Für Service: (49)-06838-907-100
D
114A1991H
Anleitungen
–
Garagentoröffner Modell MotorLift 4000
Instructions
–
Modèle MotorLift 4000 de ouvre-porte de garage
Instructions
–
Garage Door Operator Model MotorLift 4000
Instruktioner
–
Model MotorLift 4000 Garageportsåbner
Instrucciones –
Abridor de la puerta de garage, Modelo MotorLift
4000
O‰ËÁ›Â˜
–
M˯·ÓÈÛÌfi˜ AÓÔ›ÁÌ·ÙÔ˜ °Î·Ú·˙fiÔÚÙ·˜,
MÔÓÙ¤ÏÔ MotorLift 4000
Istruzioni
–
Apriporta per garage Modello MotorLift 4000
Instruksjoner –
Garasjeportåpner, Modell MotorLift 4000
Instrukties
–
Model MotorLift 4000 Garagedeuropener
Instruções
–
Operador automático de porta –
Modelo MotorLift 4000
Instruktioner
–
Garageportöppnare Modell MotorLift 4000
Ohjeet
–
Autotallin oven avaaja, Malli MotorLift 4000
Alfred Nobel Str. 4 - 66793 Saarwellingen, Deutschland
F
Für Service: (43)-2623-72225-33
A
Pour Service: (33) 03.87.95.39.28
NL
™
TM
For Service: 0800 317847
GB
(31) 020-684.79.78
Advertisement
Table of Contents
Related Manuals for Chamberlain MotorLift 4000
Summary of Contents for Chamberlain MotorLift 4000
- Page 1 ™ Anleitungen – Garagentoröffner Modell MotorLift 4000 Instructions – Modèle MotorLift 4000 de ouvre-porte de garage Instructions – Garage Door Operator Model MotorLift 4000 Instruktioner – Model MotorLift 4000 Garageportsåbner Instrucciones – Abridor de la puerta de garage, Modelo MotorLift 4000 O‰ËÁ›Â˜...
-
Page 2: Table Of Contents
D. Double-wing door – Special door arm required. See your dealer. B. One-Piece Door with Horizontal and Vertical Track – Special door arm E. Canopy door – Special door arm (F, The Chamberlain Arm™) (F, The Chamberlain Arm™) required. See your dealer. -
Page 3: Tools Required: Illustration
Check to make sure the chain is not twisted. Remove the screwdriver. Important: If you have a canopy or dual-track door, you need to use the instructions packed with The Chamberlain Arm™ TIGHTEN THE CHAIN/CABLE – Accessory in conjunction with this Owner's Manual when assembling the T-rail. - Page 4 INSTALLATION SECTION – HANG THE OPENER – The opener must be securely fastened to a structural support of the garage. Three representative installations are shown. Yours may be different. Hanging brackets (1) should be angled (Figure A) to Wear protective goggles when working overhead to protect your provide rigid support.
-
Page 5: Connect Door Arm
OPERATION OF THE LIGHTED DOOR CONTROL BUTTON PROGRAM YOUR OPENER & REMOTE – Press to open or close the door. Press again to reverse the door Activate the opener only when door is in full view, free of during the closing cycle or to stop the door during opening cycle. obstruction and properly adjusted. -
Page 6: Hex Screws
OPERATION OF YOUR OPENER FORCE ADJUSTMENT – Your opener can be activated by any of the following devices: The force, as measured on the closing edge of the door, should not exceed 150 N (15kg). If the closing force is adjusted to more •... -
Page 7: Problems
HAVING A PROBLEM? 8. The garage door opens and closes by itself: 1. Opener doesn't operate from either door control or remote: • Is there a neighbor with a garage door opener using the same frequency code? Change your code. •... -
Page 8: Specifications
Push button and automatic stop in (9) Model 770EML ......The Protector System™ up direction. Electronic.....Independent up and down force (10) Model 1703EML ......The Chamberlain Arm™ adjustment screws. (11) Model 1EML ......Door Handle Quick Release Electrical......Motor overload protector and low voltage push (12) Model 34EML ......2-Position Key Switch... -
Page 9: Lock Washers
Abbildungen – Garagentoröffner Modell MotorLift 4000 Figures – Modèle MotorLift 4000 de ouvre-porte de garage Illustrations – Garage Door Operator Model MotorLift 4000 Illustration – Model MotorLift 4000 Garageportsåbner Ilustraciones – Abridor de la puerta de garage, Modelo MotorLift 4000 ™¯‹Ì·... -
Page 10: Nuts
114A1992G... - Page 11 114A1992G...
- Page 12 114A1992G...
-
Page 13: Carriage Bolts
114A1992G... - Page 14 114A1992G...
- Page 15 114A1992G...
- Page 16 114A1992G...
- Page 17 114A1992G...
- Page 18 114A1992G...
- Page 19 114A1992G...
- Page 20 114A1992G...
- Page 21 114A1992G...
- Page 22 4330EML 4333EML 845EML 4335EML 75EML 1703EML LO CK LIG HT 1702EML 760EML 747EML 770EML 1EML 34EML/41EML 114A1992G...
- Page 23 41A3473 183B112 217A238 41A3489 10A20 183B112 183B111 83A4 41A4330 41A2848 183B113 29C128 41A4166 41A4353 12B374 41B2616 41A3475-1 1A995 178B34 178B35 12B350 41A2828 114A1992G...
