Westinghouse LTV-20v4 Quick Connect Manual

20"
LTV-20v4 LCD TV
QUICK
CONNECT
G U I D E
CONGRATULATIONS on pur-
chasing a Westinghouse LCD
TV! This Quick Connect Guide
will help you get started in 3
easy steps. On the back you
will find information to maxi-
mize your LCD TV experience.
For complete installation,
usage instructions, and safety
precautions please refer to
the User's Manual.
Westinghouse Digital Electronics
Keypad
1 1
CONNECT THE CONNECT THE
POWER TUNER
Use the enclosed AC Connect either cable or
power cable to connect TV antenna wire to the
to a power outlet. cable ready NTSC tuner
input labeled "ANT" on the
connection panel.
Note: This step can be skipped if
you do not use these options.
Refer to the table on the back for
connection to satellite set top
box or digital cable.
Power Button
2 2
CONNECT A DVD
PLAYER
Connect a DVD player
to the component YPbPr
input (Red, Green, blue)
and the corresponding
component audio inputs.
Video 1 (S-Video 1)/
Video 2 (S-Video 2)/YPbPr/ANT Inputs
GO! GO!
3 3
Press the Power button
to turn on the LCD TV.
w w w . w es t i nghous edi gi t al . com
