Associated documentation

Together with each system, the following documents are supplied providing informa-
tion that applies to ÄKTA ready XL.
In addition to the Operating Instructions, the documentation package supplied with
ÄKTA ready XL also includes detailed specifications and traceability documents.
The following table provides examples of technical specification documents that can
be found in the documentation package delivered with the product.
Document
Piping and Instrumenta-
tion Diagram
General specification
Assembly Drawing
Bill of Material
Spare Part List
Documentation for components produced by a third-party are, if existent, also inclu-
ded in the document package.
Abbrevi- Purpose/Contents
ation
P&ID Schematic overview of the process
flow, components and instruments
and the control system.
GS Technical data for the system.
AD Physical layout. Provides dimensional
data.
BOM Description of process-related compo-
nents.
SPL List of spare parts available from GE
Healthcare.
