Uputstvo za upotrebu (EN)
DELL laptop Inspiron 3520 (NOT21870)
Tehnoteka je online destinacija za upoređivanje cena i karakteristika bele tehnike,
potrošačke elektronike i IT uređaja kod trgovinskih lanaca i internet prodavnica u Srbiji.
Naša stranica vam omogućava da istražite najnovije informacije, detaljne karakteristike
i konkurentne cene proizvoda.
Posetite nas i uživajte u ekskluzivnom iskustvu pametne kupovine klikom na link:
https://tehnoteka.rs/p/dell-laptop-inspiron-3520-not21870-akcija-cena/
Advertisement
Table of Contents
Related Manuals for Dell NOT21870
Summary of Contents for Dell NOT21870
- Page 1 Uputstvo za upotrebu (EN) DELL laptop Inspiron 3520 (NOT21870) Tehnoteka je online destinacija za upoređivanje cena i karakteristika bele tehnike, potrošačke elektronike i IT uređaja kod trgovinskih lanaca i internet prodavnica u Srbiji. Naša stranica vam omogućava da istražite najnovije informacije, detaljne karakteristike i konkurentne cene proizvoda.
- Page 2 Inspiron 15 3520 Setup and Specifications Regulatory Model: P112F Regulatory Type: P112F001/P112F002/P112F007/P112F008 August 2023 Rev. A04...
- Page 3 A WARNING indicates a potential for property damage, personal injury, or death. © 2022-2023 Dell Inc. or its subsidiaries. All rights reserved. Dell Technologies, Dell, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
-
Page 4: Table Of Contents
Power adapter..................................19 Battery....................................20 Display....................................21 Fingerprint reader................................22 GPU—Integrated................................23 GPU—Discrete.................................. 23 Operating and storage environment..........................23 Chapter 4: Dell low blue light display................... 24 Chapter 5: Dell ComfortView....................... 25 Chapter 6: Keyboard shortcuts....................26 Chapter 7: Getting help and contacting Dell................27 Contents... -
Page 5: Chapter 1: Set Up Your Inspiron 15 3520
Follow the on-screen instructions to complete the setup. For more information about installing and configuring Ubuntu, search in the Knowledge Base Resource at www.dell.com/support. For Windows: Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you: ● Connect to a network for Windows updates. NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when prompted. - Page 6 Dell Digital Delivery Download software applications, which are purchased but not preinstalled on your computer. For more information on using Dell Digital Delivery, search in the Knowledge Base Resource at www.dell.com/support. SupportAssist SupportAssist proactively and predictively identifies hardware and software issues on your computer and automates the engagement process with Dell Technical support.
-
Page 7: Chapter 2: Views Of Inspiron 15 3520
Views of Inspiron 15 3520 Front CAUTION: The maximum operating angle for the display-panel hinge is 135 degrees. 1. Left microphone (optional) Provides digital sound input for audio recording and voice calls. 2. Camera Enables you to video chat, capture photos, and record videos. 3. -
Page 8: Right
Right 1. SD-card slot Reads from and writes to the SD card. The computer supports the following card types: ● Secure Digital (SD) ● Secure Digital High Capacity (SDHC) ● Secure Digital Extended Capacity (SDXC) 2. USB 2.0 port Connect devices such as external storage devices and printers. Provides data transfer speeds up to 480 Mbps. 3. - Page 9 Connect devices such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps. With Type-C port 1. Power-adapter port Connect a power adapter to provide power to your computer and charge the battery. 2. Power and battery-status light Indicates the power state and battery state of the computer.
-
Page 10: Top
The highlighted area indicates the actual active fingerprint reader area, and the image is for illustration purposes only. NOTE: You can customize power-button behavior in Windows. For more information, see Me and My Dell at www.dell.com/support/manuals. 2. Touchpad Move your finger on the touchpad to move the mouse pointer. Tap to left-click and two fingers tap to right-click. -
Page 11: Bottom
Provide audio output. 2. Service Tag and regulatory labels The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your computer and access warranty information. The regulatory label contains regulatory information of your computer. -
Page 12: Chapter 3: Specifications Of Inspiron 15 3520
Specifications of Inspiron 15 3520 Dimensions and weight The following table lists the height, width, depth, and weight of your Inspiron 15 3520. Table 3. Dimensions and weight Description Plastic Aluminum Height: Front height 15.52 mm (0.61 in.) 16.96 mm (0.66 in.) Rear height 17.50 mm (0.69 in.) 18.99 mm (0.74 in.) - Page 13 Table 4. Processor Description Option one Option two Option three Option four Processor type Generation Intel Generation Intel Generation Intel Generation Intel Core i7-1165G7 Core i5-1155G7 Core i5-1135G7 Core i3-1115G4 Processor wattage 15 W 15 W 15 W 15 W Processor total core count Performance-cores...
- Page 14 Table 5. Processor Description Option five Option six Option seven Option eight Processor type Intel Pentium Gold 7505 12 Generation Intel Generation Intel Generation Intel Core i7-1255U Core i5-1235U Core i3-1215U Processor wattage 15 W 15 W 15 W 15 W Processor total core count Performance-cores...
-
Page 15: Chipset
Table 6. Processor Description Option nine Option ten Processor type Intel Pentium Gold 8505 Intel Celeron 7305 Processor wattage 15 W 15 W Processor total core count Performance-cores Efficient-cores Processor total thread counts NOTE: Intel® Hyper-Threading Technology is only available on Performance-cores. -
Page 16: Operating System
Operating system Your Inspiron 15 3520 supports the following operating systems: ● Windows 11 Home in S-mode, 64-bit ● Windows 11 Home, 64-bit ● Windows 11 Pro, 64-bit ● Windows 11 Pro National Academic, 64-bit ● Ubuntu 20.04 LTS, 64-bit Memory The following table lists the memory specifications of your Inspiron 15 3520. -
Page 17: Internal Slots
NOTE: To learn more about the features of different types of M.2 cards, search in the Knowledge Base Resource at www.dell.com/support. Wireless module The following table lists the Wireless Local Area Network (WLAN) module specifications of your Inspiron 15 3520. -
Page 18: Audio
Audio The following table lists the audio specifications of your Inspiron 15 3520. Table 12. Audio specifications Description Values Audio controller ● Realtek ALC3204 ● Realtek ALC3254 ● Cirrus CS8409 (CS42L42 + SN005825 ) Stereo conversion Supported Internal audio interface High definition audio interface External audio interface One headset (headphone and microphone combo) port... -
Page 19: Media-Card Reader
Table 13. Storage specifications (continued) Storage type Interface type Capacity M.2 2280 solid-state drive, QLC PCIe NVMe 3x4 Up to 1 TB Media-card reader The following table lists the media cards supported by your Inspiron 15 3520. Table 14. Media-card reader specifications Description Values Media-card type... -
Page 20: Camera
Camera The following table lists the camera specifications of your Inspiron 15 3520. Table 16. Camera specifications Description Plastic Aluminum Number of cameras Camera type HD camera FHD RGB camera Camera location Front camera Front camera Camera sensor type CMOS sensor technology CMOS sensor technology Camera resolution:... -
Page 21: Battery
Table 18. Power adapter specifications (continued) Description Values External diameter 2.90 mm (0.11 in.) Internal diameter 4.50 mm (0.17 in.) Input voltage 100 VAC x 240 VAC Input frequency 50 Hz x 60 Hz Input current (maximum) 1.70 A Output current (continuous) 3.34 A Rated output voltage 19.50 VDC... -
Page 22: Display
CAUTION: Dell recommends that you charge the battery regularly for optimal power consumption. If your battery charge is completely depleted, connect the power adapter, turn on your computer, and then restart your computer to reduce the power consumption. -
Page 23: Fingerprint Reader
Table 20. Display specifications (continued) Description Option one Option two Option three Display-panel dimensions (active area): Height 193.54 mm (7.62 in.) 193.59 mm (7.62 in.) 193.59 mm (7.62 in.) Width 344.23 mm (13.55 in.) 344.16 mm (13.55 in.) 344.16 mm (13.55 in.) Diagonal 394.91 mm (15.55 in.) 394.87 mm (15.55 in.) -
Page 24: Gpu-Integrated
GPU—Integrated The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your Inspiron 15 3520. Table 22. GPU—Integrated Controller Memory size Processor Intel UHD Graphics Shared system memory ● Intel Celeron/Pentium ● 11 Generation Intel Core i3 ●... -
Page 25: Chapter 4: Dell Low Blue Light Display
Dell low blue light display WARNING: Prolonged exposure to blue light from the display may lead to long-term effects such as eye strain, eye fatigue, or damage to the eyes. Blue light is a color in the light spectrum which has a short wavelength and high energy. Chronic exposure to blue light, particularly from digital sources, may disrupt sleep patterns and cause long-term effects such as eye strain, eye fatigue, or damage to the eyes. -
Page 26: Chapter 5: Dell Comfortview
ComfortView mode can be enabled and configured using the Dell CinemaColor application. ComfortView mode complies with TÜV Rheinland's requirement for low blue light displays. Low blue light: Dell ComfortView software technology reduces harmful blue light emissions to make extended screen time easy on your eyes. -
Page 27: Chapter 6: Keyboard Shortcuts
Keyboard shortcuts NOTE: Keyboard characters may differ depending on the keyboard language configuration. Keys used for shortcuts remain the same across all language configurations. Table 25. List of keyboard shortcuts Keys Primary Behavior Secondary Behavior (fn + Key) fn + Esc Escape Toggle fn-key lock F1 behavior... -
Page 28: Chapter 7: Getting Help And Contacting Dell
Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 26. Self-help resources Self-help resources Resource location Information about Dell products and services www.dell.com My Dell app... - Page 29 Ovaj dokument je originalno proizveden i objavljen od strane proizvođača, brenda Dell, i preuzet je sa njihove zvanične stranice. S obzirom na ovu činjenicu, Tehnoteka ističe da ne preuzima odgovornost za tačnost, celovitost ili pouzdanost informacija, podataka, mišljenja, saveta ili izjava sadržanih u ovom dokumentu.
