SERVICE MANUAL
COOKING
FOR INTERNAL AND PARTNERS USE ONLY
© ELECTROLUX HOME PRODUCTS
Consumer Service - EMEA
Quality & Continuous Improvement - Technical Support
Q&CI - Technical Support
RANGE HOOD
Publication number
For internal and partners use only.
Edition: 05/2018 - Rev. 00
0
BETA
EN
599 818 562
XXX XX XX – XX Rev. XX
Advertisement
Related Manuals for Electrolux BETA EA 340 S1 BA
Summary of Contents for Electrolux BETA EA 340 S1 BA
- Page 1 RANGE HOOD BETA SERVICE MANUAL COOKING FOR INTERNAL AND PARTNERS USE ONLY © ELECTROLUX HOME PRODUCTS Publication number For internal and partners use only. Consumer Service - EMEA 599 818 562 Quality & Continuous Improvement - Technical Support Edition: 05/2018 - Rev. 00 XXX XX XX –...
-
Page 2: Table Of Contents
CONTENTS CONTENTS PURPOSE OF THIS MANUAL SAFETY ERROR! BOOKMARK NOT DEFINED. BETA RANGE HOOD ACCESSIBILITY CIRCUIT TROUBLE SHOOTING Q&CI - Technical Support 599 818 562 Rev. 00... -
Page 3: Purpose Of This Manual
1 PURPOSE OF THIS MANUAL The purpose of this Service Manual (SM) is to provide Service Engineers who are already familiar with the repair procedures of Hoods This SM will provide information on: o Hood Range o Accessesbility o Technical and functional characteristics o Trouble shooter Document Revisions Rev. -
Page 4: Safety
2 SAFETY All the work to be performed inside the appliance requires specific skills and knowledge and may only be carried out by qualified and authorised Service Engineers Before you access internal components, take the plug out of the socket to disconnect the power supply. ... -
Page 5: Beta Range Hood
BETA RANGE HOOD 3.1 Hood Features Variant 1 Control Assembly Rocker Button Light Diffuser & Candle Lamp Variant 2 Control Assembly Push Button Spot Lamp Grease Filter Blower Assembly Ducts Q&CI - Technical Support 599 818 562 Rev. 00... -
Page 6: Accessibility
4 ACCESSIBILITY 4.1 Grease Filter Assembly (GFA) 1. Slide the latch in the handle structure backwards to unsnap Grease Filter. 2. Release the Grease Filter from the slots in the left side of its frame. Perform the same steps to remove the other filters. Placing back the Grease Filter: Start with the step 2 placing the guide projections in the guide and snap the handle latch... - Page 7 Lamp Lamp Picture Procedure to access 4..3.1 Candle Lamp See subchapter 4.3.1 4.3.2 Spot Lamp See subchapter 4.3.2 Q&CI - Technical Support 599 818 562 Rev. 00...
- Page 8 4.3.1 Candle Lamp (CL) Perform chapter Unplug the power cable from the power socket Prior to touching the light bulbs ensure they are cooled down 1. Turn the bulb in anti- clockwise direction to take it out and in clockwise direction to place it back. 4.3.2 Spot Lamp (SL) Perform chapter Have work gloves to avoid the cuts when you unsnap...
- Page 9 4.4 Ducts Have work gloves to avoid the cuts. 1. Unfasten the 2* screws which secure the ducts to the wall bracket. 2. Slide down the upper duct into the below one. 3. Lift both and take the duct out 4.5 Carbon Filter Holder (CFH) Perform chapter 1.
- Page 10 2. Turn the nut anti clockwise direction to remove the ground cable and clockwise direction to place it. 3. Unfasten the two screws which secure the BA to the hood shell. 4. Pull down the BETA EA 340 S1 BA MOTOR BETA EA 340 S1 PU MOTOR BETA EB 25 MOTOR POWER(W)
- Page 11 4.7 Control Assembly (CA) Control Assembly Picture Procedure to access 4.7.1 Push Button See subchapter 4.7.1 4.7.2 Rocker Button See subchapter 4.7.2 Q&CI - Technical Support 599 818 562 Rev. 00...
- Page 12 4.7.1 Control Assembly Push Button (CAPB) Perform chapter , chapter , the step of subchapter 4.3.2 and the step of chapter Unplug the power cable from the power socket 1. Unfasten 4* screws which secure the holder of CA. 2. Pull backward and extract down. 3.
- Page 13 7. Unfasten 2* screws which secure the holder of the power connection box. 8. Unsnap to remove the power connection box holder. 9. Unfasten 1* screw to remove the cover of the power connection box. 10. Loosen 3* screws which secure the cables. 11.
- Page 14 4.7.2 Control Assembly Rocker Button (CARB) Perform chapter and chapter 1. Unsnap the Rocker Button Holder. 2. Pull out in opposite directions to separate. 3. Push the socket inside. Perform step of chapter steps of subchapter 4.7.1 4. Unfasten 4* screws which secure the holder of the CA. 5.
- Page 15 4.8 Feeder Cable Perform chapter and the step of subchapter 4.7.1 Unplug the power cable from the power socket 1. Unfasten 2* screws which secure the FC Lock to remove. 2. Loosen 3* screws which secure the FC to the connector. 3.
-
Page 16: Circuit
5 CIRCUIT Circuit Code Circuit Links Combinations Number 04808024 Push button + Spot Lamp 04808164 Rocker Button + Candle Lamp Q&CI - Technical Support 599 818 562 Rev. 00... - Page 17 5.1 Circuit of Push button + Spot Lamp Q&CI - Technical Support 599 818 562 Rev. 00...
- Page 18 5.2 Circuit of Rocker button + Candle Lamp Q&CI - Technical Support 599 818 562 Rev. 00...
-
Page 19: Trouble Shooting
6 TROUBLE SHOOTING 6.1 Blower Assembly Blower Assembly Check with voltmeter on terminal Not working with power sourcing block feeder cable (230 V) Change the feeder cable Value 230 V? Set Max motor speed on control assembly and check with voltmeter on the motor connector side control assembly black + white (230 V) - Page 20 6.2 Candle Lamp Candle Lamp Check right position of the lamps Not working with power sourcing ON Check with voltmeter on terminal Lamps works? block feeder cable (230 V) Change the feeder cable Value 230 V? Push light button on control assembly and check with voltmeter on the lamp holder (230 V) Change the control assembly...
- Page 21 6.3 Spot Lamp Spot Lamp Check with voltmeter on terminal block feeder cable (230 V) Not working with power sourcing ON Push light button on control assembly and check with voltmeter on the light connection Change the feeder cable Value 230V? on PCB (230 V) Change the control assembly Value 230 V?
- Page 22 6.4 Control Assembly Push Button CA Push Button Check with voltmeter on terminal block feeder cable (230 V) Not working with power sourcing ON Push light button on control assembly and check with voltmeter on the light connection Change the feeder cable Value 230V? on PCB (230 V) Change the control assembly...
- Page 23 6.5 Control Assembly Rocker Button CA Rocker Button Check with voltmeter on terminal block feeder cable (230 V) Not working with power sourcing ON Push light button on control assembly and check with voltmeter on the light connection Change the feeder cable Value 230V? on the terminal block (230 V) Change the control assembly...
