Model:
TR2DT-4HS
STANDARD FEATURES
DESIGN
• True's solid door reach-in's are designed with
enduring quality that protects your long term
investment.
• Designed using the highest quality materials
and components to provide the user with colder
product temperatures, lower utility costs and
exceptional food safety.
REFRIGERATION SYSTEM
• Two independent, self contained refrigeration
systems; CFC free, environmentally friendly and
factory balanced.
• R134A refrigerator refrigerant - R404A freezer
refrigerant.
• Extra large evaporator coils balanced with higher
horsepower compressors and large condensers
maintains 33°F to 38°F (.5°C to 3.3°C) in the
refrigerator section and -10°F (-23.3°C) in the
freezer section.
• Sealed, cast iron, self-lubricating evaporator fan
motor(s) and larger fan blades give True reach-
in's a more effi cient low velocity, high volume
airfl ow design. This unique design ensures faster
temperature recovery and shorter run times in the
busiest of foodservice environments.
• Top mounted refrigeration system with evaporator
position out of food zone to maximize interior
capacity.
• Freezer automatic defrost system time-initiated,
temperature-terminated. Saves energy
consumption and provides shortest possible defrost
cycle.
• Automatic evaporator fan motor delay during
defrost cycle.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel doors, front,
sides, back and bottom.
• Interior - 300 series stainless steel liner and fl oor.
• Insulation - entire cabinet structure and solid doors
are foamed-in-place using high density, CFC free,
polyurethane insulation.
• Welded, heavy duty galvanized frame rail dipped
in rust inhibiting enamel paint for corrosion
protection inside and out.
PLAN VIEW
38
5
/
"
8
(982 mm)
3
1
/
"
16
(31 mm)
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
2001 East Terra Lane • P.O. Box 970 • O'Fallon, Missouri 63366 • (636)240-2400 • Fax (636)272-2408 • (800)325-6152 • Intl. Fax# (001)636-272-7546 • www.truemfg.com
TR Series:
Reach-In Solid Half Door Dual Temperature
Refrigerator / Freezer
• Frame rail fi tted with 4" (102 mm) diameter stem
castors - locks provided on front set.
DOORS
• 300 series stainless steel exterior and liners. Doors
open within cabinet dimensions.
• Door locks standard.
• Lifetime guaranteed recessed door handles. Each
door fi tted with 12" (305 mm) long recessed handle
that is foamed-in-place with a sheet metal interlock
to ensure permanent attachment.
• Positive seal self-closing doors with 120º stay open
feature. Lifetime guaranteed door hinges.
• Magnetic door gaskets of one piece construction,
removable without tools for ease of cleaning.
SHELVING
• One (1) factory installed interior kit option per full
section. Four (4) different interior kits available
(see Kit Options). Pilasters and tray slides are
factory installed at no charge.
LIGHTING
• Compartmentalized incandescent interior lighting
(one per section). Lights activated by rocker switch
mounted above top doors, safety shielded.
MODEL FEATURES
• Two (2) exterior digital temperature displays,
available with either °F or °C display.
• Evaporator is epoxy coated to eliminate the
potential of corrosion.
• Backguard in freezer section improves airfl ow.
• Minimum wattage heater in cabinet frame and
freezer door.
ELECTRICAL
• Unit completely pre-wired at factory and ready
for fi nal connection to a 115/208-230/60/1 phase, 3
pole, 4 wire - 20 amp dedicated outlet. Cord and
plug set included.
ELEVATION
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
TRUE FOOD SERVICE EQUIPMENT
115/208-230/1
NEMA-14-20R
1"
(26 mm)
77"
(1956 mm)
3
78
/
"
16
(1986 mm)
3
84
/
"
16
(2139 mm)
4"
5"
(127 mm)
(102 mm)
Model
KCL
TR2DT-4HS
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ 6" (153 mm) standard legs.
❒ 6" (153 mm) seismic/fl anged legs.
❒ 6" (153 mm) stainless steel legs.
❒ Stainless steel rail skirt for use with legs
(fi eld installed).
❒ Metal door handles (factory installed).
❒ Novelty baskets.
❒ Electronic temperature control (factory installed).
❒ Correctional facilities options.
❒ Curb mountable units.
❒ Remote cabinets (condensing units supplied
by others; system comes standard with 404A
expansion valve and requires R404A refrigerant).
Consult factory technical service department for
BTU information.
KIT OPTIONS
❒ Kit #1: Nine (9) sets of #1 type tray slides and
pilasters (factory installed), bottom support of one
(1) 18"L x 26"D (458 mm x 661 mm) pan or two (2)
14"L x 18"D (356 mm x 458 mm) pans.
❒ Kit #2: One (1) set half-section #2 steel rod tray
slides and pilasters (factory installed), rim support
of one (1) 18"L x 26"D (458 mm x 661 mm) pan.
❒ Kit #3: Six (6) sets of universal type tray slides and
pilasters (factory installed), bottom support of one
(1) 18"L x 26"D (458 mm x 661 mm) pan, two (2)
14"L x 18"D (356 mm x 458 mm) pans or two (2)
12"L x 20"D (305 mm x 508 mm) pans.
❒ Kit #4: Three (3) chrome shelves 21
13
28
/
"D (555 mm x 732 mm). Four (4) shelf
16
supports included per shelf (factory installed);
adjustable on 6" (153 mm) increments. Optional
wall mounted shelf support pilasters (factory
installed) with four (4) shelf clips per shelf
available; adjustable on
1
/
" (13 mm) increments.
2
❒ Additional kit option components available
individually.
51
3
/
"
8
(1305 mm)
1
19
/
"
16
(485 mm)
26
(665 mm)
PLAN VIEW
Elevation
Right
Plan
TFQA01E
TFQA01S
TFQA01P
13
/
"L x
16
60
1
/
"
2
(1537 mm)
5
/
"
32
3D
TFQA013
