Dometic DA20E Installation Instructions Manual

(220v-240v ~, 50 hz) electric cassette awning
Hide thumbs

Advertisement

Quick Links

Download this manual
USA
SERVICE OFFICE
Dometic, LLC
2320 Industrial Parkway
Elkhart, IN 46516
574-294-2511
CANADA
Dometic, LLC
46 Zatonski, Unit 3
Brantford, ON N3T 5L8
CANADA
519-720-9578
For Service Center
Assistance Call:
800-544-4881
INSTALLATION
INSTRUCTIONS
3313971.057
REVISION
Form No. 3313971.057 08/11
(Replaces 3313971.040)
©2011 Dometic, LLC
LaGrange, IN 46761
This manual must be read and
understood before installation,
adjustment, service, or mainte-
nance is performed. This unit must
be installed by a qualified service
technician. Modification of this
product can be extremely hazard-
ous and could result in personal
injury or property damage.
These Instructions must stay with unit. Owner
read carefully.
TYPE DA20E
(220V-240V ~, 50 HZ)
ELECTRIC
CASSETTE AWNING
Lire et comprendre ce manuel avant de
procéder à l'installation, à des réglages,
de l'entretien ou des réparations.
L'installation de ce produit doit être
effectuée par un réparateur qualifié.
Toute modification de ce produit peut
être extrêmement dangereuse et
entraîner des blessures ou dommages
matériels.
RECORD THIS INFORMATION FOR FUTURE
REFERENCE:
Model Number
Serial Number
Date Purchased
Retailer / Qualified Installer
AVERTISSEMENT
!
MODEL
203(XX)(XX).000(#)

Advertisement

loading

Related Manuals for Dometic DA20E

Summary of Contents for Dometic DA20E

  • Page 1 RECORD THIS INFORMATION FOR FUTURE REFERENCE: Model Number Serial Number Date Purchased Retailer / Qualified Installer TYPE DA20E (220V-240V ~, 50 HZ) ELECTRIC SERVICE OFFICE Dometic, LLC CASSETTE AWNING 2320 Industrial Parkway Elkhart, IN 46516 574-294-2511 CANADA Dometic, LLC 46 Zatonski, Unit 3...

  • Page 2: Important Safety Instructions

    This hardware must be installed by a Dometic, LLC Service Center or a qualified service tech- RECOGNIZE SAFETY INFORMATION nician. Incorrect installation can lead to se- vere injury.

  • Page 3: Specifications

    B. Specifications IMPACT OR CRUSH HAZARD. Make sure mounting bolts are located behind each ELECTRICAL SHOCK HAZARD. Installer must shoulder assembly (lateral arm attachment) provide proper earthing for equipment. Fail- to provide proper support. Otherwise, the cas- ure to obey this warning could result in death, sette awning may become unstable and could serious injury, or property damage.
  • Page 4 PROCEDURE c. Find a solid structure in RV wall for support of mounting bracket (if possible). See FIG. 3. A. Install Cassette Awning Important: A backing plate and sleeves (provided) are needed inside RV wall to strengthen awning sup- port. See FIG. 4. Note: The 10.3 mm O.D.
  • Page 5 Mounting bracket must be installed on a flat IMPACT OR CRUSH HAZARD. Do not over- surface, and leveled to ensure proper function tighten fasteners. Applying too much torque and appearance. may cause fasteners to fail, and could allow awning to collapse. Failure to obey this warn- 2.
  • Page 6 Do not allow wiring to rub against sharp edges. If supply wiring is damaged, it must 12. With the help of additional personnel, hook aw- be replaced by a Dometic, LLC Service Center ning onto mounting bracket. See FIG. 10. or a qualified service technician.
  • Page 7 B. Verify Motor And Remote Functionality 1. With power applied to awning, press the open IMPACT OR CRUSH HAZARD. Do not operate button (down arrow) briefly on awning remote. Awning should extend to its out limit. See or leave awning unattended until it is securely FIG.
  • Page 8 8 seconds (to simulate wind vibra- Any adjustment of this hardware must be per- tion). Awning should retract until it’s closed. See formed by a Dometic, LLC Service Center or FIG. 15. Note: If awning does not close, install new batteries in wind a qualified service technician only.
  • Page 9 2. Remove power from awning. PINCH POINT HAZARD. Keep clear of pivot area when raising or lowering lateral arm assembly. Failure to obey this caution could result in injury. PINCH HAZARD. Make sure power is removed 6. Pivot the lateral arm assembly down (rotate shoul- from awning before working near lateral arm der in shoulder base to lower lead rail) until shoul- assemblies.
  • Page 10 E. Readjust Lateral Arm Assemblies (If 2. Remove power from awning. Required) Do not allow lateral arm assemblies to rub PINCH HAZARD. Make sure power is removed against lower lip of back rail when closing, from awning before working near lateral arm or against awning fabric when fully opened.
  • Page 11 Examine installation for imbalance, or signs of wear or damage to cables and other criti- cal parts. Any adjustments or repairs must be performed by a Dometic, LLC Service Center or a qualified service technician. 1. Operate awning according to the Operating In- structions to verify all parts are functioning prop- erly.
