overall width of cabinetry 23 5/8 C Overall height of cabinetry 23 5/8 D Minimum inside height of cavity 22 13/16 E Minimum inside depth of cavity... - Page 7 CHECK CAVITY UNPACK PRODUCT Do not lift or move the product using the handle. Keep all packing materials until the unit has been inspected. Inspect the product to ensure there is no shipping damage. If any damage is detected contact the dealer or retailer you brought the product from to report the Measure cavity dimensions.
-
Page 8: Connect Power
REMOVE DOOR CONNECT POWER This oven must be connected to the mains power supply only by a suitably qualified person. This oven must be earthed. Open the door and remove all cable ties and packaging holding the oven shelves Before connecting the oven to the mains power supply, check that: in place. - Page 9 CONNECT POWER THREE WIRE CONNECTION If local codes permit connecting the cabinet-grounding conductor to the neutral (white) wire in junction box. Connect the two black wires together with twist-on connectors and the two red wires together with twist-on connectors. Connect the factory-taped gree and white oven wires to the neutral (white) wire in the junction box.
- Page 10 CONNECT POWER FOUR WIRE CONNECTION Seperate the green and white oven cable wires. Connect the white oven cable wire Disconnect the power supply and to the neutral (white) wire in junction remove the junction box cover. box. Connect the green grounding oven Connect the oven cable to the junction cable wire to the (green) grounding box through the U.L - listed confuit...
- Page 11 POSITION OVEN INTO CAVITY REFIT DOOR Some models only*: For dark cabinetry, the supplied trim can Holding the door on both sides, carefully be used to enhance clashing finish. lift door back onto the hinges. To install, remove the trim adhesive and press to secure to cavity.
- Page 12 ALIGN AND SECURE REFIT SHELVES Sliding shelves Place shelves back into the oven at the Align oven with surrounding cabinetry desired level. and appliances. Ensure shelves are level and correctly positioned with the guard rail at the back. Wire shelves Using the product as a guide, pre-drill 2 x 3mm pilot holes.
-
Page 13: Installer Checklist
TEST OVEN INSTALLER CHECKLIST TO BE COMPLETED BY THE INSTALLER Ensure the oven is level and securely fitted to the cabinetry. Follow the guidance on screen to ensure oven turns on and heats correctly. Check the lower trim is undamaged. Refer to your User Guide for more information. - Page 14 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2023. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
