True TBB-24GAL-60G-S Specifications

2001 East Terra Lane • P.O. Box 970 • O'Fallon, Missouri 63366
(636)240-2400 • Fax (636)272-2408 • (800)325-6152 • Intl Fax# (001)636-272-7546
Parts Dept. (800)424-TRUE • Parts Dept. Fax# (636)272-9471 • www.truemfg.com
Model:
TBB-24GAL-60G-S
ROUGH-IN DATA
Model Doors
TBB-24GAL-60G-S 2
† 3
Depth does not include 1 /
8
note: Depending on tapping kit used,
T R
RUE EFRIGERATION
TM
MADE IN
U.S.A. U.S.A. .S.A.
®
SINCE 1945
1/07
TRUE FOOD SERVICE
EQUIPMENT, INC.
24" Back Bar Cooler:
Glass Door Galvanized Top Stainless Steel Exterior
Cabinet Dimensions
Capacity
12 oz.
L
Cans Shelves
7
133 4 59 /
8
6-pks
1521
"
(35 mm) for door handle and 1
1
/ barrels may not fi t.
2
APPROVALS:
R
Printed in U.S.A.
Project Name:
Location:
Item #:
Model #:
Chart dimensions rounded up to the nearest
(inches)
(mm)
†
D H
HP
1 1 1
24 / 34 / /
4 4 3
1
/
616 870 230-240/50/1
3
"
(26 mm) for rear bumpers.
Qty:
TBB-24GAL-60G-S
True's refrigerated back bar
coolers are designed with
enduring quality and value. Our
commitment to using the highest
quality materials and oversized
refrigeration assures colder
product temperatures and years
of trouble free service.
Oversized, factory balanced,
refrigeration system holds 33°F to
38°F (.5°C to 3.3°C).
Exterior - stainless steel front and
sides. Matching aluminum back.
Galvanized steel top designed to
slide under existing cabinetry.
Interior - 300 series stainless steel
1
fl oor with /
lip and heavy gauge galvanized
steel walls.
NSF approved for packaged and
bottled product.
Positive seal doors.
"Low-E", double pane thermal
glass door assemblies with
extruded aluminum frames.
The latest in energy effi cient
technology.
Patented integrated door light
(IDL) system for brighter, shadow
free illumination.
Entire cabinet structure is foamed-
in-place using high density, CFC
free, polyurethane insulation.
Specifi cations subject to change without notice.
1
/ " (millimeters rounded up to next whole
8
NEMA
Voltage Amps Confi g.
115/60/1 7.7 5-15P
▲
3.7
▲ Plug type varies by country.
AVAILABLE AT:
AIA #
SIS #
" (13 mm) reinforced
2
number).
Cord Crated
Length Weight
(total ft.) (lbs.)
(total m) (kg)
7 355
2.13 162
