ViewSonic
DLP Projector
PJD6220
PJD6220-3D
PJD6230
PJD6240
IMPORTANT: Please read this User Guide to obtain important information on
installing and using your product in a safe manner, as well as registering your
product for future service. Warranty information contained in this User Guide will
describe your limited coverage from ViewSonic Corporation, which is also found
using the Regional selection box in the upper right corner of our website.
"Antes de operar su equipo lea cuidadosamente las instrucciones en este manual"
®
- User Guide
- Guide de l'utilisateur
- Bedienungsanleitung
- Guía del usuario
- Guida dell'utente
- Guia do usuário
- Användarhandbok
- Käyttöopas
-
-
Model No. : VS11949
VS11986
VS11990
Advertisement
Table of Contents
Related Manuals for ViewSonic PJD6220
Summary of Contents for ViewSonic PJD6220
- Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found using the Regional selection box in the upper right corner of our website.
- Page 2 Notes on the AC Power Cord AC Power Cord must meet the requirement of countries where you use this projector. Please confirm your AC plug type with the graphics below and ensure that the proper AC Power Cord is used. If the supplied AC Power Cord does not match your AC outlet, please contact your sales dealer.
-
Page 3: Table Of Contents
Remote Control ...7 Installing the Batteries... 8 Remote Control Operation ... 9 Installation ... 10 Connecting the Projector...10 Powering On/Off the Projector ... 11 Adjusting the Projector ... 12 Menu Operation ... 14 Network Control... 20 Maintenance... 31 Cleaning the Lens ... 31 Cleaning the Projector Housing ... -
Page 4: Compliance Information
If the batteries, accumulators and button cells included with this equipment, display the chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal content of more than 0.0005% Mercury or more than, 0.002% Cadmium, or more than 0.004% Lead. ViewSonic PJD6220/PJD6220-3D PJD6230/PJD6240... -
Page 5: Important Safety Instructions
ViewSonic PJD6220/PJD6220-3D PJD6230/PJD6240... -
Page 6: Declaration Of Rohs Compliance
0.4% lead by weight and as a cooper alloy containing up to 4% lead by weight. ViewSonic Proposed Maximum Actual Concentration Concentration 0.1% 0.1% 0.01% 0.1% 0.1% 0.1% PJD6220/PJD6220-3D < 0.1% < 0.1% < 0.01% < 0.1% < 0.1% < 0.1% PJD6230/PJD6240... -
Page 7: Copyright Information
VESA. PS/2, VGA and XGA are registered trademarks of International Business Machines Corporation. Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 8: Introduction
Introduction Projector Features The projector integrates high-performance optical engine projection and a user - friendly design to deliver high reliability and ease of use. The projector offers the following features: Single chip 0.55" Texas Instruments DLP XGA (1024 x 768 pixels) Auto image re-sizing (Auto-Sync.) to 1024 x 768 full screen with scaling... -
Page 9: Package Contents
Package Contents When you unpack the projector, make sure you have all these components: Projector with Lens Cap Composite Video Cable User’s Manual Save the original shipping carton and packing material; they will comein handy if you ever to ship your unit. For maximum protection, repack your unit as it was originally packed at the factory. -
Page 10: Projector Overview
Projector Overview Front View Lens cap Elevator button Lens cap strap Projection lens Front IR remote control sensor Ventilation holes ViewSonic AC power socket Speaker Control panel Zoom ring Focus ring Lamp cover PJD6220/PJD6220-3D PJD6230/PJD6240... -
Page 11: Rear View
Rear IR remote control sensor Ventilation holes Bottom View Elevator foot Ceiling mount (M4 x L7.5mm) Tilt-adjustment foot This projector can be used with a ceiling mount for support. The ceiling mount is not included in the package. ViewSonic PJD6220/PJD6220-3D PJD6230/PJD6240... -
Page 12: Using The Product
Enter Enter to sub-menu and confirm the menu selection. Activate in Color Setting, Lamp Counter Reset and Factory Default menu operations. Resync Resynchronize the projector to the input signal from a computer. Power Turn the projector on or off. Menu Display or exit the on-screen display menus. -
Page 13: Connection Ports
Connect image input signal (analog RGB or component) to this jack. Computer In Connect image input signal (analog RGB or component) to this jack. RS-232 When operating the projector via a computer, connect this to the controlling computer's RS-232C port. S-Video Connect S-Video output from video equipment to this jack. -
Page 14: Remote Control
Source Manually select an input source. Right (Computer mode only) Act as mouse right button. This function is only available when the projector is connected to a compute r via a USB cable. Enter Confirm the selection. Freeze Press "Freeze" to pause the screen image. -
Page 15: Installing The Batteries
Do not dispose of the used batteries along with household waste. Dispose of used batteries according to local regulations. Danger of explosion may happen if batteries are incorrectly replaced. Replace only with the same type recommended by the manufacturer. ViewSonic PJD6220/PJD6220-3D PJD6230/PJD6240... -
Page 16: Remote Control Operation
Do not drop the remote control or jolt it. Keep the remote control out of locations with excessively high temperature or humidity. Do not get water on the remote control or place wet objects on it. Do not disassemble the remote control. ViewSonic PJD6220/PJD6220-3D PJD6230/PJD6240... -
Page 17: Installation
The figure above is a sample connection. This does not mean that all of these devices can or must be connected simultaneously. The cables that come with the projector may differ from the above illustration. The included cables are based on actual shipment delivery. -
Page 18: Powering On/Off The Projector
When the Lamp LED begins flashing, the projector has entered stand-by mode. If you want to turn the projector back on, you must wait until the projector has completed the cooling cycle and has entered stand-by mode. Once in stand- by mode, simply press Disconnect the AC power cord from the electrical outlet and the projector. -
Page 19: Adjusting The Projector
Adjusting the Projector Adjusting the Projector Height The projector is equipped with an elevator foot to adjust the image height. To raise or lower the image: To raise or lower the image, press the elevator button and raise or lower the front of the projector. -
Page 20: Adjusting Projection Image Size
Position the projector in a horizontal position; other positions can cause heat build-up and damage to the projector. Make sure the heat ventilation holes are not blocked. Do not use the projector in a smoky environment. Smoke residue may cause build-up on critical parts (i.e. DMD, lens assembly, etc.) ViewSonic 74.94... -
Page 21: Menu Operation
Menu Operation The projector has multilingual on-screen display menus that allow you to make image adjustments and change a variety of settings. PJD6220/PJD6220-3D ViewSonic PJD6230/PJD6240... - Page 22 PJD6220-3D Function The projector has different menu and compatibility modes for 3D function as below. Menu 3D Sync - Auto: Auto 120Hz detection. - On: Enable120Hz - Off: Disable 120Hz 3D Sync Invert - On: Invert left and right frame contents.
- Page 23 To exit OSD, press the Menu button the remote control again. The OSD menu will close and the projector will automatically save the new settings. Picture (Computer / Video Mode) Brightness Brighten or darken the image.
- Page 24 Menu Position Choose the menu location on the display screen. Projection Adjust the picture to match the orientation of the projector: upright or upside-down, in front of or behind the screen. Invert or reverse the image accordingly. Signal Type Specify the source to the Computer In terminal that you wish to project.
- Page 25 Display the lamp’s elapsed operating time (in hours). Lamp Counter Reset Reset the lamp counter to 0 hours. Power Saving If no operation is performed for a specific period of time, the power to the projector is automatically turned off. Auto Source Automatically scan the input source.
- Page 26 Select either RS232 or LAN for network control. If RS232 is selected, user will not able to control the projector via LAN network and vice versa. Network Config DHCP Enable: Assign an IP address to the projector from the DHCP server automatically. Disable: Assign an IP address manually. IP Address Select an IP address.
-
Page 27: Network Control
A. Auto IP address setting (DHCP): 2. Please wait for the PC server to release IP address to the projector. DHCP icon will pop up on the bottom right corner, once the IP address is received by the projector. (It will take approx. - Page 28 2. Select “Intel Protocol (TCP/IP)” and click “Properties”. 3. Set your IP address on your computer, and click OK. “Use the following IP address” IP address: 10.0.50.105, (set the last number different to the projector IP address). Subnet mask: 255.255.0.0 ViewSonic...
- Page 29 Authority on the network control of Administrator & User: Item Show current projector status and network Status Date & Time Setting Date & Time setting by user. Control Panel Control the projector via network. Network Alert Setting Schedule ViewSonic Description Administrator User × × × × PJD6220/PJD6220-3D PJD6230/PJD6240...
- Page 30 Enter “http://10.0.50.100/” into the address bar of the web browser and press “Enter” key or click “Go” button. If the administrative and user password is disabled, it will directly go into the Status page. If the Administrative & User password is enabled Select your User Name and enter password to login. PJD6220/PJD6220-3D ViewSonic PJD6230/PJD6240...
- Page 31 Show time set on current projector. * when system status shows “Inactive”, it could either mean the projector is “Power Off”, or projector’s network control is set to be RS232 (Please refer to Network Control, Page 18 to link with the project).
- Page 32 Time Setting Update time setting on the projector. Click “Enter” button to save the settings. Show projector name on the current projector. Projector Name Power On or Power Off the projector via network. Power Select input source. Input Source Picture Brightness Adjusts the brightness setting.
- Page 33 Signal Type Selects the signal type setting. Filter Mode Power Saving Selects the power saving setting. Start-up Screen Selects the start-up screen setting. Closed Caption Selects the closed caption setting. Blank screen Enable or disable blank function. ViewSonic PJD6220/PJD6220-3D PJD6230/PJD6240...
- Page 34 Network Item Network DHCP Assign an IP address to the projector from the DHCP server automatically. Manual Assign an IP address manually. IP Address Setup IP address when DHCP is disable. Subnet Mask Setup subnet mask when DHCP is disable.
- Page 35 Setup the sender e-mail address. (Max length: 40 characters) SMTP Setting To enter the SMTP server (Mail server) name of the company. Server For example: mail.viewsonic.com (Max length: 30 characters) User Name Enter user name of the sender’s e-mail account. (Max length: 20 characters) Password Enter password of the sender’s e-mail account.
- Page 36 The schedule function is divided into two scheduling categories, as shown below: Weekly Schedule: Click “Submit” button to create new schedule. To delete schedule, click “Cancel”. Click “Submit” button to create new schedule. To delete schedule, click “Cancel”. PJD6220/PJD6220-3D ViewSonic PJD6230/PJD6240...
- Page 37 Logout: PJD6220/PJD6220-3D ViewSonic PJD6230/PJD6240...
-
Page 38: Maintenance
Maintenance The projector needs proper maintenance. You should keep the lens clean as dust, dirt or spots will project on the screen and diminish image quality. If any other parts need replacing, contact your dealer or qualified service personnel. When cleaning any part of the projector, always switch off and unplug the projector first. -
Page 39: Replacing The Lamp
The inorganic mercury is involved in the lamp. If the lamp bursts, the mercury inside the lamp will go out of the projector. Leave the area immediately if the lamp shatters while being operated and ventilate the area for at least 30 minutes in order to avoid the inhalation of mercury fumes. - Page 40 Insert the new lamp module into the projector and tighten the screws. Replace the lamp cover and tighten the screw. Turn on the projector. If the lamp does not turn on after the warm-up period, try reinstalling the lamp. Reset the lamp hour. Refer to the “Setting” menu.
-
Page 41: Specifications
Lens Manual Zoom (1.1x) Screen Size 30” – 250” Lamp PJD6220: 180W; PJD6230: 200W; PJD6240: 260W Input / Output Source D-Sub 15 pin, S-video, composite video, USB, RS-232, Audio In, Audio Out, LAN (RJ-45 connector) Speaker 10 W (5W x 2) Video Compatibility NTSC 3.58, NTSC4.43... -
Page 42: Appendix
Change the lamp. If the lamp is off, then the ballast will become malfunction. Solid The projector is shutting and the fan motor is Solid cooling the lamp for shutdown. Do not unplug the power cord or turn the power off before the Lamp LED changes to flashing. -
Page 43: Rs-232 Command And Configuration
BE, EF, 02, 06, 00, E9, D3, 30, 00, 00, 00, 00, 00 Response Comment Up (for OSD) Command Send String BE, EF, 02, 06, 00, 6D, D2, 34, 00, 00, 00, 00, 00 Response Comment ViewSonic Comment PJD6220/PJD6220-3D PJD6230/PJD6240... - Page 44 Keystone Down Command Send String BE, EF, 03, 06, 00, 23, DB, 66, 00, 00, 00, 00, 00 Response Comment Image Command Send String BE, EF, 03, 06, 00, F2, DA, 67, 00, 00, 00, 00, 00 Response Comment ViewSonic PJD6220/PJD6220-3D PJD6230/PJD6240...
- Page 45 BE, EF, 03, 06, 00, 6B, DA, 6E, 00, 00, 00, 00, 00 Response Comment Lamp Hour Command Send String BE, EF, 03, 06, 00, BA, DB, 6F, 00, 00, 00, 00, 00 Response Lamp Hour Comment ViewSonic PJD6220/PJD6220-3D PJD6230/PJD6240...
- Page 46 BE, EF, 03, 19, 00, 19, 29, 01, 47, 02, CC, CC, 00 Response Comment Change to YcbCr Channel Command Send String BE, EF, 03, 19, 00, 89, E8, 01, 47, 02, CC, CC, 00 Response Comment ViewSonic PJD6220/PJD6220-3D PJD6230/PJD6240...
- Page 47 BE, EF, 03, 19, 1E, 90, 72, 01, 47, 02, CC, CC, 00 Response Comment * The output effects of Change to YcbCr Channel Command and Change to HDTV(Y-Pb-Pr) Channel Command are the same as that of Change to Computer1 (Analog RGB) Channel Command. ViewSonic CTSZ RSTZ PJD6220/PJD6220-3D PJD6230/PJD6240...
-
