ABB MEASUREMENT & ANALYTICS | USER MANUAL
TM
User Manual | OA-ICOS
GLA151 Series QC Portable Analyzers

Advertisement

Table of Contents
loading

Summary of Contents for ABB OA-ICOS GLA151 Series

  • Page 1 — ABB MEASUREMENT & ANALYTICS | USER MANUAL User Manual | OA-ICOS GLA151 Series QC Portable Analyzers...
  • Page 2: Table Of Contents

    Warning Labels and Descriptions .................... 20 Analyzer Setup ..........................21 Connect the Power Cords ......................21 Connect the Data Interface Connections ..................21 Connect the Inlet/Outlet Plumbing Connections ................21 Initialize and Run the Analyzer ..................... 22 File System Integrity Check ...................... 23 ABB GLA151 Series QC Portable User Manual...
  • Page 3 Appendix B: Wireless Router Setup (Optional) ................65 Appendix C: Set Up Devices for Remote Access Using VNC Software ........70 Appendix D: Mirror Cleaning Procedure ..................83 Appendix E: Cables ..........................97 ABB GLA151 Series QC Portable User Manual...
  • Page 4: Disclaimer

    ABB and its affiliates are not liable for damages and/or losses related to such security breaches, any unauthorized access, interference, intrusion, leakage and/or theft of data or information.
  • Page 5: Safety

    The product must be disposed of at a specialized recycling facility. Do not use municipal garbage collection points. According to the WEEE Directive 2002/96/EC, only products used in private applications may be disposed of at municipal garbage facilities. ABB GLA151 Series QC Portable User Manual...
  • Page 6: Labels

    Electrical Hazards The analyzer poses no electrical hazards. The analyzer components operate at ≤ 6.8 V DC. ABB GLA151 Series QC Portable User Manual...
  • Page 7: Laser Hazards

    Only trained service personnel are authorized to open the housing or service the laser. Using this analyzer in a manner not specified by ABB-LGR may result in damage to the analyzer and render it unsafe to operate. Only authorized persons may open the analyzer cover or perform internal maintenance.
  • Page 8: Text Formats And Warning Icons

    General Warning Icon: gives general safety information that must be followed to avoid hazardous conditions. WARNING! Electrical Warning Icon: warns of potential electrical shock hazard. WARNING! Laser Warning Icon: warns of potential laser hazard. WARNING! ABB GLA151 Series QC Portable User Manual...
  • Page 9: Transportation And Storage Of Boxed Analyzers

    Save the original shipping materials to use when returning the analyzer to ABB-LGR if factory service or repair is needed. Table 3 lists and describes the safety icons on ABB-LGR shipping boxes. Follow these instructions when transporting and storing boxed analyzers.
  • Page 10: Warranty

    5. No-charge repair parts may be sent at ABB-LGR’s sole discretion to the purchaser for installation by purchaser. 6. ABB-LGR’s liability is limited to repair or replace any part of the analyzer free of charge if ABB-LGR’s examination discloses the part to be defective.
  • Page 11: Customer Support

    • The company-issued RMA number must be prominently displayed on the return package. No returns will be accepted collect or C.O.D. On all warranty returns, ABB-LGR will pay the shipping charges on the return of the merchandise to the customer.
  • Page 12: Analyzer Overview

    Cable Plugs and Voltage for EC Countries See page 97. • Always use the power supply cord provided by ABB-LGR. See page 97 for a description of power cords for a specific country. ABB GLA151 Series QC Portable User Manual...
  • Page 13: External Dimensions

    External Dimensions 18.5” W x 14” D x 7” H • Weight 15 kg • Cell Volume 345 cc cavity • 10 cc tubing • Total volume = 355 cc • ABB GLA151 Series QC Portable User Manual...
  • Page 14: Standard Components

    Replacement fuses, in-line filters, side covers (915-9300-0000) • Secondary AC-DC power supply (ACC-UP-AC) • This analyzer has been CE certified using data cables three meters long or less. Connecting the analyzer using longer data-cables is not recommended. ABB GLA151 Series QC Portable User Manual...
  • Page 15 If any of these failures occur, you will need a mouse, keyboard and monitor to restart the analyzer. A back up hard drive is recommended. If you have not received all of these components, contact ABB-LGR at icos.support@ca.abb.com. ABB GLA151 Series QC Portable User Manual...
  • Page 16 Figure 2 shows the left side of the analyzer. Figure 2: Left Panel Figure 3 shows the right side of the analyzer. Figure 3: Right Panel ABB GLA151 Series QC Portable User Manual...
  • Page 17: Power Connections

    Turn off the analyzer using the left side panel on/off switch. (Figure 2) 2. Unplug the power cord from the analyzer. (Figure 4) 3. Notify trained service personnel that the analyzer needs repair or servicing. ABB GLA151 Series QC Portable User Manual...
  • Page 18: Data Interface Connection Ports

    If this output is connected to an external device, it must be terminated into a moderate to high impedance (>1 kOhm). MIU port (25-pin data port) – For connecting to a Multiport Inlet Unit (optional). • Figure 5: Data Interface Connection Ports ABB GLA151 Series QC Portable User Manual...
  • Page 19: Gas Inlet/Outlet Connections

    The acceptable inlet gas pressure range is 0 to 10 psig. • The ¼” push-connect WASTE port may be: Routed to the facility ventilation system, or • Remain open, expelling non-hazardous gas into the room air. • Figure 6: Gas Inlet/Outlets ABB GLA151 Series QC Portable User Manual...
  • Page 20: Warning Labels And Descriptions

    Description The laser is rated Class 3 (invisible laser radiation) when the housing is open. Only trained maintenance personnel may open the analyzer housing. General laser warning label. Figure 7: Warning Label Locations ABB GLA151 Series QC Portable User Manual...
  • Page 21: Analyzer Setup

    ¼” push connect INLET port on the right panel of the analyzer. (Figure 8) Figure 8: Portable Analyzer External In-Line Filter To disconnect, push the outer ring around the Inlet and Waste ports to release the 1/4” tubing. ABB GLA151 Series QC Portable User Manual...
  • Page 22: Initialize And Run The Analyzer

    Main Panel Numeric display. (Figure 17) 3. Click on the maintenance SERVICE button (Figure 11) if you need more time or need to choose a maintenance setting. (Figure 12) Figure 9: Start-up Screen in Busy Mode ABB GLA151 Series QC Portable User Manual...
  • Page 23: File System Integrity Check

    Figure 10: File System Integrity Check Screen Thermal Stabilization Run the analyzer for four hours before collecting data. This allows the internal temperature to stabilize. The exact final cell temperature will be analyzer specific (~25°C). ABB GLA151 Series QC Portable User Manual...
  • Page 24: The Launch Service Screen

    GLA151-N2OM1 button displays N2O-CH4. (Figure 11) Open the auto launch window by clicking Service. • Turn off the analyzer by clicking Shutdown. • Figure 11 shows the Launch Service screen. Figure 11: Launch Service Screen ABB GLA151 Series QC Portable User Manual...
  • Page 25: The Auto Launch Screen

    Transfer files from the internal hard drive to an external storage device connected • via USB by clicking Files. Restore the analyzer’s factory settings by clicking Restore. • Figure 12 shows the Auto Launch screen. Figure 12: Auto Launch Screen ABB GLA151 Series QC Portable User Manual...
  • Page 26: Login To Access Menu Options

    If you change and forget this password, you will not be able to recover it without a factory restore. There is only one Linux account. Figure 14: Login Dialog Box 3. Click Login. ABB GLA151 Series QC Portable User Manual...
  • Page 27: Main Panel

    Refer to the Alarm Status Display section on pages 31 - 33 for detailed Temperature Status and Analyzer Status descriptions. This panel contains the User Interface Control Bar (Figure 16) and Numeric Display. (Figure 17) Figure 15: Main Panel ABB GLA151 Series QC Portable User Manual...
  • Page 28: User Interface Control Bar

    User Interface Control Bar Use the control bar to operate the analyzer. Figure 16: User Interface Control Bar ABB GLA151 Series QC Portable User Manual...
  • Page 29 Disk Space – Remaining hard-drive space • Files – Allows easy transfer of files onto USB storage devices. Setup – Accesses additional configuration and service menus. Exit – Exits the application and shuts down the analyzer. ABB GLA151 Series QC Portable User Manual...
  • Page 30: Main Panel Displays

    Figure 17 shows an example of the Numeric Display screen for the GLA151-N2OM1. It displays the numeric readout of the last measurements of gas at a specific concentration. Concentrations vary depending on the type of analyzer. Figure 17: Numeric Display ABB GLA151 Series QC Portable User Manual...
  • Page 31: Alarm Status Display

    Yellow: The data may not reliable, or maintenance is required soon. • : The analyzer requires maintenance to correct an identified fault. • Figure 18 shows the Alarm Status Display with all parameters functioning properly. Figure 18: Alarm Status ABB GLA151 Series QC Portable User Manual...
  • Page 32 The temperature is < the low warning Analyzer Temp Warning set point. Occurs when there is a false or Fault NaN reading undefined value. (NaN= not a number) Dead Band Acceptable Range No warning/alarm No warning/alarm If the Alarm Status is Yellow or Red, please refer to the Maintenance section on page 59. If issue continues, please contact icos.support@ca.abb.com. ABB GLA151 Series QC Portable User Manual...
  • Page 33 (A/B) Fit is not optimal values. Occurs when the specified operational pressure is Pressure Noisy not optimal. Occurs when the internal hard drive has < 20% HD Space Low space space left. Delete unnecessary data files. Mirrors have Mirror Health declined in Occurs when the ringdown time has degraded by > (A/B) reflectivity 10% of the factory value. Occurs when linelock control voltage is approaching Linelock (A/B) Peak is drifting control range limit. Signal Power Signal power is Occurs when laser signal power has degraded by > (A/B) degrading 10% of the factory value. Maintenance Analyzer maintenance will be needed soon (every Maintenance needed soon 360 days). ABB GLA151 Series QC Portable User Manual...
  • Page 34 Dead Band Performance No warning/alarm No warning/alarm If the Alarm Status is Yellow or Red, please refer to the Maintenance section on page 59. If issue continues, please contact icos.support@ca.abb.com. ABB GLA151 Series QC Portable User Manual...
  • Page 35: Spectrum Display

    The measured N O concentration is shown in parts per billion (ppb), and CH and H O in parts per million (ppm) on the bottom of the Spectrum Display . Figure 19: Spectrum Display (GLA151-N2OM1) ABB GLA151 Series QC Portable User Manual...
  • Page 36 The measured N O and CO concentrations are shown in parts per billion (ppb) and H O in parts per million (ppm) on the bottom of the Spectrum Display . Figure 20: Spectrum Display (GLA151-N2OCM) ABB GLA151 Series QC Portable User Manual...
  • Page 37: Timechart Display

    Click on the drop-down box in the lower-right corner of either window to toggle between available gases, and to adjust the number of significant figures. The data is saved to the file indicated in the left corner of the parameter window . Figure 21: TimeChart Display ABB GLA151 Series QC Portable User Manual...
  • Page 38: Rate Control

    The Data Rate Control Adjustment panel appears. (Figure 22) 2. Click the Operating Mode radio buttons to select the rate at which data is acquired. a. Slow-flow mode i. The internal pump is powered on. 3. Click Save. ABB GLA151 Series QC Portable User Manual...
  • Page 39 Main Panel display. a. For example, if you set the value to 5, a data point will be saved every 5 seconds. 4. Click Save. The analyzer restarts sampling at whatever rate was set last. ABB GLA151 Series QC Portable User Manual...
  • Page 40: File Transfer Menu

    At speeds slower than 1 Hz, the standard error of the average is reported. • At the end of each data file are encoded listings of settings used by the analyzer for • that data file. Settings are typically stored for diagnostic or troubleshooting purposes. ABB GLA151 Series QC Portable User Manual...
  • Page 41: Transfer Data Files

    The directory windows default to the local hard drive on the left screen and the USB memory device on the right. Navigate through folders, create new folders, and delete files and folders. USB drives should be no larger than 8GB. They must be FAT32 formatted. ABB GLA151 Series QC Portable User Manual...
  • Page 42 Wait for the Safe to Remove USB Memory Device message before removing the USB memory device. 6. Click Close to exit the File Transfer Menu . Removing the USB memory device before seeing the Safe to Remove pop-up message may result in loss of data. ABB GLA151 Series QC Portable User Manual...
  • Page 43: Types Of Directories In The Local Hard Drive

    (Figure 25) Each file is a single zipped .txt file, using the following convention: XXX_YYYY-MM-DD_f0000.txt.zip. Examples of files in the daily directory are shown in Figure 25. Figure 25: Daily Directory ABB GLA151 Series QC Portable User Manual...
  • Page 44: Archive Directory

    Each file is a single zipped .txt file, using the following convention: YYYY-MM-DD.zip. Each zipped file contains the data files for the day that the analyzer operated. Examples of files in the archive directory are shown in Figure 26. Figure 26: Archive Directory ABB GLA151 Series QC Portable User Manual...
  • Page 45: File Transfer Error Screen

    The File Transfer Error screen (Figure 27) displays when: The USB Key does not have enough storage space. • The device is not recognized. • Try again with a correctly inserted USB device. Figure 27: File Transfer Error ABB GLA151 Series QC Portable User Manual...
  • Page 46: Setup Menu

    Click the Setup button on the User Interface Control Bar . (Figure 28) Figure 28: Setup button on the User Interface Control Bar 2. The default Time/Files screen is displayed. (Figure 29) Figure 29: Setup Menu Tabs with Time/Files Screen Selected ABB GLA151 Series QC Portable User Manual...
  • Page 47: Time/Files Tab

    Time/Files Tab The Time/Files menu allows you to adjust the time zone, manually set the clock, adjust the format of data files, and adjust the Serial Configuration. Figure 30: Functions of the Time/Files Menu ABB GLA151 Series QC Portable User Manual...
  • Page 48 Absolute Local American mm/dd/yyyy, hh:mm:ss.sss Absolute Local European dd/mm/yyyy, hh:mm:ss.sss Absolute GMT American mm/dd/yyyy, hh:mm:ss.sss Absolute GMT European dd/mm/yyyy, hh:mm:ss.sss Relative Seconds After Power On ssssss.sss Relative Seconds in Hours, Minutes, hh:mm:ss.sss Seconds ABB GLA151 Series QC Portable User Manual...
  • Page 49 About The About section displays analyzer specific information, such as the: Build Date of the current software • Version of the code • IP Address • Serial Number of the analyzer • ABB GLA151 Series QC Portable User Manual...
  • Page 50: Calibration Tab

    Calibration Tab ABB-LGR recommends periodic referencing rather than calibration to ensure measurement accuracy and consistency. When calibration is necessary, follow the procedure detailed below. Calibration Procedure: Click the Setup button on the User Interface Control Bar . (Figure 16) 2. Select the Calibration tab at the top of the screen to enter the Calibration menu.
  • Page 51 11. Repeat steps 1-10 for each gas you wish to calibrate. The time of latest calibration is stored in Reference Gas Settings within the Calibration menu for future reference. ABB GLA151 Series QC Portable User Manual...
  • Page 52: Laser Adjust Tab

    The analyzer is operated outside the recommended temperature range. • Figure 33 shows the offset between absorption peaks and target lines. Figure 33: Absorption peaks off of target lines. Laser voltage adjustment needed. ABB GLA151 Series QC Portable User Manual...
  • Page 53 6. Click Close to exit the menu and return to the Main Panel . Figure 34 shows the laser voltage adjusted so that the absorption peaks are centered on the target lines. Figure 34: Absorption Peaks Centered Correctly on Target Lines ABB GLA151 Series QC Portable User Manual...
  • Page 54: Miu Tab

    MIU tab The (optional) Multi-Port Inlet Unit (MIU-8 or MIU-16) is an ABB-LGR accessory that allows automated control of 8 or 16 inlet ports (depending on the ordered configuration). These ports are directed to the inlet port of the analyzer for sampling unknown gases and reference gases.
  • Page 55: Analog Output Tab

    Analog Output, the on-screen displays and data files continue to record the correct measured concentration, but the Analog Output will saturate at its maximum value of 5.0 volts until the concentration drops back into the expected range. Figure 36: Analog Output Screen ABB GLA151 Series QC Portable User Manual...
  • Page 56 Table 9: D Sub Pins and Pin Assignments D Sub Pin Assignment Output Voltage Pins O Signal 0-5 Volts CO Signal 0-5 Volts O Signal 0-5 Volts Empty Empty O Ground CO Ground O Ground Empty ABB GLA151 Series QC Portable User Manual...
  • Page 57: Service Tab

    Service Tab ABB-trained field service engineers monitor the performance of the analyzer via the Service screen. (Figure 38) These settings determine the level of change that could affect measurement • performance. The alarm threshold levels are analyzer dependent and are set based upon the last •...
  • Page 58: Shutting Down The Analyzer

    OFF switch on the left panel of the analyzer. (Figure 2) Figure 41: Final Shutdown Screen Failure to wait for the power down command to display before shutting off power to the analyzer may result in file system instability. ABB GLA151 Series QC Portable User Manual...
  • Page 59: Maintenance

    Periodically note the ring-down time. If a significant reduction in ring-down time occurs: Request a mirror cleaning kit from ABB-LGR. • If further maintenance is required, contact ABB-LGR for service. • Technical Support: icos.support@ca.abb.com Only authorized persons may open the analyzer cover or perform internal maintenance.
  • Page 60: Replace The Fuse

    3. Unlatch the Case Securing Latches. (Figure 42) a. Push the latch button. b. Pull down on the latch. Figure 42: Case Securing Latches 4. Open the case top. (Figure 43) Figure 43: Open the Case Top ABB GLA151 Series QC Portable User Manual...
  • Page 61 5. The fuse is located on the upper portion of the analyzer on the left side above the internal pump. (Figure 44) Figure 44: Analyzer Fused Inlet 6. Pull the fuse out of the fuse fixture. (Figure 45) Figure 45: Remove the Fuse ABB GLA151 Series QC Portable User Manual...
  • Page 62 9. Re-attach the 11-30 VDC power connector into the left side of the analyzer. (Figure 10. Flip the Power switch to the ON position on the left side of the analyzer. (Figure 4) ABB GLA151 Series QC Portable User Manual...
  • Page 63: Appendix A: Accessing Data Using The Ethernet

    Double-click on the lgrdata directory to see a listing of the data files stored on the internal hard drive of the analyzer. Open or transfer any of the data files, as you would with any Windows share drive. ABB GLA151 Series QC Portable User Manual...
  • Page 64: Additional Notes

    It is possible to access the shared analyzer data directory from operating systems other than Windows. The analyzer uses a Samba server to share the data directory, which could be accessed by any appropriate Samba client application. ABB GLA151 Series QC Portable User Manual...
  • Page 65: Appendix B: Wireless Router Setup (Optional)

    Network Client (VNC) software on your remote device. Refer to page 70 (Appendix C: Set Up Devices for Remote Access Using VNC Software) for details on setting up devices for remote access using VNC software (optional). ABB GLA151 Series QC Portable User Manual...
  • Page 66 2. On the same device, launch a Web browser, then type http://tplinkwifi.net the address bar. (Figure 48) Figure 48: Logging In 3. Enter admin (in lowercase) for the username, and enter Lgr123456789 for the password. 4. Click Login. ABB GLA151 Series QC Portable User Manual...
  • Page 67 5. On the left panel, click Quick Setup. (Figure 49) Figure 49: Start Router Configuration 6. Click Next. 7. In the Main Panel , select the Access Point button. (Figure 49) 8. Click Next. ABB GLA151 Series QC Portable User Manual...
  • Page 68 Wireless Password fields, then click Next. Figure 50: Wireless Setting Screen 10. In the Network Setting screen, click Next. (Figure 51) Figure 51: Network Setting Screen 11. Click Finish. 12. Restart the analyzer. ABB GLA151 Series QC Portable User Manual...
  • Page 69 4. Plug the blue cable into the other port of the Ethernet union. (Figure 53) 5. Connect a local area network (LAN) cable from an external computer to the analyzer Ethernet port, located on the external side panel. ABB GLA151 Series QC Portable User Manual...
  • Page 70: Appendix C: Set Up Devices For Remote Access Using Vnc Software

    4. Enter the wireless password printed on the router sticker. (Figure 47) Every router has a different, unique SSID number, and wireless password. 5. Select Connect. (Figure 54) Figure 54: Password Connection Screen ABB GLA151 Series QC Portable User Manual...
  • Page 71 Search for Android-vnc-viewer and install the application by tapping on the Install button. (Figure 56) An Internet connection is required for this step. Complete instructions for installing the Android-vnc-viewer can be found online http://code.google.com/p/android-vnc-viewer/wiki/Documentation ABB GLA151 Series QC Portable User Manual...
  • Page 72 For example, if the IP address of the Android device that was displayed in Step 8 is 192.168.100.101, then the IP address of the analyzer will be 192.168.100.100. 13. In the Password field, enter lgrvnc. ABB GLA151 Series QC Portable User Manual...
  • Page 73 The screen size is adjustable to fit the screen of the device. (Figure 59) Figure 59: Analyzer Software Interface Display with Size Adjustment for Android Devices ABB GLA151 Series QC Portable User Manual...
  • Page 74 (Figure 47) 5. Select Join. Figure 61: Router Connection Screen 6. The Network Connections screen confirms that the iOS device is connected to the router. (Figure 62) Figure 62: Router Connection Confirmation Screen ABB GLA151 Series QC Portable User Manual...
  • Page 75 Mocha VNC Lite for iOS is the software used in this example. (Figure 64) • An Internet connection is required for this step. • Complete instructions for installing Mocha VNC Lite for iOS can be found online at: http://www.mochasoft.dk/iphone_vnc_help2/help.htm. Figure 64: VNC Selection Screen ABB GLA151 Series QC Portable User Manual...
  • Page 76 For example, if the IP address of the iOS device that was displayed in Step 8 is 192.168.100.101, then the IP address of the analyzer will be 192.168.100.100. 13. In the VNC Password field , enter lgrvnc. ABB GLA151 Series QC Portable User Manual...
  • Page 77 15. To connect the iOS device to the analyzer, tap the IP Config you set up. The analyzer software will display on the device. (Figure 68) The screen size is adjustable to fit the screen of the device. Figure 68: Analyzer Software Interface Screen (Size Adjustment for iOS Devices) ABB GLA151 Series QC Portable User Manual...
  • Page 78 3. Click on the Wireless Network Connections icon in the bottom left of the screen (Figure 69) to open the Windows Wireless Networks dialog-box. (Figure 70) Figure 69: Wireless Connections Icon Figure 70: Windows Wireless Networks ABB GLA151 Series QC Portable User Manual...
  • Page 79 5. In the Security key field, enter the wireless password located on the router sticker. (Figure 47) 6. Click OK. Figure 71: Network Connections Security Screen 7. The Connection Status dialog-box displays. (Figure 72) Figure 72: Current Connectivity Screen ABB GLA151 Series QC Portable User Manual...
  • Page 80 (Figure 73) Figure 73: Wireless Network Connection Screen 9. Verify the IP address of the Windows device: a. Right-click on the TP-LINK-775C network connection. b. Click Status. (Figure 74) Figure 74: Current Connectivity Screen ABB GLA151 Series QC Portable User Manual...
  • Page 81 10. The Wireless Network Connection Status dialog-box displays. (Figure 75) Figure 75: Wireless Network Connection Status Window 11. Click the Details button to display the Network Connection Details window. (Figure 76) Figure 76: Network Connection Details Window ABB GLA151 Series QC Portable User Manual...
  • Page 82 For example, if the IP address of the Windows device that was displayed in Step 12 is 192.168.100.101, then the IP address of the analyzer will be 192.168.100.100. Wireless devices can compete for dynamic addresses. If the 192.168.100.100 address does not connect, then use 192.168.100.101. ABB GLA151 Series QC Portable User Manual...
  • Page 83: Appendix D: Mirror Cleaning Procedure

    • Mirror cleaning kits are included as part of the (recommended) maintenance kits (MTN-CLEAN-M). See Optional Components. If further maintenance is required, contact ABB-LGR for service. • Technical Support: icos.support@ca.abb.com Only authorized persons may open the analyzer cover or perform internal maintenance.
  • Page 84 Figure 78 shows the mirror cleaning kit. Figure 78: Mirror Cleaning Kit ABB GLA151 Series QC Portable User Manual...
  • Page 85 3. Wait ≈ 10 minutes to allow the pressure in the measurement cell to reach ambient room pressure. 4. Unlatch the Case Securing Latches. (Figure 79) a. Push the latch button. b. Pull down on the latch. Figure 79: Unlatch the Case ABB GLA151 Series QC Portable User Manual...
  • Page 86 Figure 80: Ultra-Portable Case Open 6. Remove the safety shield by un-screwing the two flat-head screws and carefully lifting the shield off of the laser assembly. (Figure 81) Figure 81: Remove the Laser Safety Shield ABB GLA151 Series QC Portable User Manual...
  • Page 87 9. Without removing any wires from the detector, place the detector assembly as far from the cavity as possible. Figure 83: Open Ultra-Portable Analyzer Case Showing Mirror Flanges ABB GLA151 Series QC Portable User Manual...
  • Page 88 11. Remove both mirror flanges by unscrewing and loosening the three large flange bolts. The bolts are captive and cannot be removed from the flange. (Figure 85) Figure 85: Remove the Mirror Flanges ABB GLA151 Series QC Portable User Manual...
  • Page 89 Chapman screwdriver kit. (Figure 87) Figure 87: Detach the Backing Ring If the small-diameter face-seal O-ring sticks to the mirror, gently remove it and place the O-ring back into the groove at the bottom of the flange. ABB GLA151 Series QC Portable User Manual...
  • Page 90 15. Place the mirror flange on top of the Teflon tube (provided) and carefully push the flange downwards until the mirror pops out of the flange O-ring. (Figure 88) Figure 88: Releasing the Mirror ABB GLA151 Series QC Portable User Manual...
  • Page 91 Do not attempt to remove particles stuck to the mirror by placing the gas canister nozzle close to the mirror surface. Doing this may result in damage to the mirror. ABB GLA151 Series QC Portable User Manual...
  • Page 92 Leave enough tissue free on the near side of the mirror to hold when you drag it. (Figure 91) Figure 91: Put Tissue on the Mirror ABB GLA151 Series QC Portable User Manual...
  • Page 93 This is called drag wiping . (Figure 100) Figure 93: Drag Wipe Step 2 If you see liquid on the mirror after you pass the wipe over it, then you are wiping too fast. ABB GLA151 Series QC Portable User Manual...
  • Page 94 Figure 94: Clean the HR Surface 15. Perform the drag wipe process in this order on the high-reflectivity side: a. Acetone (4 drops) b. Methanol (4 drops) Acetone (4 drops) d. Methanol (4 drops) ABB GLA151 Series QC Portable User Manual...
  • Page 95 8. Gently close the case top by re-latching the Case Securing Latches. (Figure 79) 9. Plug the system in and turn the power ON. If you performed the cleaning properly, the cavity ring-down time will be close to the target value. ABB GLA151 Series QC Portable User Manual...
  • Page 96 Methanol HPLC Plus, ≥ 99.9% (Sigma-Aldrich Part #: 646377) • Compressed air duster canister (McMaster-Carr Part #: 7437K35) • Chapman screwdriver kit (McMaster-Carr Part #: 5399A16) • Edmond Scientific lens tissue (Part #: NT52-105) • ABB GLA151 Series QC Portable User Manual...
  • Page 97: Appendix E: Cables

    Appendix E: Cables Table 11 describes the power cables shipped with your analyzer. Table 11: Power Cables Region Cable Specifications Australia and New Zealand United Kingdom ABB GLA151 Series QC Portable User Manual...
  • Page 98 Europe United States ABB GLA151 Series QC Portable User Manual...
  • Page 99 – Canada G1P 0B2 particulars shall prevail. ABB CA does not in whole or in parts – is forbidden Tel: +1 418 877 2944 accept any responsibility whatsoever for without prior written consent of ABB Email: Icos.support@ca.abb.com...
