- Page 1 User Manual Wireless Mobile and PC to HDTV GWAVRB PART NO. M1467 www.iogear.com...
- Page 2 Microsoft Corporation. IOGEAR makes no warranty of any kind with regards to the information presented in this document. All information furnished here is for informational purposes only and is subject to change without notice. IOGEAR assumes no responsibility for any inaccuracies or errors that may appear in this document.
-
Page 3: Table Of Contents
Table of Contents Features Package Contents System Requirements Overview Hardware Installation - Receiver Connect with Wi-Fi Direct - Android devices - Windows 10 devices (for OEM installations only) Compliance Information Limited Warranty Contact... -
Page 4: Features
Features • USB Micro-B Power Port - Connect the power adapter to this port to supply power to the device. • HDMI Out - Connect to the display with the HDMI cable • Mode Button – Switch back and forth between the default mode and the Enhanced Wi-Fi mode •... -
Page 5: Package Contents
Package Contents 1 x GWAVRB 1 x Installation CD 1 x Power Adapter 1 x User Manual 1 x Micro USB Power Cable 1 x Warranty Card 1 x HDMI Cable System Requirements PC (Minimum Requirements) Smartphones and Tablets • Intel Core i5 2nd Gen or AMD Phenom II X4 •... -
Page 6: Overview
Overview Duplicast Wireless A/V Receiver: USB Micro-B Power Port - Connect the power adapter to this port to supply power to the device. HDMI Out - Connect to the display with the HDMI cable Micro USB HDTV Mode Button – Switch back and forth between the Mode default mode and the Enhanced Wi-Fi mode USB Port - This port is reserved for service and... -
Page 7: Hardware Installation - Receiver
The Power LED will light solid blue. Turn on your TV or projector, and make sure you select the correct video source. The IOGEAR Duplicast flash screen will come up on the display and SSID, Pin Code and IP Address will populate the bottom of the screen. -
Page 8: Connect With Wi-Fi Direct
Connect with Wi-Fi Direct Once you have verified that your device is Wi-Fi Direct ready, you can cast your content to the big screen by following the steps below. Android devices On your Display option screen, connect by tapping on the cast option specific to your device (see example to the right). - Page 9 After you initiate the connection, wait a few seconds for your device to establish the connection with the wireless receiver. When a black screen displays on both the TV and your device, the connection has been established. The technical term for this is “sync”, and the two devices have now synced with each other.
-
Page 10: Windows 10 Devices (For Oem Installations Only)
Windows 10 devices (for OEM installations only) Open Settings to connect to a wireless display. Click on System. When the Display settings option window appears, click on Connect to a wireless display. - Page 11 At the right side of the screen, the Duplicast receiver will appear. Click on it to start the connection process. Wait a few seconds for the connection to be made and then you should see both the TV and laptop screen go dark briefly (an indication the connection is being established).
-
Page 12: Compliance Information
Compliance Information Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential setting. -
Page 13: Limited Warranty
Limited Warranty This product carries a 1 Year Limited Warranty. For the terms and conditions of this warranty, please go to http://www.iogear.com/support/warranty Register online at http://www.iogear.com/register Important Product Information Product Model Serial Number Contact WE’RE HERE TO HELP YOU! NEED ASSISTANCE SETTING UP THIS PRODUCT? Make sure you: 1. - Page 14 Notes...
- Page 16 © 2017 IOGEAR...
