Philips 20PFL4122/79 Service Manual

Hide thumbs Also See for 20PFL4122/79:
Table of Contents

Advertisement

Quick Links

Download this manual
Colour Television
Contents
1. Technical Specifications, and Connections
6. Block Diagrams, Test Point Overview, and
Waveforms
Block Diagram Power Management
Scaler Board: DC-DC Power
Scaler Board: Lips & Inverter IF
Scaler Board: Tuner
Scaler Board: Video Inputs
Scaler Board: DSUB Input
Scaler Board: DVI-D Input
Scaler Board: MST96885LD/ALD
Scaler Board: Flash ROM & SDRAM
Scaler Board: Key, IR ComPair, Side I/F (S-09) 28
Scaler Board: ITV I/F
Scaler Board: Panel I/F
Scaler Board: Audio I/F
Scaler Board: Audio Amplifier
Scaler Board: Test Points
Keyboard Panel
©
Copyright 2007 Philips Consumer Electronics B.V. Eindhoven, The Netherlands.
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system or transmitted, in any form or by any means, electronic,
mechanical, photocopying, or otherwise without the prior permission of Philips.
Published by CS 0771 BU CD Customer Service
Page
Contents
2
4
6
9
10. Spare Parts List
17
18
19
Diagram PWB
(S-01) 20
33-42
(S-02) 21
33-42
(S-03) 22
33-42
(S-04) 23
33-42
(S-05) 24
33-42
(S-06) 25
33-42
(S-07) 26
33-42
(S-08) 27
33-42
33-42
(S-10) 29
33-42
(S-11) 30
33-42
(S-12) 31
33-42
(S-13) 32
33-42
43
(P01) 46
48-49
(P02) 47
48-49
(K) 50
51
53
Printed in the Netherlands
20PFL4122/79
20PFL4122/93
20PFL4122/98
20HF4005/93
Subject to modification
Chassis
TPS1.0A
LA
H_17042_000.eps
191107
Page
54
59
61
64
68
73
EN 3122 785 17042

Advertisement

Table of Contents
loading

Related Manuals for Philips 20PFL4122/79

Summary of Contents for Philips 20PFL4122/79

  • Page 1: Table Of Contents

    All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips. Published by CS 0771 BU CD Customer Service...
  • Page 2 TPS 1.0A LA 1. Technical Specifications,Connections,and Chassis Overview 1.Technical Specifications,Connections,and Chassis Overview Index of this chapter: Power consumption 1.1 Technical Specifications Normal: 60W/Typ. at PC mode, 60W /Typ. 1.2 Connections at TV mode (LED: Blue) 1.3 Chassis Overview Max: 65W(with Audio) Standby <...
  • Page 3 TPS 1.0A LA 1. Technical Specifications, Connections and Chassis Overview 1.2.3 HDMI Pin assignment (Nafta only) 1.2.4 VGA Pin assignment Type A Connector No. 1 No. 19 No. 2 No. 18 PIN No. SIGNAL PIN No. SIGNAL TMDS Data2+ Green TMDS Data2 shield Blue TDMS Data2-...

  • Page 4: Safety Instructions,Warnings,And Notes

    Mains/AC power plug.\ 2.Set the Mains/AC Power switch to the ON position " " Philips CE is producing Lead-free sets (PBF) from 1.1.2005 (keep the Mains/AC Power cord unplugged!) onwards. 3.Measure the resistance value between the pins of the...
  • Page 5 Always respect voltages.While some may not be dangerous in themselves,they can cause unexpected reactions that are best In September 2005,Philips CE introduced a change in the way avoided.Before reaching into a powered TV set,it is best to test the serial number(or production number,see Figure 2-1)is the high voltage insulation.It is easy to do,and is a good service...

  • Page 6: Directions For Use

    TPS 1.0A LA 3. Directions for Use 3. Directions for Use You can download this information from the following websites: http://www.philips.com/support http://www.p4c.philips.com PC Mode 1st Layer 2nd Layer 3rd Layer 4th Layer Picture Color temp Normal Warm Cool Brightness Contrast...
  • Page 7 TPS 1.0A LA 3. Directions for Use Contrast Brightness Color Sharpness Color temp Normal Warm Cool Picture format Expand 4:3 Compress 16:9 HD 4:3 Smart sound Personal Speech Music Movie Multimedia Settings Treble Bass Balance Incredible surround Timer Clock Start time Stop time Sleep timer Auto lock...
  • Page 8 TPS 1.0A LA 3. Directions for Use Clear all Start ? Source list SIDE AV Install Language English Thai (Only /79/98) Arabic (Only /79/98) Auto store Start ? Auto store Please wait Prog. found Frequency Manual store Manual store Start ? Prog.

  • Page 9: Mechanical Instructions

    TPS 1.0A LA 4. Mechanical Instructions 4. Mechanical Instructions Step 2. Remove the Back cover and SHIELD-MAIN as Fig.4~5. Remove the 4 screws, then r emove the back cover as Fig.4 Index of this chapter: b. Remove the 5 screws , then remove SHIELD-MAIN as Fig.5. 4.1 Assy/Panel Removal 4.2 Set Re-assembly 4.1 Assy/Panel Removal...
  • Page 10 TPS 1.0A LA 4. Mechanical Instructions Fig.7 Fig.10 Step 5. Remove Front bezel assy and LVDS cable as Fig.8~9. Remove the LVDS cable as Fig.8. Insulation material b. Remove the Front bezel assy as Fig.9. 4.2 Set Re-assembly To re-assemble the whole set, execute all processes in reverse order.

  • Page 11: Service Modes, Error Codes And Fault Finding

    TPS 1.0A LA 5. Service Modes, Error Codes and Fault Finding 5. Service Modes, Error Codes and Fault Finding index of this chapter: 5.1 CSM 5.2 Factory Mode 5. 3 Repair Flow Chart 5.1 CSM It can display CSM windows message when press 1-2 3-6 5-4 on the button (RC) remote control in normal operation mode. The following information is displayed on screen: CSM Item Contents...
  • Page 12 TPS 1.0A LA 5. Service Modes, Error Codes and Fault Finding 5.2 Factory Mode It can enter Factory Mode 1. Press "062596+Menu" on the button (RC) remote control as Fig1 Fig 1 2.Choose F3 93 V1.77 71.1 and press"OK"button to enter factory mode as Fig 2 Fig 2 3.
  • Page 13 TPS 1.0A LA 5. Service Modes, Error Codes and Fault Finding 5.3 Repair flow chart 1.No work/LED is off Check if power switch is Replace Power switch normal Check IR board CN001 pin1=0V,pin2=3.7V, Check IR board pin3=3V,pin4=2.85V ,pin5=5V,pin6 =3.3V Check scaler board U102 pin1=14V,pin4=1.22V, pin7=16V,pin8=5V, 2.No raster/picture too...
  • Page 14 TPS 1.0A LA 5. Service Modes, Error Codes and Fault Finding 3.No picture/LED is green Check scaler board U102 Check power pin1=14V,pin4=1.22V, pin7=16V,pin8 Check circuit around Check if each regulator and working voltage eliminate short and U152,pin2=3.3V open situation pin3=5V Check if clock Replace X350 source X350...
  • Page 15 TPS 1.0A LA 5. Service Modes, Error Codes and Fault Finding 4.No TV sound Check if tuner TU201 pin11 Replace TU201 output IF signal Check U301 5.No earthphone sound Check Eliminate short and open U760 pin15=3.3V situation Check U760 pin20=HPOUTL Replace U760 pin6=HPOUTR Replace Side AV Board...
  • Page 16 TPS 1.0A LA 5. Service Modes, Error Codes and Fault Finding 6.No remote function Tty another Replace one good remote control remote control Check IR receiver 7.LED and function key poor Check circuit around control board and cable between control board and scaler board 8.No HDMI picture Invalid Change U701 writen...

  • Page 17: Wiring Diagram

    TPS1.0A LA 6. Block Diagram Block Diagram Wiring Diagram Index of this chapter: Wiring Diagram 6.2 Block Diagram 089T176E 16909 FFC CABLE 50P 295mm P0.5 CN0101 4 PIN Key Board 095T8014 10935 FP Harness 7P+3p-6P+4P 570+270mm 46507 CN921 11 PIN CN806 2 PIN 2 PIN...

  • Page 18: Block Diagram

    6. Block Diagram TPS 1.0A LA 6.2 Block Daigram Block Diagram S-07...
  • Page 19 TPS 1.0A LA 6. Block Diagram Power Management...
  • Page 20 7. Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Schematic Daigram-DC-DC Power S-01 S-01 +5V_STBY +16V U7105 L7103 35uH +16V C7118 Q7109 C7133 ON/OFF C7104 A2 C7105 A4 0.1uF ZD7103 0.1uF U7101 C7106 B3 C7107 E2 L7101 SSA34-E3 C7119 R7101 C7108 E4...

  • Page 21: Circuit Diagrams And Pwb Layouts

    7.Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Schematic Diagram-lips&Inverter I/F S-02 R7201 CN7201 C2 C7201 A4 R7202 R7203 BRIGHT_ADJ C7202 A4 R7204 Q7201 C7203 B4 BL_ADJ BC847C C7204 B4 C7201 C7202 C7205 C2 0.1uF C7206 C3 C7208 C2 C7209 C3 C7210 C3 C7211 C2...
  • Page 22 7. Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Schemtic Daigram-Tuner S-03 TU2101 C2101 C5 C2102 B6 C2103 B4 C2104 B5 C2105 B6 TV_CVBS R2102 C2102 TUNER_CVBS C2106 B5 FB2101 C2107 B6 R2104 C2103 C2104 C2108 C2 75R 1% 330P(NC) 330P(NC) C2109 C6...
  • Page 23 7.Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Schemtic Daigram-Video inputs S-04 +3V3_ESD CN2201 B1 CN2202 D1 CN2203 E7 R_PR2 R2221 47R(NC) C2227 47N(NC) PR2+ PR2+ FB2208 30R(NC) C2201 E3 G_Y2 R2222 47R(NC) C2228 47N(NC) D2206 D2207 D2208 C2202 B5 FB2209 30R(NC)
  • Page 24 7. Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Schemtic Daigram-DSUB input CN1101 C4 CN1102 C1 S-05 C1101 C5 C1102 A3 +5V_STBY VGA5V C1103 B5 C1104 B6 C1105 B7 C1106 B3 D1101 C1107 B3 C1108 B2 BAT54C C1109 C8 C1110 C8 C1111 C8 C1112 C8...
  • Page 25 7.Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Schemtic Diagram-DVI-D input S-06 +5V_STBY DVI5V D5101 BAT54C +3V3_STBY R5102 DVI_5V DDC_DVI_WP CN5101 B1 C5101 C5101 B2 D5102 0.1uF C5102 B3 R5101 R5103 R5104 BAT54C U5101 C5103 B3 DDC_WP C5104 C5 NC/NC/NC/E0/E0 C5105 C7 DDC_DVI_WP...
  • Page 26 7. Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Schemtic Daigram-MST96885LD/ALD S-07 AUOutR +3.3AVDD for AVDD_DVI AUOutR AUOutL AUOutL FB4102 VDDP Pin6, Pin12 AUOutR2 LineoutR AUOutL2 TP4102 +3V3_STBY AVDD_DVI 600R C4102 AUMONO AUMONO 10uF 50V(NC) AUR3 VDDP VDDP T POINT R AUR3 C4104...
  • Page 27 7.Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Schemtic Daigram-flash rom&sdram S-08 FB4201 +3V3_MC +3V3_MC +3V3_MQ +3V3 600R C4202 FB4202 +3V3_MQ C4203 C4204 C4205 C4201 C4206 C4207 10U 10V 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 600R C4201 A3 SPI Flash ROM C4202 A1 MDATA[0..15]...
  • Page 28 7. Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Schemtic Daigram-Key,IR compair,side I/F S-09 For Key BOARD For Compair I/F CN7302 CN7303 CN7301 B3 R7302 R7308 CN7302 A3 KEY1 R7310 KEY2 CN7303 A6 R7309 CN7304 B6 C7301 C2 R7303 63363 3P 2.0mm 63363 3P 2.0mm...
  • Page 29 7.Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Schemtic Daigram-ITV I/F S-10 Power for I-BOARD (Level 2) Video I/F for I-BOARD (Level 2) CN7402 CN7401 FB7401 CVBS_TERR_OUT +12V_ITV CN7401 A5 +5V_ITV 120R(NC) R7402 100R(NC) CVBS_VSYNC CN7402 A1 R7403 100R(NC) CVBS_HSYNC CN7403 C2...
  • Page 30 7. Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Schemtic Daigram-panel I/F S-11 S-11...
  • Page 31 7.Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Schemtic Daigram-Audio I/F S-12 YPbPr2_AU_INL R6117 10K(NC) C6132 2.2uF(NC) CN6101 C1 AUL3 CN6102 C1 CN6103 A1 C6128 R6118 C6129 C6102 B3 22P(NC) 12K(NC) 560P(NC) C6103 B4 C6104 C3 C6105 C4 YPbPr2_AU_INR R6119 10K(NC)
  • Page 32 7. Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Schemtic Daigram-Audio AMP S-13 C6237 CN6201 +16V_AUDIO 470NF 50V ROUT- ROUT+ SPROUT+ ROUT- FB6205 120R(NC) R6201 R6246 C6236 C6235 63362 2P 2.0MM 0R05(NC) 2.2? 3W 100N 25V 100N 25V AMP_STBY CN6201 A6 CN6202 A6...
  • Page 33 7.Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Layout C1101 D2 C4116 C2 C6201 B4 C7124 B2 D2207 D3 Q7102 A1 R2224 C3 R4176 B2 R6227 A5 R7402 A3 C1102 D2 C4117 C2 C6202 A4 C7125 A2 D2208 D3 Q7103 B2 R2225 D3 R4177 B2 R6228 C3 R7403 A3 C1103 D2 C4118 B2 C6203 A4 C7126 A1 D4101 C2 Q7104 B2 R2226 D3 R4179 B2 R6229 B4 R7404 A3 C1104 D2 C4119 B2 C6205 B3 C7127 A2 D5101 D1 Q7105 A1 R2227 D3 R4182 B2 R6230 B4 R7405 A3 C1105 D2 C4120 B2 C6206 B4 C7128 B2 D5102 D1 Q7106 B2 R2228 C3 R4183 B2 R6231 B4 R7406 A3...
  • Page 34 7. Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Layout(top left)
  • Page 35 7.Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Layout(top right)
  • Page 36 7. Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Layout(button left)
  • Page 37 7.Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Layout(button right)
  • Page 38 7. Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board Layout-1...
  • Page 39 7.Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Baord Layout-1(top left)
  • Page 40 7. Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board layout-1(top right)
  • Page 41 7.Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board layout-1(button left)
  • Page 42 7. Circuit Diagrams and PWB Layouts TPS 1.0A LA Scaler Board layout-1(button right)
  • Page 43 7.Circuit Diagrams and PWB Layouts TPS 1.0A LA Test Point Pin 4 - U7105 (+5V_STBY) Pin 4 - U7101 (+3V3_STBY) Pin 4 -U7106 (+5V_ITV) Pin 3 U7104 (+3V3) C2204 (PB1+) Pin 1 - D7102 (+5) Pin 3 - U7103 (+1V8 ) C2218 (SV_Y0) Pin 2 - FB7106 (PANEL_VCC) Pin 1 -FB7104 (+5V_PANEL)
  • Page 44 7. Circuit Diagrams and PWB Layouts TPS 1.0A LA Test Point C1109 (RIN+), C1110 (GIN+), R1125 (HS_RGB) R1126 (VS_RGB) R1110 (TXD), R1115 (RXD) Pin 7 –U1101 (DDC_DSUB_WP) C1111 (BIN+), C1112 (SOG) Pin 7 -U5101 (DDC_DVI_WP) R5110 (SDA_HD), R5111 (SCL_HD) Pin 1 -X4101 R4161 (KEY1), R4184 (KEY2) R4186 (SYS_RST) Pin 7 -U4104 (NVRAM_WP)
  • Page 45 7.Circuit Diagrams and PWB Layouts TPS 1.0A LA Test Point C6111 (AUL2), C6118 (AUR2) R7505 (LCK) C6110 (AUL1), C6116 (AUR1) C6108 (AUL0), C6114 (AUR0) R7506 (LDE) C6205 (AUOUTR), C6208 (AUOUTL) R6246 (AMP_VCC) R6205 (AMP_STBY) (Note: Volume = 100)
  • Page 46 7. Circuit Diagrams and PWB Layouts TPS 1.0A LA Power Board Schemtic Daigram P-01 FB903 C931 50R/3000mA L921 2200PF 500V C932 0.8uH BD901 1000uF 25V BD901 B1 GBU408 D921 C937 R941 SP20150 C933 C934 100N 50V CN901 F1 C907 R905 1000uF 25V 470uF 25V C920...
  • Page 47 7.Circuit Diagrams and PWB Layouts TPS 1.0A LA Power Board Schemtic Diagram P-02 Q811 C858 4uF7 25V PT801 +16V ZD801 +16V C828 CN801 PDR_A 100N 25V NDR_B CONN C859 4uF7 25V_NC D801 RLZ5.6B C834 BAV99 D802 +16V +16V 10pF/3KV BAV99 PDR_A R801 10K EEL-13...

  • Page 48: Power Board (P01)

    7. Circuit Diagrams and PWB Layouts TPS 1.0A LA Power Board Layout BD901 C2 J825 B1 C801 B3 J826 B1 C802 B2 J827 B2 C834 B1 J828 B3 C837 A1 J829 B2 C840 A2 J830 B2 C843 A3 J831 B2 C846 A4 J832 B3 C849 A4 J833 B1 C900 C1 J834 B3...
  • Page 49 7.Circuit Diagrams and PWB Layouts TPS 1.0A LA Power Board Layout-1 C803 B3 D802 B1 R819 B2 C804 B2 D803 B2 R821 B2 C805 B3 D804 B2 R822 B2 C806 B2 D805 B2 R823 B2 C807 B2 D806 A2 R824 B2 C808 B2 D807 B3 R825 B2 C809 B2 D808 B3 R826 B2 C810 B2 D809 B4 R827 B2...
  • Page 50 7. Circuit Diagrams and PWB Layouts TPS 1.0A LA Key Board Schemtic Daigram SW0102 SKHHAM2520-PL R0102 CN0101 B1 R0101 B3 R0102 A3 SW0101 R0103 B3 SKHHAM2520-PL R0104 C3 R0105 B3 R0101 220R SW0101 B4 SW0102 A4 SW0103 B4 SW0104 C4 CN0101 SW0103 SW0105 B4...
  • Page 51 7.Circuit Diagrams and PWB Layouts TPS 1.0A LA Key Board Layout CN0101 A1 R0101 A3 SW0101 A3 R0102 A4 SW0102 A4 R0103 A3 SW0103 A3 R0104 A2 SW0105 A2 R0105 A2 SW0106 A1 SW104 A2...

  • Page 52: Ir Board

    7. Circuit Diagrams and PWB Layouts TPS 1.0A LA IR Board Schemtic Diagram +5V_STBY CN0201 C1 C0201 C4 D0201 B3 ED0201 A3 R0201 Q0201 B3 330R Q0202 B4 Q0203 B3 LED0201 Q0204 B3 Transceiver (NC) Q0203 Q0202 R0201 A3 R0202 C4 R0203 C4 R0204 C3 BC858CG...
  • Page 53 7.Circuit Diagrams and PWB Layouts TPS 1.0A LA IR Board Layout...

  • Page 54: Alignments (Incl. Service Tools & Compair)

    TPS 1.0A LA 8. Alignments 8. Alignments Index of this chapter: 8.1 Electrical Instructions 8.2 ISP Instructions 8.3 Serial Number Definition Notes: You could adjust the LCD/TV following this chapter when the LCD/TV has the below defect. 1. Change panel. 2. Change or repair main board. 3.
  • Page 55 ComPair Note: If you encounter any problems, contact your local support desk. Introduction ComPair (Computer Aided Repair) is a Service tool for Philips 8.2.2 LVDS Tool Consumer Electronics products. and offers the following: 1. ComPair helps you to quickly get an understanding on how Support of the LVDS Tool has been discontinued.
  • Page 56 EN 56 TPS1.0A LA Personal Notes: E_06532_012.eps 131004...
  • Page 57 TPS1.0A LA EN 57 Personal Notes: E_06532_012.eps...
  • Page 58 TPS 1.0A LA 8. Alignments 8.3 Serial Number Definition BOM Code: PANEL SUPPLIER CODE LPL(LG) B Z 2 A 0 6 5 1 0 0 0 0 0 1 Serial number (6 digits) Production year/week code Service version change code BOM (bill of Material) code Site code (Production center) BZ CODE ( AR---CZECH REPUBLIC,...

  • Page 59: Circuit Descriptions,Abbriviation List, And Ic Data Sheets

    TPS 1.0A LA 9. Circuit Descriptions, Abbreviations List and IC Data Sheets 9. Circuit Descriptions, Abbreviations List and IC Data Sheets Index of this chapter 9.1 Circuit Descriptions 9.2 Abbreviations List 9.3 IC Data Sheets Circuit Descriptions 9.1.1General Description This LCD TV F3-AS2 platform supports PC analog input up to XGA panel and supports TV (RF) for all China (/93) and AP (/79 /98) systems (PAL B/G, PAL D/K, PAL I, SECAM B/G, SECAM D/K, SECAM L, SECAM L1, NTSC M), YC, CVBS, Y Pb Pr, DVI and PC signal input from SDTV to HDTV (480i/p, 576i/p, 720p, 1080i/p).
  • Page 60 TPS 1.0A LA 9. Circuit Descriptions, Abbreviations List and IC Data Sheets Pattern generator for production test - Supports OSD MUX and alpha blending capability - Supports blinking and scrolling for closed caption applications Video Plane - 2-D video deinterlacer - Edge-oriented adaptive algorithm for smooth low-angle edges - MStar 3rd Generation Advanced Color Engine (MStarACE-3) gives: Brilliant and fresh color...

  • Page 61: Abbreviation List

    9. Circuit Descriptions, Abbreviations List and IC Data Sheets TPS 1.0A LA 9.2 Abbreviations List Customer Service Mode ATSC Advanced Television Systems Committee, the digital TV standard in the USA Digital Versatile Disc EEPROM Electrically Erasable and Programmable Read Only Memory 3DNR Temporal (3D) Noise Reduction Automatic Gain Control: algorithm that controls the video input of the feature box...
  • Page 62 Scan mode where two fields are used to form one frame. Each field contains half the number of Interlaced the total amount of lines. The fields are written in "pairs", causing line flicker. Infra Red Interrupt Request LATAM Latin America Liquid Crystal Display Light Emitting Diode LG.Philips LCD (supplier) MUTE MUTE Line...
  • Page 63 9. Circuit Descriptions, Abbreviations List and IC Data Sheets TPS 1.0A LA Thin Film Transistor SRAM Static RAM STBY STandBY Sync On Green SVGA 800x600 (4:3) SVHS Super Video Home System Software SWAN Spatial temporal Weighted Averaging Noise reduction SXGA 1280x1024 TMDS Transmission Minimized Differential Signalling...

  • Page 64: Ic-Data Sheets

    9. Circuit Descriptions, Abbreviations List and IC Data Sheets TPS 1.0A LA 9.3 IC Data Sheets This section shows the internal block diagrams and pin configurations of ICs that are drawn as "black boxes" in the electrical diagrams (with the exception of "memory" and "logic" ICs). 9.3.1 IC Data Sheet-MST96885L(U4101) PIN Assignments...
  • Page 65 9. Circuit Descriptions, Abbreviations List and IC Data Sheets TPS 1.0A LA 9.3.2 IC Data Sheet-TPA3005D2PHPR...
  • Page 66 9. Circuit Descriptions, Abbreviations List and IC Data Sheets TPS 1.0A LA 9.3.3 IC Data Sheet-HY57V641620ETP(U4203)
  • Page 67 9. Circuit Descriptions, Abbreviations List and IC Data Sheets TPS 1.0A LA...
  • Page 68 TPS 1.0A LA 10.Recommended/Spare Parts List Model: 20PFL4122/93(CPT) 12NC:8670 000 27396 C4104 996500042233 CER2 1206 Y5V 10V 10U P8020 R 065G1206106A7Z C4105 996500042262 CAP CHIP 0603 100N 50V Y5V -20%+80% 065G060310437Z C4106 996500042262 CAP CHIP 0603 100N 50V Y5V -20%+80% 065G060310437Z Mechanical Parts C4107 996500042229 CAP CHIP 0603 22P 50V NPO +/-5%...
  • Page 69 TPS 1.0A LA 10.Recommended/Spare Parts List C6220 996500042403 CER 1210 10U 25V Y5V -20%+80% 065G121010627Z R2110 996500042212 RST CHIPR 0 OHM +-5% 1/10W 061G0603000 C6221 996500042403 CER 1210 10U 25V Y5V -20%+80% 065G121010627Z R2113 996500042212 RST CHIPR 0 OHM +-5% 1/10W 061G0603000 C6222 996500042259 CAP CHIP 0603 100P 50V NPO +/-5% 065G060310131J...
  • Page 70 ZD1101 996510002526 DIODE BZX84-C5V6 SOT-23 VISHAY 093G 39S901 T R7208 996500042214 RST CHIPR 10 KOHM +-5% 1/10W 061G0603103 ZD1101 996500044282 DIODE BZX84-C5V6 SOT-23 PHILIPS 093G 39S911 T R7209 996500042664 RST CHIPR 47 OHM +-5% 1/10W 061G0603470 ZD1102 996510002526 DIODE BZX84-C5V6 SOT-23 VISHAY...
  • Page 71 C900 996510002733 Y1 CAP 470PF +10% 250V AC KX 065G306K4712BM ZD7402 996510002526 DIODE BZX84-C5V6 SOT-23 VISHAY 093G 39S901 T ZD7402 996500044282 DIODE BZX84-C5V6 SOT-23 PHILIPS 093G 39S911 T C901 996500043824 Y1 CAP 470pF +10% 250VAC CD SERIES 065G306K4712B3 ZD7403 996510002526 DIODE BZX84-C5V6 SOT-23 VISHAY...
  • Page 72 996510004358 DIODE BYV26EGP 1A 1000V DO-41 093G110090152T D910 996500043412 DIO SIG SM BAV103 (VISH) R 093G 64901 T D910 996500043413 DIODE BAV103 SOD-80C PHILIPS 093G 52S900 T D911 996500043412 DIO SIG SM BAV103 (VISH) R 093G 64901 T D911 996500043413 DIODE BAV103 SOD-80C PHILIPS...

  • Page 73: Revision List

    Revision List TPS1.0A LA EN 73 11. Revision List Manual xxxx xxx xxxx.0 • First release. Manual xxxx xxx xxxx.1 • 20PFL4122/79/98 release. Manual xxxx xxx xxxx.2 • 20HF4005/93 release.

This manual is also suitable for:

20pfl4122/9320pfl4122/9820hf4005/93

Table of Contents
