- Page 1 Dishwasher User Manual Geschirrspüler Benutzerinformation LVS345CQSX...
-
Page 2: Table Of Contents
The information can be found on the rating plate. Warning / Caution-Safety information General information and tips Environmental information VISIT OUR WEBSITE: To get usage advice, brochures, trouble shooter, service and repair information: www.smeg.com/services/customer-service CONTENTS 1. SAFETY INFORMATION...................2 2. SAFETY INSTRUCTIONS.................4 3. INSTALLATION....................6 4. PRODUCT DESCRIPTION................6 5. - Page 3 1.1 Children and vulnerable people safety This appliance can be used by children aged from 8 years • and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
-
Page 4: Safety Instructions
If the supply cord is damaged, it must be replaced by the • manufacturer, its Authorised Service Centre or similarly qualified persons in order to avoid a hazard. WARNING: Knives and other utensils with sharp points • must be loaded in the basket with their points down or placed in a horizontal position. - Page 5 • Ensure that there are no visible water • Please note that self-repair or non- leaks during and after the first use of the professional repair can have safety appliance. consequences and might void the • If the water inlet hose is damaged, guarantee.
-
Page 6: Installation
3. INSTALLATION Valid only for Germany: Before installation, WARNING! refer to the chapter "Rückschlagventil" in the German user manual. Refer to Safety chapters before installation. For detailed installation information, see the installation instruction supplied with the appliance. 4. PRODUCT DESCRIPTION Worktop Air vent Ceiling spray arm... -
Page 7: Control Panel
5. CONTROL PANEL On/off button Option touch button Program touch button Indicators Programme indicators Start touch button Display Delay touch button 5.1 Indicators Indicator Description Salt indicator. It is on when the salt container needs refilling. It is always off while the pro‐ gramme operates. -
Page 8: Programmes
Indicator Description Extreme indicator. Sterilise indicator. 6. PROGRAMMES The order of the programmes in the table may not reflect their sequence on the control panel. Programme Dishwash‐ Degree of Programme phases Options er load soil Crockery, cut‐ Normal, • Prewash •... - Page 9 Programme Dishwash‐ Degree of Programme phases Options er load soil Crockery, cut‐ • Prewash lery, pots, • Dishwashing 50 - 60 °C Auto pans • Intermediate rinse • Final rinse 60 °C • Drying • Dry Assist None Cleaning • Cleaning 70 °C the appli‐...
-
Page 10: Options
Water (l) Energy (kWh) Duration (min) Programme 1)2) 0.010 The pressure and the temperature of the water, the variations of the mains supply, the options, the quantity of dishes and the degree of soil can change the values. The values for programmes other than ECO are indicative only. 6.2 Information for test institutes To receive the necessary information for conducting performance tests (e.g. -
Page 11: Settings
8. SETTINGS 8.1 Programme selection mode and How to enter user mode user mode Make sure the appliance is in programme When the appliance is in programme selection mode. selection mode, you can set a programme To enter user mode, press and hold and enter user mode. - Page 12 German French de‐ mmol/l mg/l (ppm) Clarke Water soften‐ degrees grees (°fH) degrees er level (°dH) 11 - 14 19 - 25 1.9 - 2.5 185 - 254 13 - 17 4 - 10 7 - 18 0.7 - 1.8 70 - 184 5 - 12 <4...
- Page 13 • The remaining indicators are off. • The display shows the current setting: e.g. = level 5. 2. Press Program repeatedly to change the setting. 3. Press the on/off button to confirm the setting. 8.3 The rinse aid level The rinse aid helps to dry the dishes without streaks and stains.
-
Page 14: Before First Use
9. BEFORE FIRST USE 1. Make sure that the current level of the 5. Remove the salt around the opening of water softener agrees with the the salt container. hardness of the water supply. If not, adjust the level of the water softener. 2. -
Page 15: Daily Use
1. Open the lid (C). 4. Close the lid. Make sure that the lid locks 2. Fill the dispenser (B) until the rinse aid into position. reaches the marking ''MAX''. 3. Remove the spilled rinse aid with an Fill the rinse aid dispenser when the absorbent cloth to prevent excessive indicator (A) is clear. -
Page 16: Hints And Tips
1. Open the appliance door. • The indicator is on. 2. Press simultaneously Delay and Option • The remaining time counts down in until the appliance is in programme hours. The final hour is displayed in selection mode. minutes. When the countdown is completed, the Cancelling the programme programme starts and the indicator of the 1. - Page 17 • Make sure that items in the baskets do not much rinse aid results in bluish layers on touch or cover each other. Only then can the items. the water completely reach and wash the • Make sure that the water softener level is dishes.
-
Page 18: Care And Cleaning
11.6 Unloading the baskets • The filters are clean and correctly installed. 1. Let the tableware cool down before you • The cap of the salt container is tight. remove it from the appliance. Hot items • The spray arms are not clogged. can be easily damaged. - Page 19 5. Make sure that there are no residues of food or soil in or around the edge of the 1. Turn the filter (B) counterclockwise and sump. remove it. 6. Put back in place the flat filter (A). Make sure that it is correctly positioned under the 2 guides.
- Page 20 CAUTION! An incorrect position of the filters can cause bad washing results and damage to the appliance. 12.5 Cleaning the lower spray arm We recommend to clean the lower spray arm regularly to prevent soil from clogging the holes. Clogged holes can cause unsatisfactory washing results.
- Page 21 turn it counterclockwise until it locks into 2. Move the upper basket to the lowest level place. to reach the spray arm more easily. 3. To detach the spray arm (C) from the delivery tube (A), turn the mounting element (B) counterclockwise and pull the spray arm downwards.
-
Page 22: Troubleshooting
13. TROUBLESHOOTING Refer to the below table for information on WARNING! possible problems. With some problems, the display shows an Improper repair of the appliance may alarm code. pose a danger to the safety of the user. Any repairs must be performed by qualified personnel. - Page 23 Problem and alarm code Possible cause and solution The temperature of the water in‐ • Make sure that the temperature of the inlet water does not exceed side the appliance is too high or 60°C. malfunction of the temperature • Switch the appliance off and on.
- Page 24 WARNING! Refer to "Before first use", "Daily use", or "Hints and tips" for other We do not recommend using the possible causes. appliance until the problem has been completely fixed. Unplug the appliance Once you have checked the appliance, and do not plug it in again until you are deactivate and activate the appliance.
-
Page 25: Technical Information
Problem Possible cause and solution Traces of rust on cutlery. • There is too much salt in the water used for washing. Refer to "The water softener" • Silver and stainless steel cutlery were placed together. Do not place silver and stainless steel items close together. There are residues of detergent in •... -
Page 26: Environmental Concerns
Voltage (V) 220 - 240 Electrical connection Frequency (Hz) Water supply pressure Min. / max. MPa (bar) 0.05 (0.5) / 1 (10) Water supply min. 5 - max. 60 °C Cold water or hot water Capacity Place settings Refer to the rating plate for other values. If the hot water comes from alternative source of energy (e.g. - Page 30 117834131-A-472023...
