Uniden EXP91 Operating Manual

Uniden EXP91 Operating Manual

900-mhz cordless phone with voice scramble
Hide thumbs Also See for EXP91:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual

Important Safety Instructions

When using your telephone equipment, basic safety precautions
should always be followed to reduce the risk of fire, electrical
shock, and injury to persons, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not
use liquid cleaners or aerosol cleaners. Use a dry cloth for
cleaning.
4. Do not use this product near water; for example, near a sink or
in a wet area.
5. Do not place this product on an unstable cart, stand, or table.
The telephone may fall, causing serious damage to the unit.
6. To protect the product from overheating, do not block or cover
any slots or openings in the Base Unit. This product should
never be placed near or over a radiator or heat register. This
product should not be placed in a built-in installation unless
proper ventilation is provided.
7. This product should be operated only from the type of power
source indicated on the marking label.
8. Do not allow anything to rest on the power cord. Do not locate
this product where the cord will be damaged by persons walking
on it.
9. Do not overload wall outlets and extension cords, as this can
result in the risk of fire or electrical shock.
10. Never push objects of any kind into this product through the
Base Unit slots, as they may touch dangerous voltage points or
short out parts that could result in a risk of fire or electric shock.
Never spill liquid of any kind on the product.
11. To reduce the risk of electric shock, do not disassemble this
product. Contact qualified service personnel when some service
or repair work is required. Opening or removing covers may
expose you to dangerous voltages or other risks. Incorrect
reassembly can cause electric shock when the appliance is
subsequently used.
1

Advertisement

Table of Contents
loading

Related Manuals for Uniden EXP91

Summary of Contents for Uniden EXP91

  • Page 1: Important Safety Instructions

    5. Do not place this product on an unstable cart, stand, or table. The telephone may fall, causing serious damage to the unit. 6. To protect the product from overheating, do not block or cover any slots or openings in the Base Unit. This product should never be placed near or over a radiator or heat register.
  • Page 2 If the product exhibits a distinct change in performance. 13. Do not use the telephone to report a gas leak in the vicinity of the leak. To reduce the risk of fire or injury to persons by the battery, read and follow these instructions: 1.

  • Page 3: Introduction

    Code™ digital security which automatically selects one of over 65,000 digital security codes for the Handset and Base Unit. Also, the AutoSecure™ feature electronically locks your phone when the Handset is in the Base. To get the most from your EXP91, please read this Operating Guide thoroughly. Introduction...

  • Page 4: What's Included With Your Exp91

    What’s Included with Your EXP91 EXP91 Base EXP91 Handset Rechargeable Battery AC Adapter Long Telephone Cord Short Telephone Cord Operating Guide If any of these items are missing or damaged, contact your place of purchase.

  • Page 5: Installation

    Selecting the Installation Location Select a location for the EXP91 to avoid excessive heat or humidity (as in a kitchen or bathroom). The Base Unit of your EXP91 can be placed on a desk or tabletop near a standard 120V AC outlet and telephone line jack, mounted on a standard AT&T or GTE wall...

  • Page 6: Setting The Dial Mode Switch

    9V DC input jack on the Base Unit. Note: Place the AC adapter cord inside the molded strain-relief. 2. Plug one end of the long telephone cord into the TEL LINE jack on the Base Unit. AC ADAPTOR SEE OWNER'S MANUAL 93tnpls AC ADAPTOR...
  • Page 7 5. Plug the AC Adapter into a standard 120V AC wall outlet. Note: Use only the AC Adapter supplied with the EXP91. Place the telephone and power cords where they will not create a trip hazard, or where they could become chafed and create a fire or other electrical hazards.

  • Page 8: Wall Installation

    Wall Installation Setting the Handset Retainer 1. Remove the Handset Retainer on the Base Unit by sliding it upward. 2. Flip the Retainer over so the tab is facing up. 3. Slide the Retainer back into the Base Unit. 900MHz 93tab1 900MHz 93tab2...
  • Page 9 Mounting on a Standard Wall Plate The EXP91 is designed to be mounted on a standard AT&T or GTE wall plate. 1. Plug the AC Adapter into the Base Unit. 2. Place the AC Adapter cord inside the left channel cord holder.
  • Page 10 6. Plug the AC Adapter into a standard 120V AC wall outlet. Note: Use only the AC Adapter supplied with the EXP91. Route the power cord where it will not create a trip hazard, or where it could become chafed and create a fire or other electrical hazards.
  • Page 11 Mounting Directly on a Wall If you do not have a standard wall plate, you can mount the EXP91 directly on a wall. Before mounting your cordless telephone, consider the following: Select a location away from electrical cables, pipes, or other items behind the mounting location that could cause a hazard when inserting screws into the wall.
  • Page 12 3. Place the AC Adapter cord inside the left channel cord holder. 4. Plug one end of the long telephone cord into the TEL LINE jack on the Base Unit. 5. Place the telephone cord into the right channel cord holder.
  • Page 13 8. Plug the AC Adapter into a standard 120V AC wall outlet. Note: Use only the AC Adapter supplied with the EXP91. Route the telephone and power cords where they will not create a trip hazard, or where they could become chafed and create a fire or other electrical hazards.

  • Page 14: Installing The Battery Pack

    Note: The built-in Memory Backup feature allows up to 3 minutes after disconnecting the old Battery Pack to install a new one without losing any phone numbers that may be stored in the telephone’s memory. To install or replace the rechargeable battery in your phone, follow these steps: 1.

  • Page 15: For Optimum Battery Performance

    For optimum battery performance: Charge the new battery overnight before using your phone. Do not let the battery become fully discharged. Be sure to return the Handset to the base at night. Charging the Handset Place the Handset on the base to charge. Low Battery Indicator When the Battery Pack in the Handset is low and needs to be...

  • Page 16: Operating Instructions

    When the Handset Is off the Base 1. When the EXP91 rings, pick up the Handset and press any key. 2. The talk LED will light, indicating a connection has been made. 3. After you are finished with your conversation, press the button to hang up.

  • Page 17: Using The Flash Button

    Using the Flash Button to send a timed hook-flash for accessing services such as call waiting, etc. Press the button on the Handset during your conversation. Using the Redial Button button dials the last number that you called. Press . The last number called is dialed again. Note: If any other key is pressed before redial the last number.

  • Page 18: Storing A Mixed Tone/Pulse Numbers

    Dialing a Stored Number To dial a number stored in memory, press and the memory location (0-9). Your EXP91 will dial the stored number. Note: If you select a memory location that does not have a stored number, the Handset will beep rapidly and will not dial.

  • Page 19: Erasing A Stored Number

    Erasing a Stored Number 1. Remove the Handset from the Base Unit. 2. Press twice. 3. Press the memory location number (0-9) you want to clear. You will hear a long beep confirming that you have erased the number. Using the Page Feature The Page feature sends a signal from the Base Unit to the Handset causing it to beep.

  • Page 20: Troubleshooting

    Many factors limit range, and it would be impossible to include all the variables in our rating. The Maximum Range rating of the EXP91 is meant to be used as a means of comparison against other range claims. Radio Interference Radio interference may occasionally cause interruptions in your conversations.

  • Page 21: Specifications

    General Frequency Control Modulation Operating Temperature Base Unit Transmit Frequency Power Requirements Size Weight Handset Transmit Frequency Size Weight Battery Capacity Talk Mode Standby Mode Specifications shown are typical and subject to change without notice. Specifications Phase Locked Loop -10 - 50 C 925.999 ~ 927.952 MHz (40 Channels) 9V 210mA (from AC Adapter)
  • Page 22 EXP 91 Operating Guide...
  • Page 23 Before you read anything else, please observe the following: WARNING! Uniden America Corporation DOES NOT represent this unit to be waterproof. To reduce the risk of fire, electrical shock, or damage to the unit, DO NOT expose this unit to rain or moisture.
  • Page 24 Base Controls and Indicators handset retainer - used to hold Handset in Base for wall mounting. power LED - indicates that AC power is on. in use LED - indicates the phone is in use. charge LED - indicates when the handset is charging. page/find - use to locate the handset.

  • Page 25: Handset Controls

    talk - used to answer calls keypad - touchpad keys )/tone - special access key for some phone systems mem - used to enter or recall numbers in memory flash - used to access call waiting (if available) talk/batt low - indicates when phone is in use or if the battery is low chan - used to select another channel for clearer reception (#) access key - special access key for some phone systems volume/ringer volume - set both the ringer and earphone volumes...

  • Page 26: Table Of Contents

    Installing Your EXP91 ........5...

  • Page 27: One Year Limited Warranty

    WARRANTOR: UNIDEN AMERICA CORPORATION (“Uniden”) ELEMENTS OF WARRANTY: Uniden warrants, for one year, to the original retail owner, this Uniden Product to be free from defects in materials and craftsmanship with only the limitations or exclusions set out below.
  • Page 28 Covered under one or more of the following U.S. patents: 4,511,761 4,523,058 4,797,916 5,426,690 ® ©1997 Uniden America Corporation All Rights Reserved Printed in China...
