Meet the Ithaca
Series 150 impact printer. Leading companies in the POS and hospitality industries trust the Ithaca
®
brand for fast, reliable printers that last. Our 150 is a compact, economical printer with excellent reliability and an
industry-leading warranty. It prints at speeds of 9.5 lines per second, and has the flexibility of receipt, journal and
validation capabilities. Our 150 also utilizes Oki
snap-out, user-friendly ribbon cassette. We have four different 150 models to choose from, each delivering high
performance at an extremely low total cost of ownership, together with a 2-year warranty offering extended maintenance
options. And, of course, the Series 150 is backed by our solid reputation for quality and reliability.
OUR MODELS
151 Receipt (When ordered with Auto-Cut option,
single-piece spill-resistant cover is standard.)
152 Receipt/Journal
153 Receipt/Journal/15-line Validation
154 Receipt/15-line Validation
OUR PRINTING CHARACTERISTICS
Style
Pitch
Maximum
(char./in.) (char./line)
Condensed
17.1
OUR INTERFACE OPTIONS
RS232C:
Bi-Directional Serial (9-Pin)
IEEE1284:
Bi-Directional Parallel (25-Pin)
Universal Serial Bus (USB)
OUR PRINTER DRIVERS
Windows™ 95/98/2000/Me/XP, NT 4.0, OPOS
OUR OPTIONS
• Journal Lock
• Display Pass-Thru (Serial Only)
• Auto-Cutter — Partial Cut leaves a 1 mm (.04 in.)
tab in center of receipt.
• Light Gray or Black Cabinetry
OUR POWER REQUIREMENTS
Internal Universal AC Power:
90 VAC to 264 VAC
(Self-Ranging), 47 to 63 Hz
OUR RELIABILITY
Printer in full operation (using all available features)
MCBF: 4,000,000 to 5,000,000 Print Lines
(Depending on Model)
MTBF: 22,000 to 30,000 Hours (Depending on
Model)
Printhead: 200,000,000 Characters
Auto-Cutter: 1,000,000 Cuts
Made to Order. Built to Last.
* Reliability data is based on our standard test conditions
simulating a normal retail operating environment.
OUR ENVIRONMENTAL SPECS
Operating Temperature:
0 to +50 degrees C (32 to +122 degrees F)
Operating Humidity:
10 to 90% RH non-condensing
OUR REGULATORY COMPLIANCE
FCC Class A
CSA 950
UL 1950
VDE 950
OUR SUPPLIES AND SERVICE
We offer convenient one-stop shopping for all
your printer needs — paper, spare parts, manuals,
printer servicing/refurbishment and more. For more
information, call us at 1.877.7ithaca or visit our
Web site at www.ithacaprinters.com.
© 2003 TransAct Technologies, Inc. Contents of this publication may be changed without notice and shall not be regarded as a warranty. The Ithaca name and logo, Made to Order. Built to Last., and PcOS are registered
trademarks of TransAct Technologies. Windows is a registered trademark of Microsoft Corporation. IBM is a registered trademark of International Business Machines Corporation. ESC/POS is a trademark of Seiko
Epson Corporation. Star is a registered trademark of Star Micronics Corporation. Oki is a registered trademark of Okidata Corporation. All rights reserved.
®
Print Speed
(lines/sec.)
48
9.5
10 char./line
@
48
5.9
40 char./line
@
*
®
CE Mark
technology, known worldwide for quality, reliability and a snap-in/
OUR FEATURES AND BENEFITS
• Print Speed: 9.5 lps. (340 cps.) — On Standard Test Receipt
• Standard Warranty: Two Years (Extended Maintenance Plan Available)
• Cash Drawer Drivers: Dual with Status (RJ11)
• Print Zone Widths: 61 mm (2.4 in.) or 72 mm (2.8 in.)
• Data Buffer: Up to 6K Configurable
• CPI: 4, 6, 8.5, 10, 12, 15, 17.1, 20, 24
• APA Bit Map Graphics
• Portrait or Landscape Printing
• Simple Loading of Receipt Paper
• Available Emulations: Ithaca/IBM (PcOS
• 67 Language Code Pages
• Self Diagnostics
• Concealed Cable Entry
• Bar Codes: Code 39, Code 93, Interleaved 2 of 5, UPC-A and UPC-E,
EAN8 and EAN13, Code 128
• Interface Parameters: Software Configurable via Buttons or Interface Port
*
Licensed Command Firmware available as an option.
OUR MEDIA
Paper Roll (One-Ply):
• Width: 82.5 mm (3.25 in.) or optional 76 mm (3 in.)
• Diameter: 89 mm (3.5 in.)
• Length Per Roll: 73.1 m (240 ft.)
• One-Ply Maximum Thickness: .11 mm (.0045 in.)
Paper Roll (Two-Ply):
• Width: 82.5 mm (3.25 in.)
• Diameter: 89 mm (3.5 in.)
• Length Per Roll: 38.1 m (125 ft.)
• Maximum Thickness Per Ply: .09 mm (.0035 in.)
Paper Roll (Three-Ply, not for use with Model 151 with Auto-Cut):
• Width: 82.5 mm (3.25 in.)
• Diameter: 89 mm (3.5 in.)
• Length Per Roll: 26 m (85 ft.)
• Maximum Thickness Per Ply: .25 mm (.01 in.)
Ribbons: 3-4.5 Million Character Life
• Ithaca or Genuine Oki Snap-on Ribbon Cassette (Black or Purple)
OUR PHYSICAL CHARACTERISTICS
Dimensions: 171.45 mm W x 287 mm D x 142 mm H
(6.75 in. W x 11.3 in. D x 5.6 in. H)
Weight: 2.95 kg (6.5 lbs.)
Shipping Weight: 4.32 kg (9.5 lbs.)
WHO WE ARE
TransAct Technologies, Inc. (NASDAQ: TACT) designs, develops, manufactures
and markets transaction-based printers under the Ithaca
names. In addition, the company markets related consumables, spare parts and service.
The company's printers are used worldwide to provide receipts, tickets, coupons, register
journals and other documents. The company focuses on the following vertical markets:
point-of-sale (POS), and gaming and lottery. All of TransAct's products are manufactured
in ISO9001-certified facilities.
WHERE TO REACH US
TransAct Technologies, Inc.
Ithaca Facility
20 Bomax Drive
Ithaca, New York 14850
1.877.7ithaca (1.877.748.4222)
Fax: 607.257.3868
www.ithacaprinters.com
®
), Epson* ESC/POS
and Magnetec
®
TransAct Technologies, Ltd.
7 Wood View
Broomhouse Lane Industrial Estate
Edlington, Doncaster DN12 1EQ
United Kingdom
Phone:
++
44 (0) 1709 772500
Fax:
++
44 (0) 1709 772505
®
, Microline, Star
brand
®
®
a product of
15-9476.0803
