Technics SH-8055 Service Manual

ORDER No. HAD85071734
Service Manual
Stereo Graphic Equalizer Equalizer
Color
({K).... Black Type
Color Area
{K) | [PA] ...Far East PX
(K)
| [PE] ... European Military
~
f Please use this manual together with the service manual for Model No. SH-8055, Order No. SD83062526C9.
J
CHANGE
Wi REPLACEMENT PARTS LIST
Notes:
(1) Mentioned in this parts list are only those changed in Model No. SH-8055 for destination [PA, PE] area (silver type).
(2) Important safety notice:
Conponents identified by A\ mark have special characteristics important for safety. When replacing any of these
components, use only manufacturer's specified parts.
Change of Parts No.
Ref. No. SH-8055
SH-8055
Part Name & Description
moet Remarks
[PA,PE] Silver Type P [PA,PE] Black Type
il
RESISTORS
R45, ERD25TJ124 ERD257TJ154 Carbon, 150kQ, 1/4w, +5% 1
R539 ERD25FJ471 ERD25FJ561 Carbon, 56092, 1/4W, 5% 1 Fig. 1
R556 a ERD25FJ472 Carbon, 4.7kQ, 1/4W, +5% 1 Fig. 1
R643~646 ERD25FJ152 ERD25FJ222 Carbon, 2.2kQ,, 1/4W, +5% | 4
CABINET and CHASSIS PARTS.
qT
SGWK210PA SGWK210BA
Front Panel
7 1
|
a SDUK8 SDUK8—1 Dial Plate 1
3 SGXK75 SGXK75-1 Ornament Cover 1
4 SGXK76 SGXK76-1 Ornament Cover 1
5 SGUK10 SGUK10—1 Transparent Plate 1
6 SGXK74 SGXK74—1 Sub Front Panel 1
8 SBD69—3K SBD69—1 Button, Display Level 1
10 SBC475—1 SBC475 Button 4
26 SKCK110S SKCK110B Cabinet i
SCREWS
N1 XTB3t+8B XTB3+8BFZ Screw, Panel M'tg. 3
Ni2 SNE2095—2 SNE2095—5 Screw, Cabinet M'tg. 4
PACKING PARTS
PI SPGK116 SPGK208 Carton Box 1
P4 'SPP699 SPPK47 Polyethylene Bag 1
