Electrolux VERSA Service Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
SERVICE MANUAL
COOKING
FOR INTERNAL AND PARTNERS USE ONLY
© ELECTROLUX HOME PRODUCTS
Consumer Service - EMEA
Quality & Continuous Improvement - Technical Support
Q&CI - Technical Support
VERSA Range
Publication number
For internal and partners use only.
599 8170 – 86
Edition: 04/2018 - Rev. 00
0
HOOD
EN
XXX XX XX – XX Rev. XX

Advertisement

loading

Related Manuals for Electrolux VERSA

Summary of Contents for Electrolux VERSA

  • Page 1 HOOD VERSA Range SERVICE MANUAL COOKING FOR INTERNAL AND PARTNERS USE ONLY © ELECTROLUX HOME PRODUCTS Publication number For internal and partners use only. Consumer Service - EMEA 599 8170 – 86 Quality & Continuous Improvement - Technical Support Edition: 04/2018 - Rev. 00 XXX XX XX –...

  • Page 2: Table Of Contents

    CONTENTS CONTENTS PURPOSE OF THIS MANUAL SAFETY VERSA HOOD ACCESSIBILITY CIRCUIT TROUBLE SHOOTING 599 8170 – 86 Rev. 00 Q&CI - Technical Support...

  • Page 3: Purpose Of This Manual

    1 PURPOSE OF THIS MANUAL The purpose of this Service Manual (SM) is to provide Service Engineers who are already familiar with the repair procedures of Hoods This SM will provide information on: o Hood Range o Accessesbility o Technical and functional characteristics o Trouble shooter Document Revisions Rev.

  • Page 4: Safety

    2 SAFETY  All the work to be performed inside the appliance requires specific skills and knowledge and may only be carried out by qualified and authorised Service Engineers.  Before you access internal components, take the plug out of the socket to disconnect the power supply. ...

  • Page 5: Versa Hood

    VERSA HOOD 3.1 Hood Features It's a mechanical device which situated upper the cooktop, mainly contains a Blower Assembly, Grease Filters and a Control Assembly. Control Assembly Light Diffuser & Candle Lamp Spot Lamp Grease Filter Blower Assembly Slider Slide Out Assembly Glass 599 8170 –...

  • Page 6: Accessibility

    4 ACCESSIBILITY 4.1 Grease Filter Assembly (GFA) 1. Slide the latch in the handle structure leftwards to unsnap GFA. 2. Release the GFA from the slots in the left side of its frame. Placing back the GFA: Start with the step 2 placing the guide projections in the guide and snap the handle latch Depending on the size of the hood, number of filters vary 4.2 Slide-Out Assembly (SOA)
  • Page 7 4.3 Glass Perform chapter and the first step of chapter 1. Unfasten 2* screws which secure the glass blocker. 2. Remove the glass blocker. 3. Slide the glass leftward. 4. Push up and slide rightward to remove the glass. 599 8170 – 86 Rev. 00 Q&CI - Technical Support...
  • Page 8 4.4 Slider Perform chapter and the first step of chapter 1. Unfasten 4* screws which secure the slider. 2. Unfasten 2* screws which secure the slider blockers. 3. Pull out to remove the Slider. 4.5 Slider Guide(SG) Perform the chapter 1.
  • Page 9 4.6 Lamp Lamp Picture Procedure to access 4.6.1 Candle Lamp See subchapter 4.6.1 4.6.2 Spot Lamp See subchapter 4.6.2 599 8170 – 86 Rev. 00 Q&CI - Technical Support...
  • Page 10 4.6.1 Candle Lamp (CL) Perform chapter and the first step of chapter 1. Turn the bulb in anti- clockwise direction to take the CL out and in clockwise direction to place it back. Assure that power cable is plugged out Check if the lamp is hot 4.6.2 Spot Lamp (SL) Perform chapter...
  • Page 11 4.7 Light Diffuser (LD) Perform the chapter and the subchapter 4.6.1 to access the LD Have work gloves to avoid the cuts when you unsnap 1. Unsnap two from the four snaps of the LD inside the hood. 2. Push the LD down to remove it. 4.8 Lamp Holder (LH) Perform chapter and chapter...
  • Page 12 4.9 Feeder Cable (FC) Perform Chapter and the step of chapter 1. Loosen 2* screws which secure the feeder cable to the connections device. 2. Extract the FC. 599 8170 – 86 Rev. 00 Q&CI - Technical Support...
  • Page 13 4.10 Led Driver (LD) Perform chapter and the step of subchapter 4.6.2 1. Unfasten 2* screws which secure the LD to the Hood shell. First Option (replacing the LD only): 2. Unfasten 1* screw which secure the cover of LD to remove it. 3.
  • Page 14 4.11 Blower Assembly(BA) Perform chapter and the step of chapter 4.6.2 Unplug the power cable from the power socket Be sure to hold up the BA during the perform of steps 2 of this chapter 1. Depress the two snaps on the connector inward and pull to separate out. 2.
  • Page 15 4.12 Control Assembly (CA) 4.12 Control Assembly Picture Procedure to access 4.12.1 Rocker Button See subchapter 4.12.1 4.12.2 Square Push Button See subchapter 4.12.2 599 8170 – 86 Rev. 00 Q&CI - Technical Support...
  • Page 16 4.12.1 Rocker Button Perform chapter and 2 step of chapter 1. Unsnap the cover. 2. Pull out the CA. 3. Loosen 3* screws which fasten the CA to the connector. 4.12.2 Square Push Button To remove the Square Push Button CA, perform subchapter 4.12.1 599 8170 –...

  • Page 17: Circuit

    5 CIRCUIT Circuit Code Circuit Links Combinations Number 04808159 Square push button +Candle Lamp 04808160 Rocker Button+ Candle Lamp 04808166 Rocker Button + Spot Lamp 599 8170 – 86 Rev. 00 Q&CI - Technical Support...
  • Page 18 5.1 Circuit of Square Push Button+Candle Lamp 599 8170 – 86 Rev. 00 Q&CI - Technical Support...
  • Page 19 5.2 Circuit of Rocker Button + Candle Lamp 599 8170 – 86 Rev. 00 Q&CI - Technical Support...
  • Page 20 5.3 Circuit of Rocker Button + Spot Lamp 599 8170 – 86 Rev. 00 Q&CI - Technical Support...

  • Page 21: Trouble Shooting

    TROUBLE SHOOTING 6.1 Blower Assembly Blower Assembly Check with voltmeter ON Not working with power sourcing ON PCB terminal block feeder cable(230V) Change the feeder cable Value 230V Set max motor speed on Control Assembly and check with voltmeter on the motor connector cables black + white(230V) Change Control Assembly Value 230V?
  • Page 22 6.2 Candle Lamps Candle Lamp Check right position of the lamps Not working with power sourcing Lamps works? Check with voltmeter on terminal block feeder cable (230 V) Change the Feeder Cable Value 230V? Push light button on control assembly and check with voltmeter on the light connection on terminal block (230 V) 599 8170 –...
  • Page 23 Change the control assembly Value 230V? Check with voltmeter on the lamp holder (230 V) Change the lamps wiring Value 230V? Lamps works Change Lamps Final Service 599 8170 – 86 Rev. 00 Q&CI - Technical Support...
  • Page 24 6.3 Spot Lamps Spot Lamp Check with voltmeter ON Not working with power PCB terminal block feeder sourcing ON cable(230V) Change the feeder Value 230V? cable Push light button ON and check with voltmeter on the light connection in the terminal block(230V) Change Control Value 230V? Assembly...
  • Page 25 6.4 Control Assembly Control Assembly Check with voltmeter ON Not working with power PCB terminal block feeder sourcing ON cable(230V) Change the feeder cable Value 230V? Push light button ON and check with voltmeter on the light connection in the terminal block(230V) Change Control Value 230V?
