Casio 2766 Operation Manual

MO0307-EA
Getting Acquainted
Congratulations upon your selection of this CASIO watch. To get the most out
of your purchase, be sure to carefully read this manual and keep it on hand
for later reference when necessary.
Expose the watch to bright light to charge its battery before using it.
You can use this watch even as its battery is being charged by exposure to
bright light.
• Be sure to read "Battery" of this manual for important
information you need to know when exposing the watch to bright
light.
Applications
The built-in sensors of this watch measure direction, altitude, barometric
pressure, and temperature. Measured values are then shown on the display.
Such features make this watch useful when hiking, mountain climbing, or
when engaging in other such outdoor activities.
• The measurement functions built into this watch are not intended for
taking measurements that require professional or industrial precision.
Values produced by this watch should be considered as reasonable
representations only.
• When engaging in mountain climbing or other activities in which losing
your way can create a dangerous or life-threatening situation, always be
sure to use a second compass to confirm direction readings.
• CASIO COMPUTER CO., LTD. assumes no responsibility for any loss,
or any claims by third parties that may arise through the use of this
watch.
General Guide
• The illustration below shows which buttons you need to press to navigate
between modes.
• In any mode, press L to illuminate the display.
Alarm Mode
Data Recall Mode
D
D
Hand Setting Mode
Stopwatch Mode
D
Timekeeping
Month – Day
Day of week
Seconds
Hour : Minutes
PM indicator
To set the digital time and date
1. In the Timekeeping Mode, hold down A until the seconds start to flash,
which indicates the setting screen.
2. Press D to move the flashing in the sequence shown below to select other
settings.
Seconds
Power Saving
on/off
Operation Guide 2766
Warning!
Hold down
Timekeeping Mode
D.
Press D.
D
This watch features separate digital and analog
timekeeping. The procedures for setting the
digital time and analog time are different.
• Whenever you need to adjust both the digital
and the analog time settings, make sure you
adjust the digital setting first.
Digital Time and Date
Use the Timekeeping Mode to set and view a
digital display of the current time and date. When
setting the digital time, you can also configure
settings for the 12/24-hour format and the Power
Saving function.
12/24-Hour
Minutes
Hour
Format
Day of
Day Month
week
If the digital display of the watch is blank...
• The initial factory default setting is Power Saving on.
• The watch recovers from the sleep state if you move it to a well-lit area
you press any button, or if you angle the watch towards your face for
reading.
It can take up to two seconds for the display to turn on.
*
• See "Power Saving Function" for more information.
About This Manual
(Light)
• From the Timekeeping Mode or another sensor mode, you can use buttons
B, C, or E to directly enter the mode assigned to it. From any other
mode, you must go to the Timekeeping Mode first.
Press B.
Barometer/
Thermometer Mode
L
3. When the setting you want to change is flashing, use E to change it as
described below.
Setting
Seconds
Hour, Minutes
12/24-Hour
format
Year, Month,
Day
Day of week
Power Saving
on/off
4. Press A to exit the setting screen.
• Resetting the seconds only (without changing the hour or minute setting)
causes the analog minute hand setting to be adjusted automatically.
• See "Power Saving Function" for details about configuring Power Saving
settings.
Year
If the SLEEP indicator is on the display (either
flashing or steady), it means that the display is
blank because the watch's Power Saving function
has turned off the display to conserve power.
Power Saving automatically turns off the display
and enters a sleep state whenever the watch is
left for a certain period where it is dark.
• Button operations are indicated using the
letters shown in the illustration.
• Each section of this manual provides you with
the information you need to perform operations
in each mode. Further details and technical
information can be found in the "Reference"
section.
• Most of the display examples in this manual
show only the digital display, without the analog
hands, as shown in the lower illustration.
Sensor Modes
Press C.
Digital Compass Mode
Press D.
Screen Button Operations
Press E to reset the seconds to 00.
Use E (+) to change the setting.
Use E to toggle between 12-hour (12H)
and 24-hour (24H) timekeeping.
Use E (+) to change the setting.
Use E (+) to change the setting.
Press E to toggle Power Saving on (ON)
and off (OFF).
, if
*
Press E.
Altimeter Mode
1
