- Page 1 INSTRUC TION MANUAL Model No.: B248...
-
Page 2: Safety Information
WARNING Please read the instructions carefully and follow the assembly steps. To ensure proper assembly, please follow all steps and use all parts provided. Not following this warning may result in serious injury to you or others. To prevent misalignments, keep the screws loose and do not tighten them until they are all in their correct positions. - Page 3 ASSEMBLY PARTS AND TOOL BEFORE YOU GET STARTED, A FEW POINTERS: Please open the Seat Cushion Please use the included wrench bottom and take out all accessories instead of an ELECTRIC HAND DRILL before installation. in case of damage to the chair leg. Seat Back *1 Seat Base *1 Legs *4...
- Page 4 ASSEMBLY INSTRUCTIONS Unzip the fabric cover underneath the Seat Base(2) Bottom and take out all accessories. Step 1 Connect 4 legs to the Seat Bottom. Tear off the 4 Felt Pad(8) and glue them to the bottom Step 2 of the chair legs. On a clean surface, gently turn the Seat Bottom on its side. lnsert 4 Legs(3) with 4 Flat washer Ø10/Ø48 mm(6) into the holes and tighten them.
- Page 5 ASSEMBLY INSTRUCTIONS Connect Back Cushion(1) with Seat Base(2). Put the Seat Base upright on the ground, Step 4 align the Back Cushion(1) with the Seat Base(2), and gently press the Back Cushion(1) to make it secure. Then, lay them on their side and align the 3 screw holes. Tighten the 3 screw holes by using 3 Bolt M8*50mm(4) and 3 Flat Washer Ø8/ Step 5 Ø30 mm(5), using the Wrench(7).
-
Page 6: Limited Warranty
LIMITED WARRANTY COLAMY promises to repair or replace any COLAMY chair that is found to be defective in material or workmanship within one year from the date of original purchase so long as you, the original purchaser, still owns it. This is your sole and exclusive remedy. - Page 7 LIMITED WARRANTY If the product is faulty when you receive it, please contact us and we will help you out. We reserve the right to give a partial refund in cases when the product(s) is not in an unused condition, is damaged or has missing parts, not due to our error.
- Page 8 ASSEMBLY VIDEO E-MAIL 800-507-2215 colamyhome.com support@colamyhome.com CAUTION: COLAMY DISCLAIMS ANY LIABILITY FOR DAMAGES OR INJURIES WHICH MAY OCCUR DUE TO FAILURE TO PROPERLY FOLLOW ASSEMBLY INSTRUCTIONS, PROPERLY ASSEMBLE THE PRODUCT, OR PROPERLY USE THE PRODUCT.
