Smeg STE8639L Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
G
G
U
U
I
I
D
D
E
E
F
F
O
O
R
R
U
U
S
S
I
I
N
N
G
G
T
T
H
H
E
E
D
D
I
I
S
S
H
H
W
W
A
A
S
S
H
H
E
E
R
R
A
A
N
N
D
D
T
T
H
H
E
E
W
W
A
A
S
S
H
H
I
I
N
N
G
G
P
P
R
R
O
O
G
G
R
R
A
A
M
M
S
S

Advertisement

loading

Related Manuals for Smeg STE8639L

Summary of Contents for Smeg STE8639L

  • Page 1 INSTRUCTION MANUAL...
  • Page 3 Contents 1. Description of the controls _______________________________ 2 2. Operating instructions __________________________________ 14 3. Cleaning and maintenance ______________________________ 29 4. Troubleshooting ______________________________________ 33 Thank you for choosing one of our products. You are advised to read this manual carefully; it contains all the information you need use your dishwasher safely, correctly and in the most satisfactory manner.

  • Page 4: Description Of The Controls

    User instructions 1. Description of the controls Upper panel All the dishwasher controls are grouped on the upper panel. Switch-on, programming, switch-off, etc. procedures are only possible when the door is open. The panel shown is only a guideline example: the form of the lights and buttons may vary depending on the model.
  • Page 5 User instructions PROGRAM DELAY BUTTON Press this button to delay the start of the program. INFORMATION DISPLAY (1 or 3 digits depending on model) OPTIONS (on some models only) CHILD SAFETY DEVICE (on some models only) Information displayed Scheduled program duration Remaining program time...
  • Page 6 User instructions Flexi Tabs Option recommended for the use of multi-function tablet detergent. HYCLEAN Adds a final antibacterial rinse to the selected program. Spread HALF LOAD WASH Allows washing of just a few dishes placed in both baskets. PROGRAM DELAY Allows the program to be set to start with a delay of 9, 12 or 24 hours depending on the model.
  • Page 7 User instructions PROGRAMS TABLE The manual contains the programs table for several models. To find the table for your dishwasher, compare the program symbols at the top of the table with those on your control panel. SETTING THE WASHING PROGRAM AND SWITCHING ON After identifying the most suitable program with the aid of the programs table: ...
  • Page 8 User instructions PROGRAMS TABLE DURATION CONSUMPTION PROGRAMME LOAD CROCKERY AND PROGRAM NUMBER CUTLERY PROGRESS MINUTES POWER WATER & SYMBOL KWh (1) LITRES 1 SOAK Pans and dishes awaiting 0,02 Cold prewash completion of the load Wash at 45°C 2 GLASS Glass, china and mixed Cold rinse 1,10...
  • Page 9 User instructions QUICK TIME PROGRAMS (see relevant section for explanation of functioning modes) DURATION LOAD CROCKERY AND CONSUMPTION PROGRAMME CUTLERY PROGRAM WATER NUMBER E PROGRESS MINUTI POWER LITRES KWh (1) SYMBOL RAPID 27’ Dishes with light dirt, Wash at 38°C 0,70 washed immediately after Rinse at 50°C...
  • Page 10 User instructions NOTES AND REFERENCES Only run the soak program with half loads. Options cannot be used with the soak program. The ENERSAVE option cannot be used with soak, ultra clean, or any programs which do not include the final drying stage. Standard programme under EN 50242.
  • Page 11 User instructions Washing programs Before starting a washing program make sure that: The water supply tap is open.  The softener container contains regenerating salt.   The correct amount of detergent has been added to the dispenser.  The baskets have been correctly loaded. ...
  • Page 12 User instructions ADDITIONAL OPTIONS Some models feature additional options, activated by pressing two buttons simultaneously. In this case, two lines in the control panel graphics link the symbol of the additional option to the two buttons to be pressed simultaneously to enable it. (e.g. “Flexi Tabs” in this illustration) QUICK TIME OPTION Select this option together with any washing program (except the soak program) to SHORTEN the cycle.
  • Page 13 User instructions ULTRA CLEAN The "ULTRA CLEAN" program prolongs the final hot rinse to ensure a further reduction in the bacteria level. If the temperature in the tank falls during this stage of the program (e.g. because the door is opened or due to a power blackout), the light of the option and the program lights (2) flash to warn that the additional washing phase has not been completed successfully.
  • Page 14 User instructions ULTRA CLEAN The "ULTRA CLEAN" program prolongs the final hot rinse to ensure a further reduction in the bacteria level. If the temperature in the tank falls during this stage of the program (e.g. because the door is opened or due to a power blackout), the light of the option and the program lights (2) flash to warn that the additional washing phase has not been completed successfully.
  • Page 15 User instructions TO SAVE ON ENERGY! … AND PROTECT THE ENVIRONMENT  Always use the dishwasher with a full load.  Do not wash the dishes in running water.  Use the washing program that is most appropriate for each type of load.

  • Page 16: Operating Instructions

    User instructions 2. Operating instructions Once the dishwasher has been correctly installed, prepare for use as follows:  Adjust the water softening system; Add the regenerating salt;   Add the rinse aid and detergent. Using the water softening system The amount of scale contained in the water (water hardness index) can cause whitish staining on the dry dishes, which tend to...
  • Page 17 User instructions  Do not use table salt as it contains insoluble substances which, over time, may damage the water softening system. When necessary, refill the regenerating salt container before  starting the washing program. In this way, the excess saline solution will be immediately removed by the water;...
  • Page 18 User instructions WATER HARDNESS TABLE WATER HARDNESS SETTING German French degrees (°dH) Degrees (°dF) All lights off 0 - 6 0 - 11 (no salt) One light on 7 - 10 12 - 18 Two lights on 11 - 15 19 - 27 Three lights on 16 - 21...
  • Page 19 User instructions ADDING THE RINSE AID The rinse aid helps the dishes dry faster and prevents the formation of scale deposits and staining; it is automatically added to the water during the final rinse cycle, from the container situated on the inner side of the door. To add rinse aid: ...
  • Page 20 User instructions ADDING THE DETERGENT To open the detergent dispenser cap, lightly press the button P. Add the detergent and close the cap carefully. During the washing cycle, the dispenser will be opened automatically.  When a program with hot prewash is selected (see program table), extra detergent must be placed in the cavity G/H (depending on models).
  • Page 21 User instructions The introduction of detergent into the rinse aid dispenser, even in liquid form, will damage the dishwasher. General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types to be washed and their loading.
  • Page 22 User instructions WARNING! Make sure that the dishes are securely in place so that they cannot  tip over or obstruct the rotation of the spray arms during the washing cycle.  Do not place very small objects in the baskets as these could fall and obstruct the spray arms or the wash pump.
  • Page 23 User instructions Using the baskets The dishwasher has a capacity of 13 place-settings, including serving dishes. LOWER BASKET The lower basket receives the full force of the lower spray arm, and should therefore be used for the “toughest” items with a heavier degree of soiling. All types and combinations of loads are permitted, provided that the dishes, pots and pans are arranged with all the soiled surfaces...
  • Page 24 User instructions LOADING THE LOWER BASKET Carefully load flat plates, soup plates, dessert and serving dishes, positioning them vertically. Pots, pans and their covers must be loaded upside down. When loading soup plates and dessert bowls, be sure to leave a gap between them. Loading examples: UPPER BASKET It is recommended to load the upper basket with small- or medium-sized...
  • Page 25 User instructions CUTLERY BASKET The basket has removable top grids into which items of cutlery should be inserted to keep them properly spaced and allow water to pass between them effectively. The top grids and central lid are in the bag of accessories.
  • Page 26 User instructions FLEXI DUO TOP RACK (on some models only) This comprises two independent sliding, pull-out tray racks for easier loading/unloading of cutlery. Various loading systems and configurations are possible. For example, tea cups can be loaded with the right-hand rack set in the low position, while the left-hand rack or both can be removed to allow large dishes to be put in the top basket...
  • Page 27 User instructions Examples of loading for intensive dirt...
  • Page 28 User instructions Examples of loading for intensive dirt FLEXI DUO TOP RACK (on some models only)
  • Page 29 User instructions Depending on the models, the basket may be equipped with some or all of the following accessories: Supports for cups or long objects (ladles, spoons…), on the left; can be tipped to the vertical position when not in use. Stem glass holder, on the left;...
  • Page 30 User instructions ADJUSTING THE UPPER BASKET The height of the top basket can be adjusted to allow large dishes or pans to be placed in the bottom basket. The adjustment procedure may be type A or B, depending on the dishwasher model purchased.

  • Page 31: Cleaning And Maintenance

    User instructions 3. Cleaning and maintenance Before carrying out any work, always unplug the appliance from the electrical supply or switch off the all-pole disconnection device. General warnings and recommendations Avoid the use of acidic or abrasive detergents. Clean the outer surfaces and door-lining of the dishwasher regularly using a soft cloth moistened with water or with a normal detergent suitable for painted surfaces.
  • Page 32 User instructions CLEANING THE FILTER UNIT  It is advisable to periodically inspect the centre filter C and, if necessary, to clean it. To remove the filter, grip the tabs, turn them anticlockwise and lift upwards; push the centre filter D from the underside to remove it from the micro- ...
  • Page 33 User instructions BEFORE STARTING THE DISHWASHER AFTER PROLONGED DISUSE:  Check that there are no deposits of sludge or rust inside the water pipe: if there are, allow the water to run from the water supply tap for a few minutes. Plug the power cord back into the socket.
  • Page 34 User instructions If the dishes fail to dry or remain dull, check that: there is rinse aid inside the special container;   the rinse aid dispenser setting is correct;  the detergent used is of good quality and has not lost its effectiveness (for example, through incorrect storage, with the box left open).

  • Page 35: Troubleshooting

    User instructions 4. Troubleshooting The dishwasher is capable of signalling a number of faults through the simultaneous illumination of several indicator lights, with the following meanings: FAULT DESCRIPTION Acquastop failure The anti-flooding system has been activated (for the relevant models only). The system is tripped in case of water leaks.
  • Page 36 User instructions FAULT DESCRIPTION Turbine flow-regulator malfunction (for the relevant models only) The appliance is not able to "measure" the amount of water loaded accurately. Interrupt the program and switch off the dishwasher. Switch the dishwasher back on, program it again and start the washing cycle.
