Welcome to the world of sophisticated, early warning laser/radar
detection. You have purchased one of the most advanced laser/radar
detectors available. The LRD 6299SWS/LRD 6399SWS is a complete
integrated laser/radar detector. It responds to the X-, K-, and
Ka-SuperWideband radar guns in use today and also provides 360°
detection of the latest speed monitoring system — the laser gun. The
built-in Safety Warning System (SWS™) is capable of detecting a
hazardous warning signal transmitted on the K-band.
The LRD 6299SWS/LRD 6399SWS provides distinct visual and audio
alerts to warn you of the presence of X-, K-, and Ka-SuperWideband
radar signals as well as IR laser signals. You can drive with confidence
when you bring along the LRD 6299SWS/LRD 6399SWS.
The LRD 6299SWS/LRD 6399SWS employs Super Stalker Technology
(SST), a state-of-the-art electronic system designed to make this radar
detector invisible to all current VG-2 radar detector detectors. The
LRD 6299SWS/LRD 6399SWS also uses the new D.R.O. (Dielectric
Resonant Oscillator) and E.D.I.T. (Electronic Data Interference
Terminator) circuitry, giving more reliable performance.
We are certain that you will enjoy the LRD 6299SWS/LRD 6399SWS,
and to ensure that you get the most from its features, please read this
Operating Guide carefully before installing and operating the unit.
Feature Highlights
360° Laser Detection
Complete 4-Band Coverage
Super Wideband
K/Ka Priority
Signal Strength Meter
Visual Only Mode
Audio Only Mode
Memory Retention Feature
Introduction
Safety Warning System™
4 Alarm Tones
VG-2 Undetectable
Pulse Detection
Warning Lights
Auto Mute Mode
Self Test
City and Highway Modes
1
Advertisement
Table of Contents
Related Manuals for Uniden LRD6299SWS
Summary of Contents for Uniden LRD6299SWS
-
Page 1: Introduction
You have purchased one of the most advanced laser/radar detectors available. The LRD 6299SWS/LRD 6399SWS is a complete integrated laser/radar detector. It responds to the X-, K-, and Ka-SuperWideband radar guns in use today and also provides 360° detection of the latest speed monitoring system — the laser gun. The built-in Safety Warning System (SWS™) is capable of detecting a... -
Page 2: Speed Detection Systems
Speed Detection Systems A speed detection device (often called a radar gun) sends out either a microwave signal or beam of light. When this signal reaches its target, part of the signal is reflected or bounced back toward the emitting gun. The time required for the signal to leave the gun, bounce off an object, and return is used to determine a vehicle’s distance and speed. -
Page 3: Laser
Laser The Laser Speed Detection System, also called LIDAR (for Light Detection and Ranging), uses a laser gun that emits infrared light pulses just outside the spectrum of visible light. Each reflected pulse measures the speed of the object coming toward or going away from the laser gun. Unlike radar, the laser gun emits a very narrow beam of light, so it can pinpoint a speeding car within traffic. -
Page 4: Included With Your Radar Detector
Included with Your Radar Detector Windshield Owner’s Guide Clip Printed Fuses and Material Spare Parts Coiled Cigarette Straight Power Cord Adapter LRD 6299SWS Only LRD 6399SWS Only If any of these items are missing or damaged, contact your dealer immediately. Be sure to complete and mail the Product Registration Card. -
Page 5: Controls And Functions
DC 12V Power Input — Connect the DC power cord here. Note: Use on a Uniden® supplied power cord or its replacement. D C 1 2 V... - Page 6 LED Display — LEDs display visual alerts, signal strength, and operation mode. On-Off/Volume Control — Turns the power on and adjusts the Audio Alert volume. Speaker — Sounds audio alert. There are four different audio alert tones to distinguish each type of signal received. When you become familiar with all the distinct alert tones, you can operate the LRD 6299SWS/LRD 6399SWS just by listening, devoting your full attention to the traffic in front of you.
- Page 7 X K Ka L 1 2 3 4 5 6 X-Band Signal Indicator — A green LED lights and blinks to indicate the presence of an X-band radar signal. The blink rate increases as the radar source gets closer. A distinct audio alert is also heard.
-
Page 8: Installation
Both radar waves and IR laser light will, however, pass through plastic or glass. Before you decide where to put your radar detector, please keep in mind these two important factors: For safety, do not mount the LRD 6299SWS/LRD 6399SWS in a location where it will obstruct your driving vision. -
Page 9: Adjusting The Windshield Mounting Clip
Adjusting the Windshield Mounting Clip The metal portion of the bracket locks into the plastic portion at three different positions. These positions can be used for vehicles with different vertical angles of their windshields. The back position can be used for vehicles with windshields that are slanted back. -
Page 10: Connecting The Power
Connecting the Power The LRD 6299SWS/LRD 6399SWS is designed to operate on most 12 VDC negative ground vehicle electrical systems. The power cord provided with the unit has a cigarette lighter socket plug at one end and a small connector at the other. Insert the small connector into the jack on the side of the unit. -
Page 11: Replacing The Fuse
Replacing the Fuse The cigarette lighter plug contains a 1-ampere fuse to protect it from power surges. To replace the fuse, unscrew the top of the plug. Remove the fuse and replace it with the same type. To replace the top, push in the two metal contacts and twist into place. -
Page 12: Operation
Operation You are now ready to enjoy the convenience and security of your LRD 6299SWS/LRD 6399SWS. Please read this section of the Operating Guide carefully to familiarize yourself with the basic operation of this unit. Power On Turn the Volume control to switch on the power. When you power up the LRD 6299SWS/LRD 6399SWS, it performs a self-test of all its circuits. -
Page 13: Memory Retention Feature
Memory Retention Feature The Memory Retention Feature retains the LRD 6299SWS/LRD 6399SWS’s operational settings in memory for at least 2 days without power. When you turn on the LRD 6299SWS/LRD 6399SWS, it will be in the same mode as when you turned it off. Full Warning When the LRD 6299SWS/LRD 6399SWS detects a radar, laser, or safety warning signal, it emits a distinct warning tone and the corresponding... -
Page 14: Visual Alert Only Operation
Visual Alert Only Operation You can operate the LRD 6299SWS/LRD 6399SWS in Visual Alert Only by setting the Volume control at the minimum position in Full Alert Mode. At this setting you can barely hear the audio alert in a quiet environment. -
Page 15: City Operation
City Operation In highly populated areas, you may encounter many devices that use the same frequencies as radar signals, such as motion detectors, automatic doors, and intrusion alarms. These devices may trigger an alert called “falsing.” To filter most of the weaker signals and get the most accurate radar signal recognition, press CITY to turn on the City Mode. -
Page 16: Led Signal Strength Meter In City Mode
LED Signal Strength Meter in City Mode The LED signal strength meter gives you instant information about the strength of the signal being detected. A weak signal causes the first LED to light, but as signal strength increases, more LEDs light. All four LEDs light when full signal strength is received. -
Page 17: Care And Maintenance
Care and Maintenance The LRD 6299SWS/LRD 6399SWS is designed to give you years of trouble-free service. There are no user-serviceable parts inside, and, except for the fuse, no maintenance is required. To keep your detector in new condition, follow these important suggestions: Never leave the LRD 6299SWS/LRD 6399SWS on the windshield when you park your vehicle. -
Page 18: Troubleshooting
If your LRD 6299SWS/LRD 6399SWS does not perform up to expectations, try the suggestions listed below. If you cannot get satisfactory results, call the Uniden Customer Service Center at (800) 297-1023, 8:00 a.m. to 5:00 p.m. Central Time, Monday through Friday. -
Page 19: Specifications
Temperature Range: 360° Laser Detector Receiver Type: Sensor Front End: Detector Type: Receiver Bandwidth: Spectral Response: Alert Hold Time: Radar Detector Receiver Type: Detector Type: Antenna Type: Sensitivity: Frequency of Operation: Specifications are subject to change without notice. Specifications in. (W) x 4 3.5 oz. -
Page 20: Optional Accessories & Replacement Parts
Optional Accessories & Replacement Parts Owner’s Windshield Guide Clip Fuses and Printed Material Spare Parts Coiled Cigarette Straight Power Cord Adapter... - Page 21 ® LRD 6299SWS LRD 6399SWS Operating Guide USZZ01064ZC...
- Page 22 Important: The LRD 6299SWS/LRD 6399SWS was not designed to help you disobey the law. Safe drivers always obey the posted speed limit and legal driving methods at all times. Federal and Local Regulations The FCC passed the Communications Act in 1934 to give all citizens the right to receive any type of radio transmission.
-
Page 23: Table Of Contents
Laser ..........3 Included with Your Radar Detector......4 Controls and Functions . -
Page 24: One Year Limited Warranty
(E) used in any conjunction with equipment or parts or as part of any system not manufactured by Uniden, or (F) installed or programmed by any- one other than as detailed by the Operating Guide for this product. - Page 25 Covered under one or more of the following U.S. patents: 4,622,553 4,698,632 4,709,407 4,791,420 4,831,498 5,315,302 ® ©1996 Uniden America Corporation. All rights reserved. Printed in the Philippines...
