Lennox 97G2UHV Installation Instructions Manual

Lennox 97G2UHV Installation Instructions Manual

Warm air gas furnace upflow/ horizontal left/right air discharge direct vent & non-direct vent
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLATION INSTRUCTIONS
97G2UHV
This is a safety alert symbol and should never be ignored. When you see this symbol on labels or in manuals, be alert to
the potential for personal injury or death.
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional installer (or
equivalent), service agency or the gas supplier.
As with any mechanical equipment, personal injury can
result from contact with sharp sheet metal edges. Be
careful when you handle this equipment.
Manufactured By
Allied Air Enterprises LLC
A Lennox International, Inc. Company
215 Metropolitan Drive
West Columbia, SC 29170
508404-01
This manual must be left with the homeowner for future reference.
WARNING
CAUTION
Warm Air Gas Furnace Upflow/
Horizontal Left/Right Air Discharge
Direct Vent & Non-Direct Vent

Table of Contents

Unit Dimensions ..........................................................2
Parts Arrangement.......................................................3
Gas Furnace ................................................................4
Shipping and Packing List ...........................................4
Safety Information .......................................................4
General ........................................................................6
Installation .................................................................10
Filters .........................................................................13
Duct System ..............................................................14
Venting Practices .......................................................15
Condensate Piping ....................................................34
Gas Piping .................................................................37
Electrical ....................................................................40
Blower Performance ..................................................50
Unit Start-Up ..............................................................54
Other Unit Adjustments..............................................56
Service.......................................................................57
Repair Parts List ........................................................59
*P508404-01*
Issue 2332
(P) 508404-01
Page 1 of 60
