Protech Systems SA-N718 User Manual

Intel 10th gen. core i9/i7/i5/i3 / pentium / celeron processor book size pc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER
MANUAL
SA-N718 M1
SA-N718
Intel
10th Gen. Core i9/i7/i5/i3 /
®
Pentium
/ Celeron
®
Size PC
Processor Book
®

Advertisement

Table of Contents
loading

Related Manuals for Protech Systems SA-N718

Summary of Contents for Protech Systems SA-N718

  • Page 1 USER MANUAL SA-N718 Intel 10th Gen. Core i9/i7/i5/i3 / ® Pentium / Celeron Processor Book ® ® Size PC SA-N718 M1...
  • Page 2 SA-N718 ® Intel 10th Gen. Core i9/i7/i5/i3 / Pentium® / Celeron® Processor Book Size PC COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in Jan. 2022. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Contents Revision History .................... vii Introduction ..................1-1 About This Manual ..............1-2 Getting Started ..................2-1 Package List ................2-2 System Overview ............... 2-3 2.2.1 Front View ................2-3 2.2.2 Rear View ................2-3 2.2.3 Top View ................2-4 2.2.4 Bottom View ................
  • Page 5 3.5.1 COM1 and COM2 PORT (COM1, COM2) ......3-7 3.5.2 COM3, COM4, COM5, COM6 CONNECTOR (COM3 ~ COM6) ................3-8 3.5.3 COM1, COM2 and COM4 PIN9 DEFINITION SELECTION GUIDE (JPCOM1, JPCOM2, JPCOM4) ......3-9 3.5.4 PS/2 COMBO & DUAL USB 2.0 PORT (KB_MS_USB1) . 3-11 3.5.5 DISPLAYPORT (DP1) ............
  • Page 6 Software Utilities ................. 4-1 Introduction................. 4-2 ® Installing Intel Chipset Software Installation Utility ....4-3 4.2.1 Introduction ................. 4-3 ® 4.2.2 Intel Chipset Software Installation Utility ......4-3 ® Intel Management Engine Components Installer Installation ... 4-4 Installing Graphics Driver Utility ..........4-4 Installing LAN Driver Utility ............
  • Page 7 5.4.5.3 Super IO Configuration – Serial Port 3 Configuration ..................5-17 5.4.5.4 Super IO Configuration – Serial Port 4 Configuration ..................5-18 5.4.5.5 Super IO Configuration – Serial Port 5 Configuration ..................5-19 5.4.5.6 Super IO Configuration – Serial Port 6 Configuration ..................
  • Page 8 Appendix A System Diagrams ............ A-1 SA-N718 System Exploded Diagram ............A-2 SA-N718 CPU Heat Sink Exploded Diagram ...........A-4 SA-N718 SATA HDD Exploded Diagram ..........A-5 SA-N718 PS-8080 Front Panel Assembly Exploded Diagram ....A-6 Appendix B Technical Summary ..........B-1 Block Diagram ..................B-2 Interrupt Map ....................B-3...
  • Page 9 DMA Channels Map ................B-16 Memory Map ...................B-17 Configuring WatchDog Timer ..............B-19 Flash BIOS Update .................B-21...

  • Page 10: Revision History

    Revision History The revision history of SA-N718 User Manual is described below: Version No. Revision History Page No. Date Initial Release 2022/01/27...

  • Page 11: Introduction

    Introduction This chapter provides the introduction for the SA-N718 system as well as the framework of the user manual. The following topic is included: • About This Manual SA-N718 SERIES USER MANUAL Page: 1-1...

  • Page 12: About This Manual

    Chapter 1 Introduction 1.1 About This Manual Thank you for purchasing our SA-N718 system. The SA-N718 is an updated system designed to be comparable with the highest performance of IBM AT personal computers. The SA-N718 provides faster processing speed, greater expandability and can handle more tasks than before.

  • Page 13: Getting Started

    Getting Started This chapter provides the information for the SA-N718 system. It describes how to set up the system quickly and outlines the system specifications. The following topics are included: • Package List • System Overview • System Diagrams • System Specification •...

  • Page 14: Package List

    2.1 Package List If you discover any of the items listed below are damaged or lost, please contact your local distributor immediately. Item Q’ty SA-N718 Manual / Driver DVD Quick Guide Mini Jumper (2 mm) SA-N718 SERIES USER MANUAL Page: 2-2...

  • Page 15: System Overview

    Chapter 2 Getting Started 2.2 System Overview Unit: mm 2.2.1 Front View 2.2.2 Rear View COM3 COM5 COM4 COM6 COM2 DVI-D COM1 DVI-D SA-N718 SERIES USER MANUAL Page: 2-3...

  • Page 16: Top View

    Chapter 2 Getting Started 2.2.3 Top View 300.20 2.2.4 Bottom View SA-N718 SERIES USER MANUAL Page: 2-4...

  • Page 17: Side View

    Chapter 2 Getting Started 2.2.5 Side View 2.2.6 Quarter View SA-N718 SERIES USER MANUAL Page: 2-5...

  • Page 18: System Specifications

     300.2 x 94.5 x 272.79 mm Weight  5kg Certificate  FCC/CE I/O Ports  4 x USB 3.0 (rear side)  2 x USB 2.0 (rear side)  2 x USB 3.0 (front side, option) SA-N718 SERIES USER MANUAL Page: 2-6...
  • Page 19 PS/2 Keyboard and Mouse simultaneously, PS/2 extended cable attached in packing must be used.  1 x Power LED, 1 x HDD LED Environment Operating Temp.  HDD: 0°C ~40°C (32°F~104°F) Storage Temp.  -20°C ~60°C (-4°F~140°F) Humidity  20%~ 90% SA-N718 SERIES USER MANUAL Page: 2-7...

  • Page 20: Safety Precautions

    Avoid direct sunlight exposure for a long period of time (for example, in a closed car in summer time. Also avoid the system from any heating device.). Or do not use SA-N718 when it has been left outdoors in a cold winter day. •...

  • Page 21: System Configuration

    The following topics are included: • External I/O Ports Diagram • Main Board Jumper Settings and Component Locations • How to Set Jumpers • Setting Main Board Connectors and Jumpers SA-N718 SERIES USER MANUAL Page: 3-1...

  • Page 22: External I/O Ports Diagram

    Connector for KB and MS COM5 Line In LAN2 LAN1 COM6 Line Out COM4 COM3 COM3 COM5 COM4 COM6 COM2 DVI-D COM2 COM1 DVI-D 2 x DVI-D Mic In COM1 USB 2.0 USB 3.0 SA-N718 SERIES USER MANUAL Page: 3-2...

  • Page 23: Jumper & Connector Quick Reference Table

    Audio Port Connector AUDIO1, JAUDIO1 FAN Connector CPU_FAN1, SYS_FAN1, SYS_FAN2 Front Panel Connector JFP1 Case Open Connector LPC Connector JLPC1 M.2 Slot M2_SSD1 PCIe Slot PCI_E1 Power Input Connector ATX_PWR1, ATX_PWR2 SATA1, SATA2, SATA Connector SA-N718 SERIES USER MANUAL Page: 3-2...

  • Page 24: Component Locations

    CAUTION: Always touch the motherboard components by the edges. Never touch components such as a processor by its pins. Take special cares while you are holding electronic circuit boards by the edges only. Do not touch the main board components. SA-N718 SERIES USER MANUAL Page: 3-3...

  • Page 25: Bottom View Of Bm-D025 Main Board

    Chapter 3 System Configuration 3.3.2 Bottom View of BM-D025 Main Board Figure 3-2 BM-2505 Main Board Component Location (Bottom View) SA-N718 SERIES USER MANUAL Page: 3-4...

  • Page 26: Setting Jumpers

    2 to create one setting and shorting. You can also select to connect pins 2 and 3 to create another setting. The format of the jumper picture will be illustrated throughout this manual. The figure below shows different types of jumpers and jumper settings. SA-N718 SERIES USER MANUAL Page: 3-5...
  • Page 27 Chapter 3 System Configuration Jumper diagrams Jumper settings SA-N718 SERIES USER MANUAL Page: 3-6...

  • Page 28: Setting Main Board Connectors And Jumpers

    The pin assignments are as follows: Signal RS-232 DCD# DTR# DSR# RTS# CTS# Notes: COM1 is selectable as RS-232, RS-422, RS-485 under BIOS setting. Default setting is RS-232. Please see Chapter 5 “Advanced – Super IO Configuration” for details. SA-N718 SERIES USER MANUAL Page: 3-7...

  • Page 29: Com3, Com4, Com5, Com6 Connector

    COM1, COM2, COM4: COM1 Pin 9, COM2 Pin 18, COM4 pin 9 are selectable for RI, +5V or +12V by jumper setting. Default setting is RI. Please see “COM1, COM2 and COM4 PIN9 Definition Selection Guide” for details. SA-N718 SERIES USER MANUAL Page: 3-8...

  • Page 30: Com1, Com2 And Com4 Pin9 Definition Selection Guide (Jpcom1, Jpcom2, Jpcom4)

    COM1, COM2 and COM4 PIN9 DEFINITION SELECTION GUIDE (JPCOM1, JPCOM2, JPCOM4) Jumper Location: JPCOM1, JPCOM2 Description: COM1 and COM2 RI & Voltage Selection Jumper Setting Selection Jumper Illustration (Pin Closed) (Default Setting) JPCOM1/JPCOM2 +12V JPCOM1/JPCOM2 JPCOM1/JPCOM2 SA-N718 SERIES USER MANUAL Page: 3-9...
  • Page 31 Chapter 3 System Configuration Jumper Location: JPCOM4 Description: COM4 RI & Voltage Selection Jumper Setting Selection Jumper Illustration (Pin Closed) (Default Setting) JPCOM4 +12V JPCOM4 JPCOM4 SA-N718 SERIES USER MANUAL Page: 3-10...

  • Page 32: Ps/2 Combo & Dual Usb 2.0 Port (Kb_Ms_Usb1)

    Supports both keyboard and mouse function on PS/2 by Y-cable. PS/2: PS/2 ASSIGNMENT ASSIGNMENT KB_DATA KB_CLK MS_DATA MS_CLK 11 10 Dual USB 2.0 Dual USB 2.0: ASSIGNMENT ASSIGNMENT USB D+ USB D+ USB D- USB D- KB_MS_USB1 SA-N718 SERIES USER MANUAL Page: 3-11...

  • Page 33: Displayport (Dp1)

    DISPLAYPORT (DP1) Port Location: DP1 Description: DisplayPort DP1 signals: ASSIGNMENT ASSIGNMENT LANE 0_P LANE 0_N LANE 1_P LANE 1_N LANE 2_P LANE 2_N LANE 3_P LANE 3_N AUX_EN AUX CH_P AUX CH_N +3.3V +3.3V SA-N718 SERIES USER MANUAL Page: 3-12...

  • Page 34: Dual Dvi-D Ports (Dvi1)

    Port Location: DVI1 (rear I/O) Description: 2 x DVI (Digital Visual Interface) Integrated Connectors (Supports only DVI-D signals) DVI1 DVI1 connector signals (A): ASSIGNMENT ASSIGNMENT TMDS_D2- TMDS_D2+ TMDS_HPD TMDS_D0- TMDS_CLK TMDS_D0+ TMDS_DATA TMDS_D1- TMDS_D1+ TMDS_D3+ TMDS_D3- SA-N718 SERIES USER MANUAL Page: 3-13...
  • Page 35 Chapter 3 System Configuration DVI1 connector signals (B): ASSIGNMENT ASSIGNMENT TMDS_D2- TMDS_D2+ TMDS_HPD TMDS_D0- TMDS_CLK TMDS_D0+ TMDS_DATA TMDS_D1- TMDS_D1+ TMDS_D3+ TMDS_D3- SA-N718 SERIES USER MANUAL Page: 3-14...

  • Page 36: Front Panel Connector (Jfp1)

    ASSIGNMENT SETTINGS ILLUSTRATION 1. HDD_LED+ HDD LED 3. HDD_LED- JFP1 2. PWR_LED+ Power LED 4. PWR_LED- JFP1 5. GND Reset Button 7. RST_BTN JFP1 6. PWR_BTN Power Button 8. GND JFP1 9. VCC5 JFP1 SA-N718 SERIES USER MANUAL Page: 3-15...

  • Page 37: Lan & Usb Port (Lan1_Usb1, Lan2_Usb2)

    Giga LAN Speed Indicator No LAN Switch/HUB connected Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active USB 3.0 signals: ASSIGNMENT ASSIGNMENT USB_TX_P USB D- USB_TX_N USB D+ USB_RX_P USB_RX_N SA-N718 SERIES USER MANUAL Page: 3-16...
  • Page 38 Left Side LED Green Color On7 10/100 LAN Speed Indicator Orange Color On8 Giga LAN Speed Indicator No LAN Switch/HUB connected Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active SA-N718 SERIES USER MANUAL Page: 3-17...
  • Page 39 Chapter 3 System Configuration USB 3.0 signals: ASSIGNMENT ASSIGNMENT USB_TX_P USB D- USB_TX_N USB D+ USB_RX_P USB_RX_N ASSIGNMENT ASSIGNMENT USB_TX_P USB D- USB_TX_N USB D+ USB_RX_P USB_RX_N SA-N718 SERIES USER MANUAL Page: 3-18...

  • Page 40: Line In, Line Out, Mic In Port (Audio1)

    44 43 42 HD_LINE-IN-L 35 34 33 32 25 24 23 22 HD_LINE-IN-R 5 4 1 3 2 Line In Line Out: ASSIGNMENT Line Out HD_LINE-OUT-L Mic In HD_LINE-OUT-R AUDIO1 Mic In: ASSIGNMENT HD_MIC-L HD_MIC-R SA-N718 SERIES USER MANUAL Page: 3-19...

  • Page 41: Printer Port Connector (Lpt1)

    Chapter 3 System Configuration 3.5.10 PRINTER PORT CONNECTOR (LPT1) Connector Location: LPT1 Description: Printer Port Connector LPT1 ASSIGNMENT ASSIGNMENT PRN_STRB# PRN_AFD PRN_D0 PRN_ERR# PRN_D1 PRN_INIT PRN_D2 PRN_SLIN PRN_D3 PRN_D4 PRN_D5 PRN_D6 PRN_D7 PRN_ACK# PRN_BUSY PRN_PE PRN_SLCT SA-N718 SERIES USER MANUAL Page: 3-20...

  • Page 42: Front Panel Audio Connector (Jaudio1)

    Chapter 3 System Configuration 3.5.11 FRONT PANEL AUDIO CONNECTOR (JAUDIO1) Connector Location: JAUDIO1 Description: Front Panel Audio Connector ASSIGNMENT ASSIGNMENT MIC1-L LINE-IN-L LINE-OUT-L MIC1-R JAUDIO1 LINE-IN-R LINE-OUT-R Note: JAUDIO1 is only supported in BM-D025-Z0N. SA-N718 SERIES USER MANUAL Page: 3-21...

  • Page 43: Case Open Connector (Jp5)

    Chapter 3 System Configuration 3.5.12 CASE OPEN CONNECTOR (JP5) Connector Location: JP5 Description: Case Open Connector ASSIGNMENT COPEN# SA-N718 SERIES USER MANUAL Page: 3-22...

  • Page 44: Slot (M2_Ssd1)

    M2_SSD1 ASSIGNMENT ASSIGNMENT +3.3V +3.3V PE_RX_N3 PE_RX_P3 PE_TX_N3 +3.3V PE_TX_P3 +3.3V +3.3V PE_RX_N2 +3.3V PE_RX_P2 PE_TX_N2 PE_TX_P2 PE_RX_N1 PE_RX_P1 PE_TX_N1 PE_TX_P1 PE_RX_N0 / SATA PE_RX_P0 / SATA PE_TX_N0 / SATA PE_TX_P0 / SATA PERST# SA-N718 SERIES USER MANUAL Page: 3-23...
  • Page 45 Chapter 3 System Configuration ASSIGNMENT ASSIGNMENT CLKREQ# REFCLK_N PEWAKE# REFCLK_P PE-NC / SATA-GND +3.3V +3.3V +3.3V SA-N718 SERIES USER MANUAL Page: 3-24...

  • Page 46: Pcie Bus (Pci_E1 (X16))

    Description: 164-pin PCIE Bus (x16) PCI_E1 ASSIGNMENT ASSIGNMENT +12V PRSNT#1 +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3V_AUX +3.3V WAKE# PERST# RSVD REFCLK+ HSOP0 REFCLK- HSON0 HSIP0 PRSNT#2 HSIN0 HSOP1 RSVD HSON1 HSIP1 HSIN1 HSOP2 HSON2 SA-N718 SERIES USER MANUAL Page: 3-25...
  • Page 47 HSOP4 RSVD HSON4 HSIP4 HSIN4 HSOP5 HSON5 HSIP5 HSIN5 HSOP6 HSON6 HSIP6 HSIN6 HSOP7 HSON7 HSIP7 PRSNT#2 HSIN7 HSOP8 RSVD HSON8 HSIP8 HSIN8 HSOP9 HSON9 HSIP9 HSIN9 HSOP10 HSON10 HSIP10 HSIN10 HSOP11 HSON11 HSIP11 SA-N718 SERIES USER MANUAL Page: 3-26...
  • Page 48 Chapter 3 System Configuration ASSIGNMENT ASSIGNMENT HSIN11 HSOP12 HSON12 HSIP12 HSIN12 HSOP13 HSON13 HSIP13 HSIN13 HSOP14 HSIN14 HSIP14 HSIN14 HSIP15 HSIN15 HSIP15 PRSNT#2 HSIN15 RSVD SA-N718 SERIES USER MANUAL Page: 3-27...

  • Page 49: Cpu / System Fan Connector

    Description: CPU Fan Connector (CPU_FAN1) ASSIGNMENT +12V CPU_FANTAC CPU_FANCTRL CPU_FAN1 Connector Location: SYS_FAN1 Description: System Fan Connector (SYS_FAN1) ASSIGNMENT +12V SYS_FAN1 Connector Location: SYS_FAN2 Description: System Fan Connector 2 (SYS_FAN2) ASSIGNMENT +12V SYS_FANTAC SYS_FANCTRL SYS_FAN2 SYS_FAN2 SA-N718 SERIES USER MANUAL Page: 3-28...

  • Page 50: Serial Ata (Sata) Connector (Sata1, Sata2)

    Chapter 3 System Configuration 3.5.16 SERIAL ATA (SATA) CONNECTOR (SATA1, SATA2) Connector Location: SATA1, SATA2 Description: SATA Connectors Pin Assignments for SATA1, SATA2: ASSIGNMENT SATA_TX_P SATA1 SATA_TX_N SATA_RX_N SATA_RX_P SATA2 SA-N718 SERIES USER MANUAL Page: 3-29...

  • Page 51: Internal Usb 3.0 Connector (Usb1)

    Chapter 3 System Configuration 3.5.17 INTERNAL USB 3.0 CONNECTOR (USB1) Connector Location: USB1 Description: Internal USB 3.0 Connector ASSIGNMENT ASSIGNMENT USB_D+ USB_RX_N USB_D- USB_RX_P USB_TX_P USB_TX_N USB_TX_N USB_TX_P USB_RX_P USB D- USB_RX_N USB D+ USB1 SA-N718 SERIES USER MANUAL Page: 3-30...
  • Page 52 POWER INPUT CONNECTOR (ATX_PWR1, ATX_PWR2) Connector Location: ATX_PWR1 Description: ATX Power Connector ASSIGNMENT ASSIGNMENT +3.3V +3.3V +3.3V -12V PSON +5V_SB +12V +12V ATX_PWR1 +3.3V Connector Location: ATX_PWR2 Description: Power Connector ASSIGNMENT ASSIGNMENT +12V +12V ATX_PWR2 SA-N718 SERIES USER MANUAL Page: 3-31...

  • Page 53: Low Pin Count (Lpc) Connector (Jlpc1)

    Chapter 3 System Configuration 3.5.19 LOW PIN COUNT (LPC) CONNECTOR (JLPC1) Connector Location: JLPC1 Description: LPC Connector ASSIGNMENT ASSIGNMENT FRAME SERIRQ / GND RESET LAD0 LAD3 LAD2 +3.3V LAD1 JLPC1 SA-N718 SERIES USER MANUAL Page: 3-32...
  • Page 54 Chapter 3 System Configuration 3.5.20 HARDWARE POWER FAILURE SELECTION (JP_AT1) Jumper Location: JP_AT1 Description: Hardware Power Failure Selection Jumper Setting Selection Jumper Illustration (Pin Closed) Enable JP_AT1 Open Disable (Default Setting) JP_AT1 SA-N718 SERIES USER MANUAL Page: 3-33...

  • Page 55: Flash Descriptor Override Selection (Jp1)

    Chapter 3 System Configuration 3.5.21 FLASH DESCRIPTOR OVERRIDE SELECTION (JP1) Jumper Location: JP1 Description: Flash Descriptor Override Selection Jumper Setting Selection Jumper Illustration (Pin Closed) Normal Override (Default Setting) SA-N718 SERIES USER MANUAL Page: 3-34...

  • Page 56: Pch Configuration / Recovery Selection (Jp4)

    Chapter 3 System Configuration 3.5.22 PCH CONFIGURATION / RECOVERY SELECTION (JP4) Jumper Location: JP4 Description: PCH Configuration / Recovery Selection Jumper Setting Selection Jumper Illustration (Pin Closed) Normal (Default Setting) Configure Recovery Open SA-N718 SERIES USER MANUAL Page: 3-35...

  • Page 57: Lpc Connector Irq / Gnd Selection (Jp7)

    Chapter 3 System Configuration 3.5.23 LPC CONNECTOR IRQ / GND SELECTION (JP7) Jumper Location: JP7 Description: LPC Connector IRQ / GND Selection Jumper Setting Selection Jumper Illustration (Pin Closed) (Default Setting) SA-N718 SERIES USER MANUAL Page: 3-36...

  • Page 58: Clear Cmos Data Selection (Jcmos1)

    Step 4. Power on the PC and the PC will then auto-reboot for once in order to set SoC’s register. Step 5. Done! Jumper Setting Selection Jumper Illustration (Pin Closed) Open Normal (Default Setting) JCMOS1 Clear CMOS JCMOS1 SA-N718 SERIES USER MANUAL Page: 3-37...

  • Page 59: Software Utilities

    • Installing Intel ® Chipset Software Installation Utility • Installing Intel ® Management Engine Components Installer • Installing Graphics Driver Utility • Installing LAN Driver Utility • Installing Sound Driver Utility • Installing Intel ® Rapid Storage Utility SA-N718 SERIES USER MANUAL Page: 4-1...

  • Page 60: Introduction

    Chapter 4 Software Utilities 4.1 Introduction Enclosed with the SA-N718 Series package is our driver utilities contained in a DVD-ROM disk. Refer to the following table for driver locations: Filename (Assume that Purpose DVD- ROM drive is D :) D: \Driver\Platform\1_Main ®...

  • Page 61: Installing Intel ® Chipset Software Installation Utility

    10 series, and it should be installed immediately after the OS installation is finished. Please follow the steps below: Connect the USB DVD-ROM device to SA-N718 and insert the driver disk. Enter the Main Chip folder where the Chipset driver is located.

  • Page 62: Intel ® Management Engine Components Installer Installation

    ® 4.3 Intel Management Engine Components Installer Installation Connect the USB DVD-ROM device to SA-N718 and insert the driver disk. Enter the ME folder where the driver is located. Select Windows 10 (64Bit) for your OS platform. Click SetupME.exe file for ME driver installation.

  • Page 63: Installing Lan Driver Utility

    4.5 Installing LAN Driver Utility Enhanced with LAN function, SA-N718 supports various network adapters. To install the LAN Driver, follow the steps below: Connect the USB DVD-ROM device to SA-N718 and insert the driver disk. Enter the LAN folder where the driver is located.

  • Page 64: Installing Sound Driver Utility

    Windows 10 series. To install the Sound Driver, follow the steps below: Connect the USB DVD-ROM device to SA-N718 and insert the driver disk. Open the Sound folder where the driver is located. Select Windows 10 (64-bit) for your OS platform.

  • Page 65: Installing Serial Io Driver Utility

    Chapter 4 Software Utilities 4.7 Installing Serial IO Driver Utility To install the Serial I/O Driver, follow the steps below: Connect the USB DVD-ROM device to SA-N718 and insert the driver disk. Open the Serial IO folder where the driver is located.

  • Page 66: Installing Intel Rapid Storage Utility

    Power-On Self-Test (POST). Enter Chipset > PCH-IO Configuration > SATA Configuration menu screen and select “Intel RST With Intel Optane System Acceleration” option for SATA Controller(s) option item. See the pictures below: SA-N718 SERIES USER MANUAL Page: 4-8...
  • Page 67 Chapter 4 Software Utilities Press F4 to save and validate the changed BIOS configuration and reset the system. SA-N718 SERIES USER MANUAL Page: 4-9...
  • Page 68 Chapter 4 Software Utilities Press <Del> to enter the BIOS Setup Utility program again and the Intel(R) Rapid Storage Technology option item will display under the Advanced menu screen as below: SA-N718 SERIES USER MANUAL Page: 4-10...
  • Page 69 Chapter 4 Software Utilities Select the Intel(R) Rapid Storage Technology option item and press<Enter>, and the following screen will display. Select a RAID level that you want to enter and press <Enter>. SA-N718 SERIES USER MANUAL Page: 4-11...
  • Page 70 The hard drive(s) and hard drive information of the RAID level you selected in the previous step will display: Heed that in the user interface, the hard drive(s) and hard drive information listed for your system will differ from the example above. SA-N718 SERIES USER MANUAL Page: 4-12...
  • Page 71 Chapter 4 Software Utilities Create a RAID volume from the picture below as necessary. SA-N718 SERIES USER MANUAL Page: 4-13...
  • Page 72 RST) utility supports RAID 0, 1 in W480E/Q470E SKU. To install the RAID utility, follow the steps below: Connect the USB DVD-ROM device to SA-N718 and insert the driver disk. Enter the RAID folder where the utility is located. Click SetupRST.exe file for utility installation.

  • Page 73: Bios Setup

    The BIOS Setup Utilities consist of the following menu items: Accessing Setup Utilities • Main Menu • Advanced Menu • Chipset Menu • Security Menu • Boot Menu • Save & Exit Menu • SA-N718 SERIES USER MANUAL Page: 5-1...

  • Page 74: Introduction

    These elements have combined to provide a standard environment for booting the operating system and running pre-boot applications. The diagram below shows the Extensible Firmware Interface’s location in the software stack. Figure 5-1. Extensible Firmware Interface Diagram SA-N718 SERIES USER MANUAL Page: 5-2...
  • Page 75 BIOS setup menu by pressing <Del> or <Esc> immediately while the POST message is running before the operating system is loading. All the menu settings are described in details in this chapter. SA-N718 SERIES USER MANUAL Page: 5-3...

  • Page 76: Accessing Setup Utility

    Self-Test (POST) routines and the POST message will be displayed: Figure 5-2. POST Screen with AMI Logo Press <Del> or <Esc> to access the Setup Utility program and the Main menu of the Aptio Setup Utility will appear on the screen as shown: SA-N718 SERIES USER MANUAL Page: 5-4...
  • Page 77 Select a different menu screen (move the cursor from the selected menu to the left or right). <↑> and <↓> Select a different item (move the cursor from the selected item upwards or downwards) SA-N718 SERIES USER MANUAL Page: 5-5...
  • Page 78 Load the previous configuration values. <F3> Load the default configuration values. <F4> Save the current values and exit the BIOS setup menu. <Esc> Close the sub-menu. Trigger the confirmation to exit BIOS setup menu. SA-N718 SERIES USER MANUAL Page: 5-6...

  • Page 79: Main

    PCH SKU No changeable options Displays the SKU for the PCH. Stepping No changeable options Displays the stepping of the PCH System Date month, day, year Sets the system date. The format is [Day SA-N718 SERIES USER MANUAL Page: 5-7...
  • Page 80 <+> or <-> arrow keys to increase/decrease it. Sets the system time. The format is [Hour: Minute: Second]. Users can directly enter System Time hour, minute, second values or use <+> or <-> arrow keys to increase/decrease it. SA-N718 SERIES USER MANUAL Page: 5-8...

  • Page 81: Advanced

    Hardware Monitor Sub-Menu Monitors hardware status. Super IO Watchdog Sub-Menu Super I/O Watchdog Parameters. Secondary Super IO Secondary System Super I/O Chip Sub-Menu Configuration Parameters. S5 RTC Wake Settings Sub-Menu S5 RTC Wake Parameters. SA-N718 SERIES USER MANUAL Page: 5-9...

  • Page 82: Advanced - Cpu Configuration

    L1 Data Cache No changeable options L1 Data Cache Size. L1 Instruction Cache No changeable options L1 Instruction Cache Size. L2 Cache No changeable options L2 Cache Size. L3 Cache No changeable options L3 Cache Size. SA-N718 SERIES USER MANUAL Page: 5-10...

  • Page 83: Advanced - Pch-Fw Configuration

    Description/Purpose ME Firmware Version No changeable options Displays the ME Firmware Version. ME Firmware Mode No changeable options Displays the ME Firmware Mode. ME Firmware SKU No changeable options Displays the ME Firmware SKU. SA-N718 SERIES USER MANUAL Page: 5-11...

  • Page 84: Advanced - Trusted Computing

    TPM module vendor. Enables or Disables BIOS support for Security Device - Enable (Default) security device. O.S. will not show Security Support - Disable Device. TCG EFI protocol and INT1A interface will not be available. SA-N718 SERIES USER MANUAL Page: 5-12...

  • Page 85: Advanced - Acpi Settings

    Selects the highest ACPI sleep state the ACPI Sleep State - S3 (Suspend to RAM) system will enter when the SUSPEND (Default) button is pressed. - Disabled (Default) S3 Video Repost Enables or Disables S3 Video Repost. - Enabled SA-N718 SERIES USER MANUAL Page: 5-13...

  • Page 86: Advanced - Super Io Configuration

    Serial Port 5 Configuration Sub-Menu Sets Parameters of Serial Port 5 (COM5). Serial Port 6 Configuration Sub-Menu Sets Parameters of Serial Port 6 (COM6). Parallel Port Configuration Sub-Menu Sets Parameters of Parallel Port (LPT/LPTE). SA-N718 SERIES USER MANUAL Page: 5-14...

  • Page 87: Super Io Configuration - Serial Port 1 Configuration

    - IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; Selects IRQ and I/O resource Change Settings - IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; for Serial Port 1. - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; - RS-232 (Default) Mode - RS-422 Selects COM mode. - RS-485 SA-N718 SERIES USER MANUAL Page: 5-15...
  • Page 88 No changeable options Serial Port 2. - Auto (default) Selects IRQ and I/O resource - IO=2F8h; IRQ=3; for the Serial Port 2. - IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; Change Settings - IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; SA-N718 SERIES USER MANUAL Page: 5-16...
  • Page 89 No changeable options Serial Port 3. - Auto (default) Selects IRQ and I/O resource - IO=3E8h; IRQ=7; for Serial Port 3. - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; Change Settings - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; SA-N718 SERIES USER MANUAL Page: 5-17...
  • Page 90 No changeable options Serial Port 4. - Auto (default) Selects IRQ and I/O resource - IO=2E8h; IRQ=10; for the Serial Port 4. - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; Change Settings - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; SA-N718 SERIES USER MANUAL Page: 5-18...
  • Page 91 No changeable options Serial Port 5. - Auto (default) Selects IRQ and I/O resource - IO=2F0h; IRQ=6; for the Serial Port 5. - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; Change Settings - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; SA-N718 SERIES USER MANUAL Page: 5-19...
  • Page 92 No changeable options Serial Port 6. - Auto (default) Selects IRQ and I/O resource - IO=2E0h; IRQ=11; for the Serial Port 6. - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; Change Settings - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; SA-N718 SERIES USER MANUAL Page: 5-20...

  • Page 93: Super Io Configuration - Parallel Port Configuration

    - SPP Mode; - EPP-1.9 and SPP Mode; Device Mode - EPP-1.7 and SPP Mode; Changes the Printer Port mode. - ECP Mode; - ECP and EPP 1.9 Mode; - ECP and EPP 1.7 Mode; SA-N718 SERIES USER MANUAL Page: 5-21...

  • Page 94: Advanced - Hardware Monitor

    Displays the voltage level of VCORE VCORE No changeable options in supply. Displays the voltage level of VCC5V VCC5V No changeable options in supply. Displays the voltage level of VCC12 VCC12 No changeable options in supply. SA-N718 SERIES USER MANUAL Page: 5-22...

  • Page 95: Smart Fan Mode Configuration

    Smart Fan Mode selection for Sys Smart Fan Control - Auto Duty-Cycle Mode System Fan. (Default) Manual mode fan control. Users can Manual Duty Mode Numeric (from 1 to 100) write expected duty cycle (PWM fan type) 1-100. SA-N718 SERIES USER MANUAL Page: 5-23...

  • Page 96: Advanced - Super Io Watchdog

    Enable Watchdog - Disabled (Default) enabled/disabled. - 1s (Default) Selects time unit (1sec/ 60sec) of Watchdog Timer Unit - 60s watchdog timer. The number of second count for Watchdog Timer Count Numeric Timer (10-59 seconds). SA-N718 SERIES USER MANUAL Page: 5-24...

  • Page 97: Advanced - Secondary Super Io Configuration

    Set Parameters of Serial Port 2 Serial Port 2 Configuration Sub-Menu (COM2) Set Parameters of Serial Port 3 Serial Port 3 Configuration Sub-Menu (COM3) Set Parameters of Serial Port 4 Serial Port 4 Configuration Sub-Menu (COM4) SA-N718 SERIES USER MANUAL Page: 5-25...
  • Page 98 No changeable options Serial Port 1. - Auto (default) - IO=240h; IRQ=12; - IO=240h; IRQ=3,4,5,6,7,9,10,11,12; Selects IRQ and I/O resource Change Settings - IO=248h; IRQ=3,4,5,6,7,9,10,11,12; for the Serial Port 1. - IO=250h; IRQ=3,4,5,6,7,9,10,11,12; - IO=258h; IRQ=3,4,5,6,7,9,10,11,12; SA-N718 SERIES USER MANUAL Page: 5-26...
  • Page 99 No changeable options Serial Port 2. - Auto (default) - IO=248h; IRQ=12; - IO=240h; IRQ=3,4,5,6,7,9,10,11,12; Selects IRQ and I/O resource Change Settings - IO=248h; IRQ=3,4,5,6,7,9,10,11,12; for the Serial Port 2. - IO=250h; IRQ=3,4,5,6,7,9,10,11,12; - IO=258h; IRQ=3,4,5,6,7,9,10,11,12; SA-N718 SERIES USER MANUAL Page: 5-27...
  • Page 100 No changeable options Serial Port 3. - Auto (default) - IO=250h; IRQ=12; - IO=240h; IRQ=3,4,5,6,7,9,10,11,12; Selects IRQ and I/O resource Change Settings - IO=248h; IRQ=3,4,5,6,7,9,10,11,12; for the Serial Port 3. - IO=250h; IRQ=3,4,5,6,7,9,10,11,12; - IO=258h; IRQ=3,4,5,6,7,9,10,11,12; SA-N718 SERIES USER MANUAL Page: 5-28...
  • Page 101 No changeable options Serial Port 4. - Auto (default) - IO=258h; IRQ=12; - IO=240h; IRQ=3,4,5,6,7,9,10,11,12; Selects IRQ and I/O resource Change Settings - IO=248h; IRQ=3,4,5,6,7,9,10,11,12; for the Serial Port 4. - IO=250h; IRQ=3,4,5,6,7,9,10,11,12; - IO=258h; IRQ=3,4,5,6,7,9,10,11,12; SA-N718 SERIES USER MANUAL Page: 5-29...

  • Page 102: Advanced - S5 Rtc Wake Settings [Fixed Time]

    3 for 3 a.m. and 15 for 3 Enters 0-59 to set the wake-up Wake up minute Numeric (from 0 to 59) minute. Enters 0-59 to set the wake-up Wake up second Numeric (from 0 to 59) second. SA-N718 SERIES USER MANUAL Page: 5-30...

  • Page 103: Advanced - S5 Rtc Wake Settings [Dynamic Time]

    • Dynamic Time: The system will wake on the current time + Increase minute(s). Enters 1-5 to set the increased minute(s) for Wake up minute increase Numeric (from 1 to 5) dynamic wake-up time. SA-N718 SERIES USER MANUAL Page: 5-31...

  • Page 104: Advanced - Usb Configuration

    Optical drives MASS STORAGE - Forced FDD are emulated as 'CD-ROM'. Drives DEVICES: [drive(s)] - Hard Disk with no media will be emulated - CD-ROM according to a drive type. SA-N718 SERIES USER MANUAL Page: 5-32...

  • Page 105: Advanced - Network Stack Configuration

    If disabled, IPv4 PXE boot - Enabled support will not be available. Enables / Disables IPv4 HTTP boot - Disabled (Default) IPv4 HTTP Support support. If disabled, IPv4 HTTP boot - Enabled support will not be available. SA-N718 SERIES USER MANUAL Page: 5-33...

  • Page 106: Advanced - Nvme Configuration

    Numeric (from 1 to 50) will be checked. 5.4.12 Advanced – NVMe Configuration Menu Path Advanced > NVMe Configuration NVMe Configuration Screen BIOS Setting Options Description/Purpose NVMe Configuration No changeable options Displays NVMe device. SA-N718 SERIES USER MANUAL Page: 5-34...

  • Page 107: Chipset

    This menu allows users to configure advanced Chipset settings such as System Agent (SA) and PCH-IO configuration parameters. Chipset Screen BIOS Setting Options Description/Purpose System Agent (SA) Sub-Menu System Agent (SA) Parameters. Configuration PCH-IO Configuration Sub-Menu PCH Parameters. SA-N718 SERIES USER MANUAL Page: 5-35...
  • Page 108 System Agent (SA) Configuration Screen BIOS Setting Options Description/Purpose Memory Configuration Sub-Menu Memory Configuration. Graphics Configuration Sub-Menu Graphics Configuration. PEG Port Configuration Sub-Menu PEG Port Configuration. - Disabled VT-d Enables or Disables VT-d function. - Enabled (Default) SA-N718 SERIES USER MANUAL Page: 5-36...
  • Page 109 Memory Configuration Screen BIOS Setting Options Description/Purpose Memory Frequency No changeable options Displays the Frequency of Memory. DIMM1 No changeable options Displays the size of DIMM1. DIMM2 No changeable options Displays the size of DIMM2. SA-N718 SERIES USER MANUAL Page: 5-37...

  • Page 110: System Agent (Sa) Configuration - Graphics

    The Graphics Configuration allows users to configure the display settings for the LCD panel. Graphics Configuration Screen BIOS Setting Options Description/Purpose - Auto (Default) Select the Graphics device that should Primary Display - IGFX be Primary Display. SA-N718 SERIES USER MANUAL Page: 5-38...
  • Page 111 No changeable options information. - Disabled Enable Root Port - Enabled Enables or Disables the Root Port. - Auto (Default) - Auto (Default) - Gen1 Max Link Speed Configures PCI-E1 Max Speed. - Gen2 - Gen3 SA-N718 SERIES USER MANUAL Page: 5-39...
  • Page 112 - Enabled (Default) to wake up the system. Specifies what state to go to when - Power On Restore AC Power Loss power is re-applied following a - Power Off (Default) power failure (G3 state). SA-N718 SERIES USER MANUAL Page: 5-40...

  • Page 113: Configuration

    I219 LAN PCI Express 9 No changeable options PCI Express 9 settings I210 LAN2 Sub-Menu PCI Express Root Port Settings M.2 PCI Express x4 M Key Sub-Menu PCI Express Root Port Settings. (for Q470/W480 only) SA-N718 SERIES USER MANUAL Page: 5-41...
  • Page 114 - L1.1 PCI Express L1 Substates settings. - L1.1 & L1.2 - Disabled (Default) Hot Plug Hot Plug support enabled / disabled. - Enabled - Auto (Default) PCIe Speed Configures PCIe Speed. - Gen1 SA-N718 SERIES USER MANUAL Page: 5-42...
  • Page 115 • Disabled - Disables ASPM. - Auto - Disabled (Default) L1 Substates - L1.1 PCI Express L1 Substates settings. - L1.1 & L1.2 - Disabled (Default) Hot Plug Hot Plug support enabled / disabled. - Enabled SA-N718 SERIES USER MANUAL Page: 5-43...

  • Page 116: Pch-Io Configuration - Sata Configuration

    Displays the SATA device’s name. - Disabled Enables or Disables SATA Port Port 1 - 3 - Enabled (Default) Device. - Disabled (Default) Enables or Disables SATA Port Hot Plug - Enabled Device Hot Plug function. SA-N718 SERIES USER MANUAL Page: 5-44...

  • Page 117: Security

    Specifies the administrator alphanumeric characters. password. User Password Password can be 3-20 Specifies the user password. alphanumeric characters. Enters sub-menu with option to enabled password protected HDD Security Configuration Sub-Menu HDD/SSD (if supported by SATA device). SA-N718 SERIES USER MANUAL Page: 5-45...
  • Page 118 <Enter>, and the password dialog entry box appears. Select the configured Administrator Password or User Password that you want to delete. Leave the dialog box blank and press <Enter>. Press <Enter> again when the password confirmation box appears. SA-N718 SERIES USER MANUAL Page: 5-46...

  • Page 119: Boot

    Specifies the power-on state of the Bootup NumLock State - Off NumLock Key. - Disabled (Default) Enables or Disables Quiet Boot Quiet Boot - Enabled options. - [Drive(s)] Boot Option #1~#n Sets the system boot order. - Disabled SA-N718 SERIES USER MANUAL Page: 5-47...

  • Page 120: Save & Exit

    Discard Changes and Reset to discard any changes you have made and restore the factory BIOS defaults. Load User Defaults You may simply press F3 at any time to load the Optimized Values which resets all BIOS settings to the factory defaults. Save & Exit Screen SA-N718 SERIES USER MANUAL Page: 5-48...
  • Page 121 Saves the changes done so far as User Save as User Defaults No changeable options Defaults. Restores the User Defaults to all the Restore User Defaults No changeable options setup options. Forces to boot from selected Boot Override - [Drive(s)] [drive(s)]. SA-N718 SERIES USER MANUAL Page: 5-49...

  • Page 122: Appendix A System Diagrams

    SA-N718 system. • SA-N718 System Exploded Diagram • SA-N718 CPU Heat Sink Exploded Diagram • SA-N718 SATA HDD Exploded Diagram • SA-N718 PS-8080 Front Panel Assembly Exploded...
  • Page 123 Appendix A System Diagrams SA-N718 System Exploded Diagram 4X 4X 5 8X 15 8X 4X 6 Component Name Part No. Q’ty SA-5701 Inner Chassis Asm 80-015-03001445 BM-D025_Main_PCB_Assy See Page A-4 ST-1808 Front Panel STD Type C (Black) See Page A-5...
  • Page 124 90-004-01100038 (20.5x20.5x7.6mm)(Black) ATX 250W AC Power Supply(UL 62368) 52-001-00925001 SA-5701 FSP250-50FGBBI(M) Power Holder 20-229-03001445 Driver_Bay_Kit_Asm. See Page A-5 Flat Head Screw #2/ψ5/M3x0.5Px5mm 22-212-30005311 SA-5701 Top Chassis (w/Paint)(Black) 20-015-03061445 SA-5701 IO Shield + Mylar 80-010-07001445 SA-N718 SERIES USER MANUAL Page: A-3...

  • Page 125: Sa-N718 Cpu Heat Sink Exploded Diagram

    Appendix A System Diagrams SA-N718 CPU Heat Sink Exploded Diagram Component Name Part No. Q’ty BM_2505 MAINBOARD CPU HEAT SINK(ψ90x13) & FAN 21-003-09595001 (95x95x16.8mm) L=300mm SA-N718 SERIES USER MANUAL Page: A-4...

  • Page 126: Sa-N718 Sata Hdd Exploded Diagram

    Appendix A System Diagrams SA-N718 SATA HDD Exploded Diagram Component Name Part No. Q’ty PMB-531LF DRIVE BAY FOR 2.5” HDD 20-004-03001082 2.5”_HDD_SATA FILLISTER HEAD SCREW #2 / M3x0.5Px5mm 22-272-30049015 SA-N718 SERIES USER MANUAL Page: A-5...

  • Page 127: Sa-N718 Ps-8080 Front Panel Assembly Exploded Diagram

    Appendix A System Diagrams SA-N718 PS-8080 Front Panel Assembly Exploded Diagram Component Name Part No. Q’ty ST-1808 Front Panel STD Type C(Black) 30-003-28210006 TRUSS Head Screw #2 / T3.0x1.3Px8mm 22-122-30008005 SA-N718 SERIES USER MANUAL Page: A-6...

  • Page 128: Appendix B Technical Summary

    The following topics are included: • Block Diagram • Interrupt Map • I/O Map • DMA Channels Map • Memory Map • Configuring WatchDog Timer • Flash BIOS Update SA-N718 SERIES USER MANUAL Page: B-1...

  • Page 129: Block Diagram

    COM 1 (5V/12V) COM 4 (5V/12V) RS232/422/485 RS232 FINTEK COM 2 COM 5 (5V/12V) RS232 LPC SIO RS232 F81966D-I COM 3 COM 6 RS232 RS232 PS/2 LPT Port Keyboard Connector Monitor (Wafer 2.0 ) Mouse SA-N718 SERIES USER MANUAL Page: B-2...

  • Page 130: Interrupt Map

    IRQ 72 Microsoft ACPI-Compliant System IRQ 73 Microsoft ACPI-Compliant System IRQ 74 Microsoft ACPI-Compliant System IRQ 75 Microsoft ACPI-Compliant System IRQ 76 Microsoft ACPI-Compliant System IRQ 77 Microsoft ACPI-Compliant System IRQ 78 Microsoft ACPI-Compliant System SA-N718 SERIES USER MANUAL Page: B-3...
  • Page 131 IRQ 111 Microsoft ACPI-Compliant System IRQ 112 Microsoft ACPI-Compliant System IRQ 113 Microsoft ACPI-Compliant System IRQ 114 Microsoft ACPI-Compliant System IRQ 115 Microsoft ACPI-Compliant System IRQ 116 Microsoft ACPI-Compliant System IRQ 117 Microsoft ACPI-Compliant System SA-N718 SERIES USER MANUAL Page: B-4...
  • Page 132 IRQ 150 Microsoft ACPI-Compliant System IRQ 151 Microsoft ACPI-Compliant System IRQ 152 Microsoft ACPI-Compliant System IRQ 153 Microsoft ACPI-Compliant System IRQ 154 Microsoft ACPI-Compliant System IRQ 155 Microsoft ACPI-Compliant System IRQ 156 Microsoft ACPI-Compliant System SA-N718 SERIES USER MANUAL Page: B-5...
  • Page 133 IRQ 189 Microsoft ACPI-Compliant System IRQ 190 Microsoft ACPI-Compliant System IRQ 191 Microsoft ACPI-Compliant System IRQ 192 Microsoft ACPI-Compliant System IRQ 193 Microsoft ACPI-Compliant System IRQ 194 Microsoft ACPI-Compliant System IRQ 195 Microsoft ACPI-Compliant System SA-N718 SERIES USER MANUAL Page: B-6...
  • Page 134 IRQ 279 Microsoft ACPI-Compliant System IRQ 280 Microsoft ACPI-Compliant System IRQ 281 Microsoft ACPI-Compliant System IRQ 282 Microsoft ACPI-Compliant System IRQ 283 Microsoft ACPI-Compliant System IRQ 284 Microsoft ACPI-Compliant System IRQ 285 Microsoft ACPI-Compliant System SA-N718 SERIES USER MANUAL Page: B-7...
  • Page 135 IRQ 318 Microsoft ACPI-Compliant System IRQ 319 Microsoft ACPI-Compliant System IRQ 320 Microsoft ACPI-Compliant System IRQ 321 Microsoft ACPI-Compliant System IRQ 322 Microsoft ACPI-Compliant System IRQ 323 Microsoft ACPI-Compliant System IRQ 324 Microsoft ACPI-Compliant System SA-N718 SERIES USER MANUAL Page: B-8...
  • Page 136 IRQ 357 Microsoft ACPI-Compliant System IRQ 358 Microsoft ACPI-Compliant System IRQ 359 Microsoft ACPI-Compliant System IRQ 360 Microsoft ACPI-Compliant System IRQ 361 Microsoft ACPI-Compliant System IRQ 362 Microsoft ACPI-Compliant System IRQ 363 Microsoft ACPI-Compliant System SA-N718 SERIES USER MANUAL Page: B-9...
  • Page 137 IRQ 396 Microsoft ACPI-Compliant System IRQ 397 Microsoft ACPI-Compliant System IRQ 398 Microsoft ACPI-Compliant System IRQ 399 Microsoft ACPI-Compliant System IRQ 400 Microsoft ACPI-Compliant System IRQ 401 Microsoft ACPI-Compliant System IRQ 402 Microsoft ACPI-Compliant System SA-N718 SERIES USER MANUAL Page: B-10...
  • Page 138 IRQ 435 Microsoft ACPI-Compliant System IRQ 436 Microsoft ACPI-Compliant System IRQ 437 Microsoft ACPI-Compliant System IRQ 438 Microsoft ACPI-Compliant System IRQ 439 Microsoft ACPI-Compliant System IRQ 440 Microsoft ACPI-Compliant System IRQ 441 Microsoft ACPI-Compliant System SA-N718 SERIES USER MANUAL Page: B-11...
  • Page 139 IRQ 474 Microsoft ACPI-Compliant System IRQ 475 Microsoft ACPI-Compliant System IRQ 476 Microsoft ACPI-Compliant System IRQ 477 Microsoft ACPI-Compliant System IRQ 478 Microsoft ACPI-Compliant System IRQ 479 Microsoft ACPI-Compliant System IRQ 480 Microsoft ACPI-Compliant System SA-N718 SERIES USER MANUAL Page: B-12...
  • Page 140 IRQ 4294967287 Intel(R) I210 Gigabit Network Connection IRQ 4294967288 Intel(R) I210 Gigabit Network Connection IRQ 4294967289 Intel(R) I210 Gigabit Network Connection IRQ 4294967290 Intel(R) I210 Gigabit Network Connection IRQ 4294967291 Intel(R) I210 Gigabit Network Connection SA-N718 SERIES USER MANUAL Page: B-13...
  • Page 141 IRQ 4294967293 Intel(R) USB 3.1 eXtensible Host Controller - 1.10 (Microsoft) IRQ 4294967294 Standard SATA AHCI Controller Note: These resource information were gathered using Windows 10 (the IRQ could be assigned differently depending on OS). SA-N718 SERIES USER MANUAL Page: B-14...

  • Page 142: I/O Map

    Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000000F0-0x000000F0 Numeric data processor 0x000002E0-0x000002E7 Communications Port (COM6) 0x000002E8-0x000002EF Communications Port (COM4) 0x000002F0-0x000002F7 Communications Port (COM5) 0x000002F8-0x000002FF Communications Port (COM2) 0x00000378-0x0000037F Printer Port (LPT1) 0x000003E8-0x000003EF Communications Port (COM3) SA-N718 SERIES USER MANUAL Page: B-15...

  • Page 143: Dma Channels Map

    Standard SATA AHCI Controller 0x00004090-0x00004097 Standard SATA AHCI Controller 0x0000EFA0-0x0000EFBF Intel(R) SMBus - A323 Intel(R) Active Management Technology - 0x0000FFF8-0x0000FFFF SOL (COM8) DMA Channels Map DMA Channels Map Assignment Channel 3 Printer Port (LPT1) SA-N718 SERIES USER MANUAL Page: B-16...

  • Page 144: Memory Map

    Standard SATA AHCI Controller 0xA1239000-0xA12397FF Standard SATA AHCI Controller 0xFE010000-0xFE010FFF Intel(R) SPI (flash) Controller - A324 0xFE1DF000-0xFE1DFFFF Intel(R) Active Management Technology - SOL (COM8) 0xFED40000-0xFED44FFF Trusted Platform Module 2.0 0xFE1DC000-0xFE1DCFFF Intel(R) Management Engine Interface SA-N718 SERIES USER MANUAL Page: B-17...
  • Page 145 Intel(R) SMBus - A323 0xA0000-0xBFFFF PCI Express Root Complex 0xE0000-0xE3FFF PCI Express Root Complex 0xE4000-0xE7FFF PCI Express Root Complex 0xE8000-0xEBFFF PCI Express Root Complex 0xEC000-0xEFFFF PCI Express Root Complex 0xF0000-0xFFFFF PCI Express Root Complex 0x40000000-0x403FFFFF Motherboard resources SA-N718 SERIES USER MANUAL Page: B-18...

  • Page 146: Configuring Watchdog Timer

    To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. SA-N718 SERIES USER MANUAL Page: B-19...
  • Page 147 ;------------------------------- Enable Watch PME-------------------------------------------- dx, al dx, al ;-------------------------- Set second as counting unit -------------------------------------- dx, al dx, al ;-------------------------- Start the watchdog timer -------------------------------------- dx, al ;---------------------------------Exit the extended function mode ------------------------- dx, al SA-N718 SERIES USER MANUAL Page: B-20...

  • Page 148: Flash Bios Update

    (2) Turn on the computer and press <ESC> or <DEL> key during boot to enter BIOS Setup. (3) Select [Boot] menu and set the USB bootable device to be the boot device. (4) Press <F4> key to save configuration and exit the BIOS setup menu. SA-N718 SERIES USER MANUAL Page: B-21...
  • Page 149 Appendix B Technical Summary SA-N718 SERIES USER MANUAL Page: B-22...
  • Page 150 BIOS ROM and the system will be unable to boot up next time. After BIOS update procedure is completed, the following messages will be shown: SA-N718 SERIES USER MANUAL Page: B-23...
  • Page 151 Restart the system and boot up with the new BIOS configuration. The BIOS Update is completed after the system is restarted. Reboot the system and verify if the BIOS version shown on the initialization screen has been updated. SA-N718 SERIES USER MANUAL Page: B-24...

Table of Contents
