USER'S MANUAL
MANUEL DE L'UTILISATEUR
MANUAL DEL USUARIO
LCM-19v7
LCD Monitor
Moniteur LCD
Monitor LCD

   Also See for Westinghouse LCM-19v7

   Related Manuals for Westinghouse LCM-19v7

   Summary of Contents for Westinghouse LCM-19v7

  • Page 1

    USER’S MANUAL MANUEL DE L’UTILISATEUR MANUAL DEL USUARIO LCM-19v7 LCD Monitor Moniteur LCD Monitor LCD...

  • Page 2: Table Of Contents

    Distorted Image ... 20 Image is Not Centered (size is not scaled correctly)... 21 Colors are Not Correct ... 21 No Sound... 21 Mounting the LCD Monitor on a Wall ... 21 Additional Questions... 21 Table of Contents ... 6 ...

  • Page 3: Important Product Safety Instructions

    LCD Monitor and to protect it from overheating, these openings must not be blocked or covered. • Do not block the openings by placing the LCD Monitor on a bed, sofa, rug or other similar surface. • Do not place the LCD Monitor in a built-in installation such as a bookcase or rack unless proper ventilation is provided and the manufacturer’s instruction have been...

  • Page 4: S Afety G Uidelines

    IMPORTANT NOTICE CONCERNING POWER CORD SELECTION The specific power cord for this LCD Monitor is enclosed and has been selected according to the country of destination and must be used to prevent electric shock. Use the following guidelines if it is necessary to replace the original cord set, or if the cord set is not enclosed.

  • Page 5: C Leaning The Lcd M Onitor

    Westinghouse Digital does not recommend the use of any ammonia or alcohol-based cleaners on the LCD Monitor screen or case. Some chemical cleaners have been reported to damage the screen and/or LCD Monitor case. Westinghouse Digital will not be liable for damage resulting from the use of any ammonia or alcohol-based cleaners.

  • Page 6: Features, Plug & Play

    A power control system, Power Saver, is installed inside the LCD monitor. If the LCD monitor has not been used for a certain period of time, the system will turn the LCD monitor to low voltage mode to save electrical power.

  • Page 7: Installation, P Ackage C Ontents

    INSTALLATION Congratulations on your purchase of a Westinghouse 19” LCD Monitor. Sleek and practical, this lightweight and wall-mountable LCD monitor delivers a crisp and clear display optimized for 1280 x 1024 display resolution. Package Contents Your product package includes: • 19” Westinghouse LCD Monitor •...

  • Page 8: Front View Of The Lcd Monitor

    Front View of the LCD Monitor Use the buttons on the front of the LCD Monitor to display the On Screen Display (OSD). The OSD controls are defined in “OSD Functions” on page 11. • Switch between picture, text and economy modes.

  • Page 9: Rear View Of The Lcd Monitor

    Rear View of the LCD Monitor 1. AC IN (Power) 2. Audio-IN 3. DVI-D 4. D-SUB (VGA) 5. Lock Hole • Connect the power cord from AC IN to a power source. • Using the cable provided, connect to the Audio out (Green) from a computer.

  • Page 10: C Onnect Audio And Video Cables To A Pc

    1. Attaching the Base Stand to the LCD Monitor Attach the base stand to the LCD monitor stand neck. Align the holes and tabs; press in and snap into place. To remove the base stand, press the tabs on the bottom of the stand neck and remove the base.

  • Page 11: Connect Power Cable, Turn The Power On

    AC outlet. Turn the Power On Press the power button on the front of the LCD monitor. The LED light will turn blue if a signal input is detected or it will be orange if no input is detected.

  • Page 12: M Ounting The Monitor On A W All

    2. Remove the plastic covers and screws to remove the LCD monitor stand neck. 3. Use the 100mm VESA hole pattern on the back of the monitor to secure a Westinghouse Décor Wall Mount to the monitor and mount it on a wall.

  • Page 13: Osd Menu Functions

    OSD Menu Functions All the function settings for the LCD monitor are controlled via the control keys located on the bottom part of the front panel. To display the OSD main menu, press the “Menu” keypad button on the control keys. (Note: The OSD menu display will disappear automatically after approximately 10 seconds, if no action is taken.)

  • Page 14: Image Menu

    Adjust the contrast of the image. Contrast Adjust the picture sharpness of low resolution pictures. Sharpness Adjust the LCD monitor clock. (Optional) Clock Adjust the LCD monitor phase. (Optional) Phase Move the image left or right on the screen. (Optional) H.

  • Page 15: Audio Menu

    Audio Menu Function Adjust the volume of the audio. Volume Disable the audio. Mute Description...

  • Page 16: Color Menu

    Color Menu Function User/9300K/7500K/6500K/sRGB Color temp Adjust red color. Adjust green color. Green Adjust blue color. Blue Description...

  • Page 17: Misc Menu

    OSD time-out Adjust OSD display time setting. Move OSD display position to any one of the following 5 OSD position positions within the overall screen. Restore LCD monitor to factory settings. Reset Analog / Digital Input Select Adjust clock, phase and positions automatically. (Optional) Auto setting Color Management Engine.

  • Page 18: Info Menu

    Info Menu Function Displays resolution. Resolution Horizontal Displays horizontal frequency. frequency Vertical Displays vertical frequency. frequency Description...

  • Page 19: Q Uick A Djustments

    Quick Adjustments You can skip the Menu pages and display an adjustment scale directly by using the following button operations: • Brightness: Press the Brightness button when the Menu is not displayed. • Contrast: Press the Contrast button when the Menu is not displayed. •...

  • Page 20: Display Modes

    Display Modes The monitor backlighting can be controlled by using the Turbo button on the control keypad. There are 3 modes: Economy, Text, and Picture. To toggle between these modes, press the Turbo key until the mode you desire is selected. These modes automatically change the backlighting levels between bright, brighter, and brightest.

  • Page 21: Appendix, S Pecifications

    Appendix Specifications Item Type Panel Size Optimum Resolution Response Time Contrast Ratio Maximum Brightness Viewing Angles Physical Wall/Arm Mount Video Input Signal Audio Speaker Output Voltage Power Operating Conditions Temperature Humidity Altitude Temperature Storage Conditions Humidity Altitude Unit Dimensions Carton Unit Weight Regulations...

  • Page 22: T Roubleshooting, No Power, No Image, Power Is On But No Screen Image

    Troubleshooting No Power • Make sure the DC cord is plugged into the back of the LCD monitor. • Make sure the AC power cord is securely connected to the AC socket. • Plug another electrical device (like a radio) to the power outlet to verify that the outlet is supplying the proper voltage.

  • Page 23: Image Is Not Centered (size Is Not Scaled Correctly), Colors Are Not Correct, No Sound

    • Use the 100mm VESA hole pattern to secure a mounting plate to the LCD monitor. • Use professional installation to reduce the risk of injury and damage. Additional Questions • See our website at www.westinghousedigital.com. • Contact Westinghouse Digital Customer Service at (866) 287-5555 or write us at service@westinghousedigital.com.

  • Page 24

    Westinghouse Digital Electronics SE-UM-1905-0601 Santa Fe Springs, CA...
