Parts Identification - Kinetico 2020c Installation Instructions Manual

Parts Identification

Owners Manual
Installation
Instructions
Softener Assembly
Includes:
control module
main and remote tanks
tank connectors
connector bracket
connector bracket pins
located inside cabinet models:
2020c
206c
208c
2040c
2050c
Safety
Read / Review
Read all steps, guides and rules
carefully before installing and using
the Kinetico Filter System.
Soldering
Use a scorch pad to protect any
surface that may be exposed to a
torch flame or excessive heat.
Use only LEAD FREE solder.
Mach Control Valve
2040c
2050c
2040s OD
2030s
2060s
2100s
2175s
2060s OD
2100s OD
CP 213s OD
CP 216s OD
4060s OD
Included with these systems:
Inlet / Outlet Adapters
Adapter E-clips
Inlet / Outlet O-rings
Chemical Care
Close or remove PVC containers and
other flammable materials to prevent
fire or
explosions.
Provide proper
ventilation when
using PVC
cleaner or glue.
Grounding
When installing a plastic component,
install grounding straps BEFORE the
lines are actually cut to ensure that the
ground is never broken.
Classic Control Valve
2020c
CC 206c
CC 208c
Q227c
Q 237
2050s
Included with these systems:
Inlet / Outlet Adapters
Adapter Bracket Pin
Adapter Bracket
Inlet / Outlet O-rings
Eye Protection
Wear protective eyewear while
installing to prevent potential eye injury
that could be caused by splattering
soldering materials or metal/plastic
shavings.
Natural Reach
Use a ladder for all work overhead
beyond your natural reach. If working
continuously at a height of six feet or
more, employ the appropriate safety
devices.
2
Brine Tank
Drain Line Tubing
Brine Line Tubing
Brine Valve
Cabinet, standard,
commercial
