2.1

Attaching the arm/base

To assemble the monitor base:
1. Open the box as illustrated. (Figure 1)
2. Insert the base into the arm. Fix the base to the arm by fastening the bundled
screw. (Figure 2)
3. Attach the arm into the monitor. (Figure 3)
4. Hold the stand and lift the monitor carefully, then place it on a flat surface.
(Figure 4)
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
Base screw size: M5 x 25 mm.
ASUS PG32UCDM Series OLED Monitor
(Figure 1)
(Figure 4)
(Figure 2)
(Figure 3)
2-1
