Watchguard Firebox T45-CW Hardware Manual

Firebox T45-CW Hardware Guide
WatchGuard Firebox is a comprehensive advanced network security platform that puts IT security professionals
back in charge of their networks with widely deployable, enterprise-grade security and threat visibility tools
suitable for any organization, regardless of budget, size, or complexity.
The Firebox T45-CW supports up to 20 users looking for intelligent network security appliances to secure small
environments such as a temporary site, branch office, or retail POS. The Firebox T45-CW features 5G cellular
and dual-band Wi-Fi 6 options built into the device that minimize disruptions to network activity.
Fireware OS
The Firebox T45-CW supports WatchGuard's next generation UTM OS—Fireware® OS. Each Firebox appliance
includes Fireware OS and delivers exceptional protection against today's sophisticated threats to make sure
that your business stays connected. For more information on the features of Fireware OS, see
Package Contents
Firebox T45-CW appliance
Quick Start Guide
1 RJ45 Ethernet cable
1 power adapter (100-240V)
1 power cord (US, AU, EU, UK)
4 external antennas
4 antenna terminal covers
About Your Hardware
Hardware Specifications
Processor NXP LS1043ASE7QQB, 1.6GHz, 4-Core
Memory DDR4 4GB
Storage M.2 SSD 16GB
Power Supply Input Ratings: 100-240V AC, 50-60Hz, 1.5A Max
Output Ratings: 12V DC, 4A, 48W
MTBF 477,304 hours
Dimensions D = 203.2 mm (8")
W = 215.9 mm (8.5")
H = 45.72 mm (1.8")
Weight 0.983 kg (2.17 lbs)
Interface Specifications
Network Interfaces
Cellular Interface
5 RJ45 connectors, 1000Base-TX (10/100/1000Mbps)
5G NR
Nano SIM card slot
Fireware Help.
