- Page 1 VA550 ViewPanel ® User Guide Guide de l’utilisateur Bedienungsanleitung Guía del usuario Istruzioni per l’uso Guia do Usuário Bruksanvisning Руководство для пользователя With Landscape & Portrait Display Modes Full 15.0" Diagonal Viewable Screen...
-
Page 2: Table Of Contents
Quick Installation ...4 Using the ViewPanel Setting the Timing Mode ...5 Adjusting the Screen Image ...6 Specifications ...11 Troubleshooting...12 Customer Support ...13 Cleaning the ViewPanel ...14 Limited Warranty ...15 Appendix Safety Guidelines ...16 Compliance Information ...17 CE Conformity ...17 ViewSonic VA550... -
Page 3: Product Registration
NERGY Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this mate- rial, or the performance or use of this product. -
Page 4: Getting Started
Package Contents Your VA550 package includes: • VA550 ViewPanel • Setup Guide • Power cords • Video cable • AC/DC Adapter • ViewSonic Wizard CD-ROM (including user guide PDF file and INF/ICM display optimization files) . Important! ® ViewSonic VA550... -
Page 5: Quick Installation
VA550 INF file. ViewSonic 4 Install display optimization files (INF and ICM files) ® (1) Insert the ViewSonic Wizard CD-ROM into your computer’s CD-ROM drive. NOTE: If your computer does not have a CD-ROM drive, see Customer Support in this user guide. -
Page 6: Using The Viewpanel
Do not set the graphics card in your computer to exceed the WARNING: maximum refresh rate of 75Hz; doing so may result in permanent damage to your ViewPanel. controls (pages 8 - 10) to adjust ® ® VESA 1024 x 768 @ 60 Hz desktop > Properties > ® ViewSonic VA550... -
Page 7: Adjusting The Screen Image
Adjusting the Screen Image Use the buttons on the front control panel to display and adjust the OnView controls from ViewSonic the next page and are further explained in the menu controls, pages 8 - 10. ViewSonic ® . The controls are explained in the steps at the top of VA550 ®... - Page 8 (The black border around the edge of the screen should barely touch the illuminated "active area" of the ViewPanel ® • Adjust FINETUNE so that the screen image looks focused, crisp, and sharp. to scroll up or down or down buttons. ViewSonic VA550...
- Page 9 Preset 1— for a colder, more blue image. Preset 2— for a warmer, more red image. RGB — Individual adjustments for red, green, and blue. ViewSonic automatically centers and sizes the screen image. users) start from the Windows desktop. ®...
- Page 10 Fine Tune automatically centers, sizes and fine tunes the video Auto Sync signal to eliminate noise and distortion. adjusts the width of the screen image. moves the screen image left or right. moves the screen image up or down. ViewSonic VA550...
- Page 11 1024 x 768 and the refresh rate is 60 Hertz. Language and control screens. Recall the monitor is operating in a factory preset mode (page 11). To return all controls to factory settings, press Exception: This control will not affect changes made with the RGB color control.
-
Page 12: Specifications
Warning: Do not set the graphics card in your computer to exceed these refresh rates; doing so may result in permanent damage to the ViewPanel. Macintosh computers older than G3 require a ViewSonic contact ViewSonic. 15" (full 15" viewable diagonal area), TFT (Thin Film Tran- sistor), Active Matrix XGA LCD, 0.297 mm pixel pitch... -
Page 13: Troubleshooting
Loose or broken pins in the cable connector could cause an improper connection. • Connect the ViewPanel to another computer. • If you have an older graphics card, contact ViewSonic adapter. Control buttons do not work •... -
Page 14: Customer Support
ViewSonic VA550... -
Page 15: Cleaning The Viewpanel
® cleaners on the ViewPanel screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the ViewPanel. ViewSonic will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners. ViewSonic ®... -
Page 16: Limited Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components. -
Page 17: Appendix
L or coloured RED. If you have any questions concerning which proper power cord to use, please consult with the dealer from whom you have purchased the product. ViewSonic Switzerland ... SEV Britain ... BASE/BS Japan ... Electric Appliance Control Act... -
Page 18: Compliance Information
Install and use the equipment according to the instruction manual. CE Conformity The device complies with the requirements of the EEC directive 89/336/EEC as amended by 92/31/EEC and 93/68/EEC Art.5 with regard to "Electromagnetic compatibility", and 73/ 23/EEC as amended by 93/68/EEC Art.13 with regard to "Safety". ViewSonic VA550... - Page 19 NOTE ViewSonic VA550...
- Page 20 ViewSonic Corporation 381 Brea Canyon Road Walnut, CA 91789 Tel (909) 869-7976 Tel (800) 688-6688 Fax (909) 468-1202...
