20"
W32001 LCD TV
QUICK
CONNECT
G U I D E
CONGRATULATIONS on pur-
chasing a state of the art LCD
TV! This Quick Connect Guide
will help you get started in 3
easy steps. On the back you will
find information to maximize
your LCD TV experience. For
complete installation, usage
instructions, and safety precau-
tions please refer to the User
Guide.
Westinghouse Digital Electronics
KEYPAD
1
CONNECT THE
CONNECT THE
POWER
TUNER
Remove the dust cover for
Connect either analog cable
the connection panel on the
or TV antenna wire to the
back of the LCD. Use the
cable ready NTSC tuner input
enclosed A/C power cable
labeled "TV" on the connec-
to connect A/C power to the
tion panel.
power adapter kit. Insert the
smaller end of the adapter
Note: this step can be
cord into the DC 12V input
skipped if you do not use
on the connection panel.
these options.
The power indicator on the
front of the LCD glows
orange.
POWER INDICATOR
REMOVABLE STAND FOR OPTIONAL WALL MOUNTING
2
CONNECT A DVD
PLAYER
Connect a DVD player to the
component YPbPr input (Red,
Green, Blue) and the corre-
sponding component audio
inputs labeled "Audio In 2"
located on the connection
panel.
CONNECTION PANEL
3
GO!
Press Power on the key-
pad to turn on the LCD.
The power indicator on
the front panel of the LCD
glows green.
www.westinghousedigital.com
