Important Safety Instructions

This product has been designed to assure your personal safety. Improper use
can result in potential electrical shock or fire hazards. Carefully observe and
comply with all warnings, cautions, and instructions placed on the product, or
described in this operating guide.
WARNING! — When using your telephone equipment, these basic safety
precautions should always be followed to reduce the risk of fire, electrical shock,
and injury to persons:
Instructions — Read, understand, and retain all instructions.
Warnings — Follow all warnings and instructions marked on the product.
Cleaning — Unplug this product from the wall outlet before cleaning, and use a
dry cloth, without liquid or aerosol cleaners.
Water and Moisture — Do not use this product near water; for example, near a
bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a
swimming pool.
Placement — Do not place this product on an unstable cart, stand, or table. The
telephone may fall, causing serious damage to the unit.
Ventilation — Slots and openings in the cabinet and the back or bottom are
provided for ventilation. To protect the product from overheating, these openings
must not be blocked or covered. This product should never be placed near or
over a radiator or heat register. This product should not be placed in a built-in
installation unless proper ventilation is provided.
1

Advertisement

Table of Contents
loading

Related Manuals for Uniden Axis EP100

Summary of Contents for Uniden Axis EP100

  • Page 1: Important Safety Instructions

    WARNING! — When using your telephone equipment, these basic safety precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons: Instructions —...
  • Page 2 E. If the product has been dropped or the cabinet has been damaged. F. If the product exhibits a distinct change in performance. Hazards — Do not use the telephone to report a gas leak in the vicinity of the leak.

  • Page 3: Controls And Indicators

    Internet is a huge repository of information, provided by countless millions of people, and covering every subject imaginable. Your new AXIS EP100 E-Mail Appliance allows you to tap into one of the most useful aspects of the Internet. Electronic Mail, or E-Mail for short, is a tool for sending letters and messages to people all over the world via the Internet.
  • Page 4 This Page Intentionally Blank...

  • Page 5: Getting Started

    Getting Started Unpack Your Phone Remove all the components from the box. Check the Contents Your Axis EP100 phone should contain the following items. If any of these items are missing, please contact your place of purchase. Base Unit Handset...

  • Page 6: Preparing The Phone For Use

    Preparing the Phone for Use Connect the Power Plug one end of the AC Adapter into the DC 13V In jack on the back of your EP100 Axis phone Wrap the power cord around the strain relief notch in the base. LINE...
  • Page 7 3. Plug the other end of the AC Adapter into your wall outlet. Connecting the Phone Line 1. Plug one end of the telephone cord into the Line Jack on the back of your Axis EP100 phone. LINE DC 13V IN...
  • Page 8 Installing Additional Equipment You can install additional equipment, such as an answering machine or messaging system, by connecting it to the TEL Jack on the back of your EP100 Axis phone. Plug the other end of the telephone cord into your wall jack.

  • Page 9: Final Touches

    Getting Started Final Touches Attach the Handset 1. Plug one end of the coiled Handset cord into the Handset. 2. Plug the other end of the coiled Handset cord into the Base.
  • Page 10 Getting Started Adjust the LCD Contrast Lift the LCD Panel. Move the contrast adjustment knob to change the LCD contrast.

  • Page 11: Initial Power Up

    3. The LCD is properly adjusted when you can comfortably read the screen. Initial Power Up When you first turn on the EP100, a diagnostic is performed. During the diagnostic, which lasts around 15 seconds, the screen will be blank.
  • Page 12 This Page Intentionally Blank...

  • Page 13: Setup

    The Home screen can be reached at any time by pressing the Function Key under the Note: The LCD display could look different depending on the software in your EP100 Axis phone. Calendar Ù Ú Ù Ú Use < >...

  • Page 14: Ep100 Functional Areas

    Setup EP100 Functional Areas Your EP100 Axis phone is divided into several functional areas. These are: Arrow and Select Keys These keys are used to move the cursor on the screen, or to select a message. The Arrow and Select Keys...

  • Page 15: Function Keys

    Function Keys The Function Keys are associated with the icons on the LCD screen directly above them. To select an operation represented by an icon on the LCD screen, press the Function Key below the icon. Calendar 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30...
  • Page 16 Setup The Base Unit Keypad The base unit keypad can be used to dial phone numbers when using the speaker option. The Keyboard Use the keyboard to type e-mail messages and notes.

  • Page 17: Setup Screen

    EP100 Axis phone. Setting up the Phone This section explains how to set up the phone features of your EP100 Axis phone. The features include setting the Speaker volume, entering your local area code and prefix, and turning off the LCD screen.
  • Page 18 2. Press the Function Key under 3. Press the Function Key under Exiting Phone Setup The LCD backlight automatically turns off after ten minutes if you are not using the EP100. To exit the Phone Setup Screen, press the Function Key under...

  • Page 19: Establishing E-Mail Service

    Establishing E-Mail Service This section explains how to set up the E-Mail features of your EP100 Axis phone. The features include Automatic sign-up, selecting polling times, and setting up an existing Internet provider. Setup April 7, 1997 10:55 pm Entering the E-Mail Setup Screen...
  • Page 20 To cancel any time, press the Function Key under You must fill in the personal data section in order for your EP100 Axis phone to operate properly when using the automatic sign-up feature.
  • Page 21 Enter Your Credit Card Information 1. Enter your credit card name. For Example, John Smith. 2. Press on the keyboard. 3. Enter your credit card type (AMEX, MASTER CARD, VISA). 4. Press on the keyboard. 5. Enter your credit card number. For example, 12345678901. 6.
  • Page 22 Setup Setting Up E-Mail Retrieval Times Use this feature to set up the times you want your EP100 Axis phone to automatically dial the Internet and retrieve your E-Mail. Note: 1. Press the Function Key under 2. Press the Function Key under 3.
  • Page 23 24. The Dial-up Script is a set of commands that will tell the modem in the EP100 how to dial and login to your service provider. Before you start this procedure, be sure to have the following information ready:...
  • Page 24 20. To cancel press the Function Key under Entering a Dial-up Script The Dial-up Script is a set of commands that tell the modem in your EP100 what to do. Below are examples of Dial-up Scripts that should work for most services.
  • Page 25 Default Dial-up Script: This dial-up script is provided as the default with your EP100 Axis phone. It has been tested with Flashnet, Internet America, Netcom, and GTENet. dial wait 20 CONNECT send + wait 20 ogin: send $ISPUSER wait 20 word:...

  • Page 26: More Setup Screens

    Setup Entering Advanced Setup Information Note: 1. Press the Function Key under 2. Press the Function Key under 3. Press the Function Key under 4. Press the Function Key under 5. If your service provider requires PAP or CHAP authentication, use 5.
  • Page 27 16. Use to select daylight savings time. Selecting yes will enable your Axis EP100 to automatically sense the change to Daylight Savings Time. 17. Press the Function Key under 18. To cancel, press the Function Key under...
  • Page 28 4. Press the Function Key under 5. Repeat for other dates. 6. Press the Function Key under Restarting the System You can restart the Axis EP100 phone anytime by pressing SHIFT + TAB + DEL at the same time. : < >...

  • Page 29: Home

    A typical Calendar/Notepad screen is displayed below. Note: The LCD display could look different depending on the software version in your EP100 Axis phone. Entering notes You can store up to eight lines of notes for each date on the calendar. Each line contains 23 characters.

  • Page 30: Modifying Notes

    Home 8. Press the Function Key under Modifying notes 1. Press 2. Press 3. Press 4. Press the del key to backspace and erase text. 5. Press the return key. 6. Repeat for multiple notes 7. Press the Function Key under Viewing notes 1.

  • Page 31: E-Mail

    The LCD display could look different depending on the software in your EP100 Axis phone. Reading Messages Note: The EP100 does not accept attachments to files. Only plain text will be retrieved and displayed. 1. Press to highlight a message to read.

  • Page 32: Receiving Messages

    Receiving Messages You can configure your Axis phone to automatically receive messages at certain times during the day. See E-Mail Setting Up Polling Times on page 22 for details. To manually receive your E-Mail messages: 1. Press the Function Key under 2.

  • Page 33: Delete Messages

    8. Press the Function Key under Note: Do not touch the keyboard until the EP100 is finished sending the message. Wait until the screen displays “Messages Sent” before continuing with operations. — OR — Press the Function Key under and no message will be sent.

  • Page 34: Forwarding Messages

    Do not attempt to forward extremely long E-mail messages. Long messages can fill up the EP100’s memory and cause improper operation. — OR — Press the Function Key under to select recipient.

  • Page 35: Address Book

    A typical Address Book screen is displayed below. Note: The LCD display could look different depending on the software version in your EP100 Axis phone. Viewing Addresses 1. Press the Function Key under Note: The address book will display the message “Please wait while...

  • Page 36: Modifying Addresses

    Modifying Addresses 1. Press the Function Key under 2. Press 3. Press the Function Key under 4. Press Note: 5. Type in the changes. 6. Press the Function Key under 7. Press Deleting Addresses 1. Press the Function Key under 2.

  • Page 37: Entering New Addresses

    Entering New Addresses 1. Press the Function Key under 2. Press the function Key under 3. Press on the keyboard, or use to modify. 4. Type in the changes. Press del on the keyboard to backspace over a mistake. 5. Press the Function Key under 6.
  • Page 38 Address Book This page intentionally Blank...

  • Page 39: Caller Id

    D A typical Caller ID screen is displayed below. Note: The LCD display could look different depending on the software version in your EP100 Axis phone. Call I.D. Ù Ú Ù Ú and "select" to return call and "select"...

  • Page 40: Viewing Caller Information

    Viewing Caller Information 1. Press the Function Key under 2. Press 3. Press the Function Key under Deleting Caller Information 1. Press the Function Key under 2. Press 3. Press the Function Key under 4. Press the Function Key under Adding Caller ID Information to the Address Book 1.

  • Page 41: Using Your Phone

    Press the speaker key on the base unit. Note: If your Axis EP100 phone was in the process of sending or receiving E-mail, you may not get a dial tone for approximately five seconds while the line is cleared. Any E-mail send or...

  • Page 42: Using Your Phone With Call Waiting

    Using Your Phone Using Your Phone With Call Waiting Note: You must subscribe to call waiting service from your local phone company to use this feature. 1. While talking, you hear the call waiting signal. 2. Press the hook on the Base to switch to that call. 3.

  • Page 43: Product Specifications

    Product Specifications General LCD Display: VGA-compatible with contrast adjustment. Keyboard: Full QWERTY keyboard. Operating Temperature: 10 to 40 C Storage Temperature: -40 to 100 C Humidity: Up to 90% relative, without condensation Power Requirements Voltage: 90-130 volts AC, 55-65 Hz Specifications shown are typical and subject to change without notice.
  • Page 44 Addresses...
  • Page 45 90% Master - Englarge 112% -Bleed size: 8.5 X 11 in Trim 10.75 X 8.5 AXIS EP100 Operating Guide UDZZ01750ZZ Bleed 1/8 in Top and Bottom. Right side folds into gatefold. Left saddle spine...
  • Page 46 Controls and Indicators Handset Microphone LCD Screen Numeric Keypad Handset Hook Coiled Cord Jack LCD Contrast Function Keys Speaker speaker Speaker Volume Arrow and Select Keys Base Speaker Keyboard Base Microphone...

  • Page 47: Table Of Contents

    EP100 Functional Areas ........
  • Page 48 Using Your Phone ..........41 Receiving Calls .
  • Page 49 Uniden service center for a defect or malfunction covered by this warranty, (E) used in any conjunction with equipment or parts or as part of any system not manufactured by Uniden, or (F) installed or programmed by anyone other than as detailed by the Operating Guide for this product.
  • Page 50 Covered under one or more of the following U.S. patents: 4,511,761 4,523,058 4,595,795 4,597,916 4,803,491 5,157,686 5,253,268 5,381,460 5,434,905 ® ©1997 Uniden America Corporation All Rights Reserved Printed in the Philippines...
