- Page 1 ORIGINAL INSTRUCTIONS - according to Directives 2006/42/EC, Annex I 1.7.4.1 OPERATOR’S MANUAL T7.220 T7.235 T7.250 T7.260 T7.270 Sidewinder ll™ Auto Command - Power Command Part Number 84411172 2nd edition English January 2011...
- Page 2 Find manuals at https://best-manuals.com...
- Page 3 SECTION SUMMARY 1 - - General Information and Safety 2 - - Controls, Instruments and Operation 3 - - Field operation 4 - - Lubrication and Maintenance 5 - - Fault Finding 6 - - Accessories 7 - - Specifications 8 - - First 50 hour Service Forms 9 - - Index Find manuals at https://best-manuals.com...
- Page 4 NOTES Find manuals at https://best-manuals.com...
- Page 5 CE DECLARATION OF CONFORMITY DOCUMENT On page 1--4 is provided copy of the ”EC” Declaration of Conformity (EC Declaration of Conformity acc to 2006/42/EC). The EC Declaration of Conformity is the manufacturer’s declaration about equipment compliance to relevant EU provisions. Please keep the original document in a safe place.
- Page 6 For your better and easier understanding of the document you’ll find original text reproduced hereafter together with some notes Clause of EC Declaration of conformity 2006/42/EC According to Directive 2006/42/EC. Annex II We, [1] 1.A.1 Represented by Giuseppe Gavioli, 1.A.2 CNH Europe Holding S.A.
- Page 7 CONTENTS Title Page Section 1 - - General Information and Safety To the Owner ................1--1 Product Identification .
- Page 8 Drawbars and Towing Attachments ............3--149 Trailer Braking Systems .
- Page 9 Section 7 - - Specification General Dimensions ............... . . 7--2 Vehicle Weights .
- Page 10 METRIC AND IMPERIAL UNITS ABBREVIATIONS RECOMMENDED SI (METRIC) UNITS IMPERIAL UNIT TYPICAL APPLICATIONS NAME SYMBOL NAME SYMBOL AREA Land area hectare acre square meter square foot square inch square millimetre square inch ELECTRICITY ampere ampere volt volt microfarad microfarad F F ...
- Page 11 RECOMMENDED SI (METRIC) UNITS IMPERIAL UNIT TYPICAL APPLICATIONS NAME SYMBOL NAME SYMBOL POWER kilowatt horsepower watt Btu per hour Btu/hr Btu per minute Btu/min PRESSURE or STRESS (FORCE PER AREA) kilopascal pound per square inch inch of mercury inHg pascal inch of water megapascal pound per square inch...
- Page 12 RECOMMENDED SI (METRIC) UNITS IMPERIAL UNIT TYPICAL APPLICATIONS NAME SYMBOL NAME SYMBOL VOLUME PER TIME (includes DISCHARGE and FLOW RATE) cubic meter per minute /min cubic foot per minute /min litre per minute l/min US gallon per minute gal/min millilitre per minute ml/min UK gallon per minute gal/min...
- Page 13 OPERATORS MANUAL Ensure that each piece of non-New Holland equipment fitted to the tractor bears the CE mark. The Operators Manual supplied with your tractor is an important source of information and should be stored safely.
- Page 14 SECTION 1 - - GENERAL INFORMATION AND SAFETY IMPORTANT: It is important the 50 hour service is WARRANTY carried out as recommended to ensure your tractor provides optimum performance and efficiency. Your tractor is warranted according to legal rights in your country and the contractual agreement with the After you have operated the tractor for 50 hours, take selling dealer.
- Page 15 SECTION 1 - - GENERAL INFORMATION AND SAFETY PRODUCT IDENTIFICATION The tractor and major components are identified using serial numbers and/or manufacturing codes. Tractor identification data must be supplied to the dealer when requesting parts or service and will also be needed to aid in identifying the tractor if it is ever stolen.
- Page 16 SECTION 1 - - GENERAL INFORMATION AND SAFETY Engine Information The engine serial number and date of manufacture are stamped on the right--hand side of engine block (1), below the manifold. Record the number below. Engine Serial No. The details are repeated on the information plate located on the left side of the engine oil pan.
- Page 17 SECTION 1 - - GENERAL INFORMATION AND SAFETY Driveline Identification Power Command Transmission The serial number plate (1) is located on the right--hand side of the transmission casing behind the the battery carrier. This number is repeated on vehicle identification plate.
- Page 18 SECTION 1 - - GENERAL INFORMATION AND SAFETY ECOLOGY AND THE ENVIRONMENT Soil, air and water are vital factors of agriculture and 4. Avoid spillage when draining off used engine life in general. Where legislation does not yet rule the coolant mixtures, engine, gearbox and hydraulic treatment of some of the substances which are oils, brake fluids, etc.
- Page 19 SECTION 1 - - GENERAL INFORMATION AND SAFETY PRECAUTIONARY STATEMENTS PERSONAL SAFETY Throughout this manual and on machine decals, you will find precautionary statements (“DANGER”, “WARNING”, and “CAUTION”) followed by specific instructions. These precautions are intended for the personal safety of you and those working with you. Please take the time to read them. DANGER This word “DANGER”...
- Page 20 SECTION 1 - - GENERAL INFORMATION AND SAFETY SAFETY PRECAUTIONS A careful operator is the best operator. Most accidents Failure to follow the CAUTION, WARNING and can be avoided by observing certain precautions. To DANGER instructions may result in serious bodily help prevent accidents, read and take the following injury or even death.
- Page 21 SECTION 1 - - GENERAL INFORMATION AND SAFETY 8. Do not modify or alter or permit anyone else to 6. On four wheel drive tractors, the drive to the front modify or alter the tractor or any of its axle is automatically engaged, to provide four components or any tractor function without first wheel braking, when both footbrakes are consulting your dealer.
- Page 22 SECTION 1 - - GENERAL INFORMATION AND SAFETY OPERATING THE TRACTOR 1. Apply the parking brake, place the P.T.O. control in the ‘OFF’ position, the lift control lever in the down position, the remote control valve levers in the neutral position and the transmission levers in neutral before starting the tractor.
- Page 23 SECTION 1 - - GENERAL INFORMATION AND SAFETY sure hydraulic couplers are properly mounted and will disconnect safely in case of accidental detachment of the implement. 8. Do not park the tractor on a steep incline. 9. The cab is designed to provide the minimum noise level at the operator’s ears and meets or exceeds applicable standards in this respect.
- Page 24 SECTION 1 - - GENERAL INFORMATION AND SAFETY OPERATING THE P.T.O. SERVICING THE TRACTOR 1. When operating P.T.O.- driven equipment, shut off the engine, switch off the P.T.O. and wait until the P.T.O. stops before getting off the tractor and disconnecting the equipment.
- Page 25 SECTION 1 - - GENERAL INFORMATION AND SAFETY fluid or fuel oil under pressure can penetrate the 10. Keep equipment clean and properly maintained. skin causing serious injury. 11. Dispose of all drained fluids and removed filters Unqualified persons should not remove or properly.
- Page 26 SECTION 1 - - GENERAL INFORMATION AND SAFETY 4. Periodically check the tractor electrical system 7. A fire can cause injury or death. It is advisable to for loose connections or frayed insulation. Repair have a fire extinguisher near or on the tractor or replace any damaged parts.
- Page 27 SECTION 1 - - GENERAL INFORMATION AND SAFETY DIESEL FUEL Diesel and biodiesel fuel specifications Diesel fuel specifications are covered by the following: 1. Under no circumstances should gasoline, alcohol or blended fuels be added to diesel fuel. Europe: EN 590 -- Specification of Diesel fuel. These combinations can create an increased fire (10ppm sulfur maximum).
- Page 28 SECTION 1 - - GENERAL INFORMATION AND SAFETY SAFETY DECALS The decals reproduced on the following pages were installed on your tractor in the positions indicated in the drawings below. They are intended for your safety and for those working with you. Please take this Manual and walk around your tractor, noting the location of the decals and their significance.
- Page 29 SECTION 1 - - GENERAL INFORMATION AND SAFETY 1. Location: Left and right-hand side of fan guard To prevent serious injury, keep hands and clothing away from rotating fan and drive belt. Part No. 84269904 2. Location: Left and right- -hand side of radiator Warning! Pressurised cooling system.
- Page 30 SECTION 1 - - GENERAL INFORMATION AND SAFETY 5. Location: Top of battery Danger! Corrosive acid. Explosive gas. Wear eye protection. Avoid producing sparks. See Operator’s Manual. 6. Location: Right- -hand ’A’ pillar inside cab Warning! De--activate Turn Assist system before travelling on the highway.
- Page 31 SECTION 1 - - GENERAL INFORMATION AND SAFETY 9. Location: Right hand rear cab pillar Part No.84269928 Always turn the key to OFF position before performing any intervention or service on the tractor; always refer to the Operator’s manual for specific information.
- Page 32 SECTION 1 - - GENERAL INFORMATION AND SAFETY 13.Location: Left- -hand ‘A’ pillar inside the cab General Warning. Read and understand all the warning notes printed in the Operator’s Manual. In particular, read the General Information and Safety section in the Operator’s Manual.
- Page 33 SECTION 1 - - GENERAL INFORMATION AND SAFETY 17.Location: Left- -hand side of front hitch To avoid injury, do not stand between the implement and tractor while operating the external controls. Part No.84269906 18.Location: On the left hand door This decal identifies the instructor’s seat provided only for training purpose, refer to information provided along selection 1 in this manual for its usage and related risks.
- Page 34 SECTION 1 - - GENERAL INFORMATION AND SAFETY 21.Location: Starter Motor Warning! Do not start engine by shorting across starter terminals. Machine will start in gear if normal circuitry is bypassed. NEVER starter engine while staying on ground. Start engine only from operator’s seat, with transmission in neutral.
- Page 35 SECTION 1 - - GENERAL INFORMATION AND SAFETY 25.Location: Left hand side on the DEF/AdBlue tank Only fill the DEF/AdBlue tank with approved DEF/AdBlue solution. Do not fill with diesel fuel or water. Refer to the Operator’s Manual. Part No.84284896C 26.Location: Left hand side on the DEF/AdBlue...
- Page 36 SECTION 1 - - GENERAL INFORMATION AND SAFETY INTERNATIONAL SYMBOLS As a guide to the operation of your tractor, various universal symbols have been utilised on the instruments, controls, switches, and fuse box. The symbols are shown below with an indication of their meaning. Engine cold Turn signals Parking brake...
- Page 37 SECTION 1 - - GENERAL INFORMATION AND SAFETY AIRBORNE NOISE EMISSION In accordance with E.E.C. directives, the noise levels of tractors covered by this manual are as follows: Tractors with Cabin and Fixed Windscreen with Air Cleaner Extraction System Noise level at operators ear Drive by noise level Closed Open...
- Page 38 SECTION 1 - - GENERAL INFORMATION AND SAFETY TRACTOR VIBRATION LEVEL INFORMATION SHEET HAZARDS RELATED TO VIBRATION EXPOSURE WARNING NOTE: More information about Whole Body Vibra- The Whole Body Vibration level will depend on a lot tion (WBV) on agricultural tractors can be found on of parameters, some of them machine related, oth- specific publications and maybe covered by local ers terrain related and many driver related.
- Page 39 SECTION 1 - - GENERAL INFORMATION AND SAFETY MACHINE STABILITY The following procedure and calculation is based on the machine on even ground. The following procedure describes the requirements for machine stability, and how to calculate the required front mounted and rear mounted ballast. WARNING ballast refer...
- Page 40 SECTION 1 - - GENERAL INFORMATION AND SAFETY NECESSARY DATA TO EVALUATE STABILITY Legend To get this Value Refer to: Mass of the unladen tract- This or = Tractor with standard manual equipment, minimum fuel, no weights or liquid bal- last, no operator, and single wheel equipment Front axle load unladen...
