- Page 1 MPG Series OLED Monitor MPG 271QRX QD-OLED (3CD7) MPG 321URX QD-OLED (3DD2) User Guide...
-
Page 2: Table Of Contents
Image ........................16 Input Source ......................16 PIP/PBP ........................ 17 Navi Key ........................ 18 Setting ........................18 MSI OLED Care ..................... 19 Specifications ......................22 Preset Display Modes ....................24 Troubleshooting......................28 Safety Instructions ...................... 29 TÜV Rheinland Certification..................31 Regulatory Notices ..................... -
Page 3: Getting Started
Getting Started This chapter provides you with the information on hardware setup procedures. While connecting devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity. Package Contents MPG 271QRX QD-OLED Monitor MPG 321URX QD-OLED Documentation Quick Start Guide Stand... -
Page 4: Installing The Monitor Stand
Installing the Monitor Stand 1. Leave the monitor in its protective packaging. Align the stand to the monitor groove. 2. Push the stand towards the monitor groove until it locks in place. 3. Connect the base to the stand and tighten the base screws to secure the base. 4. -
Page 5: Adjusting The Monitor
Adjusting the Monitor This monitor is designed to maximize your viewing comfort with its adjustment capabilities. ⚠ Important Avoid touching the display panel when adjusting the monitor. ∙ ∙ Please slightly tilt the monitor backwards before pivoting it. MPG 271QRX QD-OLED -5°... - Page 6 MPG 321URX QD-OLED -5° 15° 110 mm 10° 10° 30° 30° Getting Started...
-
Page 7: Monitor Overview
Monitor Overview Getting Started... - Page 8 Cable Routing Hole Macro Key To activate OSD Application. Navi Key Power Button Kensington Lock Headphone Jack HDMI™ Connector (MPG 271QRX QD-OLED) Supports HDMI™ CEC, 2560x1440@360Hz as specified in HDMI™ 2.1. (MPG 321URX QD-OLED) Supports HDMI™ CEC, 3840x2160@240Hz as specified in HDMI™ 2.1. HDMI™...
- Page 9 USB 2.0 Type-B Upstream Port For USB Upstream Cable. ⚠ To Monitor Important Check the package for USB Upstream Cable and connect it to the PC and monitor. Once this cable is connected, the USB To PC Type-A Downstream Ports on the monitor will be ready for use.
-
Page 10: Connecting The Monitor To Pc
Connecting the Monitor to PC 1. Turn off your computer. 2. Connect the video cable from the monitor to your computer. 3. Connect the power cord to the monitor power jack. (Figure A) 4. Plug the power cord into the electrical outlet. (Figure B) 5. -
Page 11: Osd Setup
OSD Setup This chapter provides you with essential information on OSD Setup. ⚠ Important All information is subject to change without prior notice. Navi Key The monitor comes with a Navi Key, a multi-directional control that helps navigate the On-Screen Display (OSD) menu. Up/Down/Left/Right: ∙... -
Page 12: Osd Menus
OSD Menus MPG 271QRX QD-OLED MPG 321URX QD-OLED ⚠ Important The following settings will be grayed out when HDR signals are received: Night Vision Color Temperature ∙ ∙ Low Blue Light Optix Scope ∙ ∙ Brightness PIP/PBP ∙ ∙ Contrast A.I. - Page 13 G.I. 1st Level Menu 2nd/3rd Level Menu Description Auto ∙ Auto allows the monitor to automatically switch between USB input sources, such as Upstream keyboards, mice or other USB devices. ∙ Users can also designate Upstream port or Type C USB Type-C as the only USB signal source.
-
Page 14: Gaming
Gaming 1st Level Menu 2nd/3rd Level Menu Description Game Mode Premium Color ∙ Use Up or Down Button to select and preview mode effects. User ∙ Press the OK Button to confirm and apply your mode type. Racing Night Vision ∙... -
Page 15: Professional
1st Level Menu 2nd/3rd Level Menu Description Adaptive-Sync ∙ Adaptive-Sync prevents screen tearing. ∙ Activating Adaptive-Sync will affect: Affected Function Function Status » Screen Size 1:1 Set to Auto » PIP/PBP Set to OFF » Optix Scope Professional 1st Level Menu 2nd Level Menu Description Pro Mode... -
Page 16: Image
Image 1st Level Menu 2nd/3rd Level Menu Description Brightness 0-100 ∙ Properly adjust Brightness according to the surrounding lighting. Contrast 0-100 ∙ Properly adjust Contrast to relax your eyes. Sharpness ∙ Sharpness improves clarity and details of images. Color Temperature Cool ∙... -
Page 17: Pip/Pbp
PIP/PBP 1st Level Menu 2nd/3rd Level Menu Description ∙ PIP (Picture in Picture) allows users to simultaneously display multiple video sources Source HDMI™ 1 on one screen. One program is displayed on the full screen at the same time as one or more HDMI™... -
Page 18: Navi Key
∙ Users can adjust Transparency in any mode. OSD Time Out 5~30s ∙ Users can adjust OSD Time Out in any mode. RGB LED ∙ Users can adjust RGB LED to ON or OFF. MSI - Mystic Light RGB Brightness OSD Menus... -
Page 19: Msi Oled Care
∙ This function enables users to charge their devices through a USB Type-C connector. Reset ∙ Users can Reset and restore settings to original OSD Default in any mode. MSI OLED Care 1st Level Menu 2nd/3rd Level Menu Description Pixel Shift Slow ∙... - Page 20 1st Level Menu 2nd/3rd Level Menu Description Protect Notice Auto ∙ When set to Auto, Protect Notice will pop up when the panel exceeds 4 hours of cumulative Usage 16 hrs usage. ∙ When set to Usage 16 hrs, Protect Notice will pop up when the panel exceeds 16 hours of cumulative usage.
- Page 21 • 3 : 20% reduction ∙ Reducing effect depends on Brightness/ DisplayHDR setting. OLED Panel Info. ∙ This field shows the information of MSI OLED Care. * HDMI™ VRR (Variable Refresh Rate) synchronizes with Adaptive-Sync (ON/ OFF). For VRR ON/OFF status, please check Adaptive-Sync.
-
Page 22: Specifications
Specifications Monitor MPG 271QRX QD-OLED MPG 321URX QD-OLED Size 26.5 inch 31.5 inch Curvature Flat Panel Type QD-OLED 2560x1440 (WQHD) 3840x2160 (UHD) Resolution Aspect Ratio 16:9 ∙ Typical SDR: 250 nits Brightness ∙ Peak HDR: 1000 nits Contrast Ratio 1500000:1 Refresh Rate 360Hz 240Hz... - Page 23 Monitor MPG 271QRX QD-OLED MPG 321URX QD-OLED ∙ Plate Type: 100 x 100 mm ∙ Screw Type: M4 x 10 mm • Thread Diameter: 4 mm VESA Mounting • Thread Pitch: 0.7 mm • Thread Length: 10 mm Dimension (W x H x D) 610 x 422 x 242 mm 718 x 483 x 242 mm 8.3 kg...
-
Page 24: Preset Display Modes
Preset Display Modes ⚠ Important All information is subject to change without prior notice. MPG 271QRX QD-OLED Standard Mode Standard Resolution HDMI™ USB-C 2560x1440 @60Hz @120Hz @240Hz @360Hz Video Timing Resolution 720P 1080P @60Hz 1080P @120Hz 2160P @30Hz 2160P @60Hz 2160P @120Hz HDMI™... - Page 25 PBP Mode 1 (Not Support HDR) Standard Resolution HDMI™ USB-C Video Timing Resolution 720P Used for PBP Full 1920x1440 @60Hz Screen 640x1440 @60Hz PBP Mode 2/ Customize (Not Support HDR) Standard Resolution HDMI™ USB-C Video Timing Resolution 720P Used for PBP Full 1280x1440 @60Hz Screen...
- Page 26 MPG 321URX QD-OLED Standard Mode Standard Resolution HDMI™ USB-C 2560x1440 @60Hz @120Hz 3840x2160 @60Hz @120Hz @180Hz @240Hz Video Timing Resolution 720P 1080P @60Hz 1080P @120Hz 2160P @30Hz 2160P @60Hz 2160P @120Hz HDMI™ VRR for PS5 PIP Mode (Not Support HDR) Standard Resolution HDMI™...
- Page 27 PBP Mode 1 (Not Support HDR) Standard Resolution HDMI™ USB-C Video Timing Resolution 720P Used for PBP Full 960x2160 @60Hz Screen 2880x2160 @60Hz PBP Mode 2/ Customize (Not Support HDR) Standard Resolution HDMI™ USB-C Video Timing Resolution 720P Used for PBP Full 1920x2160 @60Hz Screen...
-
Page 28: Troubleshooting
Troubleshooting The power LED is off. • Press the monitor power button again. • Check if the monitor power cable is properly connected. No image. • Check if the computer graphics card is properly installed. • Check if the computer and monitor are connected to electrical outlets and are turned on. -
Page 29: Safety Instructions
∙ Place the power cord in a way that people are unlikely to step on it. Do not place anything on the power cord. ∙ If this device comes with an adapter, use only the MSI provided AC adapter approved for use with this device. - Page 30 ∙ If any of the following situations arises, get the device checked by service personnel: • The power cord or plug is damaged. • Liquid has penetrated into the device. • The device has been exposed to moisture. • The device does not work well or you can not get it working according to the User Guide.
-
Page 31: Tüv Rheinland Certification
TÜV Rheinland Certification TÜV Rheinland Low Blue Light Certification Blue light has been shown to cause eye fatigue and discomfort. MSI now offers monitors with TÜV Rheinland Low Blue Light certification to ensure users’ eye comfort and well-being. Please follow the instructions below to reduce the symptoms from extended exposure to the screen and blue light. -
Page 32: Regulatory Notices
1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. MSI Computer Corp. 901 Canada Court, City of Industry, CA 91748, USA (626) 913-0828 www.msi.com... - Page 33 Vietnam RoHS As from December 1, 2012, all products manufactured by MSI comply with Circular 30/2011/TT-BCT temporarily regulating the permitted limits for a number of hazardous substances in electronic and electric products.
- Page 34 Copyright and Trademarks Notice Copyright © Micro-Star Int’l Co., Ltd. All rights reserved. The MSI logo used is a registered trademark of Micro-Star Int’l Co., Ltd. All other marks and names mentioned may be trademarks of their respective owners.
