- Page 1 TECHNICAL MANUAL Simplebus2 Ultra audio module Art. UT2010 Passion.Technology.Design.
-
Page 2: Warning
• any purpose other than the intended use, • failure to observe the indications and warnings contained in this Manual / Instruction sheet. Comelit Group S.p.A. reserves the right to change the information provided in this Manual / Instruction Sheet at any time and without prior notice. -
Page 3: Table Of Contents
Removing nameplates (2A) / module (2B) ..........12 Installation with side-by-side boxes .............13 Connections ................... 14 UT2010 connections ................14 UT2010 connections with separate power supply ......14 Variants ....................14 Module connection ................ 15 Outdoor entrance panel module consumption table ......15 powered by Art. 1210/1210A ............15 powered by additional power supply unit Art. -
Page 4: Description
Description UT2010 Audio module for Ultra entrance panel, Simplebus2 system. For use in systems with power supply unit art. 1210 / 1210A. Easy to install and simple to configure, thanks to the smart programming of call buttons. Twilight sensor for automatic nameplate backlighting switch-off during daylight hours. - Page 5 3. 4. 5. 14. 15. 1. Indicator LEDs 13. Terminal block for connection: call sent (green) / system busy (red) RTE programmable RTE (local lock-release input) or DO input (door open indication) lock-release enabled GND SE- RTE and door lock input reference negative audio enabled SE+ electric door lock connection...
-
Page 6: Technical Characteristics
Technical characteristics Art. UT2010 GENERAL DATA Type Modular Product height (mm) Product width (mm) Product depth (mm) Product weight (g) Product colour Black RAL9005, Transparent, Aluminium Material Polycarbonate, Aluminium alloy Flush mounting Yes, with specific accessory Surface mounting Yes, with specific accessory... -
Page 7: Installation
Installation The entrance panel is available in flush-mounted or surface-mounted variants: Flush-mounted installation composition table 3110/1 3110/2 3110/3 3110/4 UT9181 UT9182 UT9183 UT9186 UT9189 UT9184 UT9188 A = Flush-mounted box B = Rain shield C = Flush-mounted module holder UT9161 UT9162 UT9163 UT9164... -
Page 8: Flush-Mounted Installation
Flush-mounted installation Optional Optional BLACK... -
Page 9: Removing Nameplates (2A) / Module (2B)
CLACK! CLACK! CLACK! CLACK! CLACK! CLACK! The button has a nameplate which can be written on (A); alternatively, an adhesive label can be applied (B). MAX 0,2 mm The total thickness of the nameplate + adhesive label must not exceed 0.2 mm. You can visit the website pro.comelitgroup.com to download MAX 0,2 mm the PDF to print the entrance panel name cards, using the... -
Page 10: Installation With Side-By-Side Boxes
Installation with side-by-side boxes Before installing the boxes in the wall, fit the spacers. -
Page 11: Wall-Mounted Installation
Wall-mounted installation Optional Optional BLACK... -
Page 12: Removing Nameplates (2A) / Module (2B)
CLACK! CLACK! CLACK! CLACK! CLACK! CLACK! The button has a nameplate which can be written on (A); MAX 0,2 mm alternatively, an adhesive label can be applied (B). The total thickness of the nameplate + adhesive label must not exceed 0.2 mm. MAX 0,2 mm You can visit the website pro.comelitgroup.com to download the PDF to print the entrance panel name cards, using the... -
Page 13: Installation With Side-By-Side Boxes
Installation with side-by-side boxes... -
Page 14: Connections
Connections UT2010 connections 1210A 1210 R GND NO NC UT2010 Max 20 m. Local door-opener button. UT2010 connections with separate power supply 1210A 1595 1210 120-230 V R GND NO NC UT2010 Max 20 m. Local door-opener button. Variants Variant for using the outdoor entrance panel relay... -
Page 15: Module Connection
Module connection On systems with Art. UT2010 and power supply unit Art. 1210/1210A, the maximum current available for the outdoor entrance panel modules is 100 mA. Calculate the total power consumption of the modules in your system configuration using the Consumption table. -
Page 16: Connection Of Button Modules Art. Ut9200
Connection of button modules Art. UT9200 1210A 1210 R GND NO NC BLACK UT2010 UT9200 MAX 8 Max 20 m. Local door-opener button. Max 8 modules (Max 30 modules with additional power supply). Connection of Touch-screen module Art. UT9270 Variant with separate power supply up to 80 users >... -
Page 17: Programming
Programming For correct programming, follow the instructions below in order Configure button type Address button modules III. Program call addresses Configure button type (single/dual) DIP 6: configuring button type: Single button (DIP6 ON). default Dual button (DIP6 OFF, default). DIP 6: configuring button type: Single button (DIP6 ON). -
Page 18: Smart Programming Of Consecutive Addresses
Smart programming of consecutive addresses Make sure the button configuration (single/dual) is correct before proceeding with programming (see “Configure button type (single/dual)”) S1 S2 Take note of the DIP-switch settings Set the address of the apartment you wish 1 2 3 4 to call (for example: 1) example: using the DIP-... -
Page 19: Programming Of Specific Addresses
Programming of specific addresses Make sure the button configuration (single/dual) is correct before proceeding with programming (see “Configure button type (single/dual)”) S1 S2 Take note of the DIP-switch settings Set the address of the apartment you wish to 1 2 3 4 call (for example: 25) example: using the DIP-... -
Page 20: Special Programming Via Dip-Switch
Special programming via DIP-switch S1 S2 Take note of the DIP-switch settings 1. Set the dip switches in accordance with the function you wish to program (see table). 2. Press the confirm button. S1 S2 When programming is complete, make sure the button configuration is correct (single/dual), see Reset the configuration of the... -
Page 21: Special Programming Table
Special programming table CODE DIP SWITCHES ON FUNCTIONS Audio-visual messages 1,2,7,8 Hebrew 3,7,8 Polish 1,3,7,8 Catalan 2,3,7,8 Galician 1,2,3,7,8 Basque 2,3,4,7,8 Danish 1,2,3,4,7.8 Norwegian 1,2,5,7,8 Swedish 1,2,3,5,7.8 Italian 4,5,7,8 French 1,4,5,7,8 Spanish 2,4,5,7,8 Dutch 1,2,4,5,7.8 Greek 3,4,5,7,8 English 1,3,4,5,7.8 German 2,3,4,5,7.8 Portuguese 2,4,7,8... - Page 22 Disables “awaiting reset time" on lock-release command (awaiting response time or talk time will be 1,5,7,8 activated) 1,4,5,6,7.8 Call transmission: single (default) 2,4,5,6,7.8 Call transmission: triple Button tones 2,3,4,8 Button press tone ON (default) 1,2,3,4,8 Button press tone OFF Button backlighting management 2,3,4,5,8 OFF mode: Button LEDs always off 1,2,3,4,5.8...
-
Page 23: Twilight Sensor
Twilight sensor Button backlighting management The twilight sensor is in AUTO mode by default: the button LEDs light up at night and switch off during the day. To change the setting to ON (LEDs always on) or OFF (LEDs always off), proceed as follows: S1 S2 Take note of the DIP-switch settings... -
Page 24: Checking Twilight Sensor Operation
Checking twilight sensor operation S1 S2 S1 S2 5 sec If it is daytime and you want to check AUTO mode operation for the twilight sensor, you can proceed as follows: 1. Enter programming mode 2. Block the twilight sensor for 5 seconds »... -
Page 25: Adjusting The Brightness Of The Button Leds
Adjusting the brightness of the button LEDs S1 S2 Take note of the DIP-switch settings Set the brightness control function (code 161) and press the confirm programming button. cod. 161 1 2 3 4 Press a button repeatedly for each module to change the individual brightness of the buttons S1 S2 When programming is complete, make sure the... -
Page 26: Light-Me Function
Light-me function Thanks to this function, button backlighting is only enabled on the user’s request, by pressing the LIGHT-ME button on the audio/video module; this saves energy and reduces light pollution. Backlighting management for this button depends on the twilight sensor setting. It is in AUTO mode by default: the LEDs light up at night and switch off during the day. -
Page 27: Replacing The Audio Module With Programming Restore Backup
Replacing the audio module with programming restore backup If the audio or audio/video module is replaced, the following instructions must be observed. The procedure should be completed within one hour of removal of the old module. Take note of the DIP-switch settings 1. -
Page 28: Configuring Via Pc
Configuring via PC All device configurations can be performed via PC and ViP Manager configuration software, available to download free of charge from pro.comelitgroup.com. √ You will need a USB micro-USB cable. Errors and indications INDICATION SOLUTION Line short-circuit Check connections Dual power supply present Remove jumper J4 on the audio module RED LED... -
