CD RECEIVER
DEH-P7150UB
DEH-P7150UB
This service manual should be used together with the following manual(s) listed below.
For the parts numbers, adjustments, etc. which are not shown in this manual,
refer to the following manual(s).
Model No.
Order No.
DEH-P600UB/XN/UC
CRT4090
CX-3240
CRT4050
PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2008
Mech. Module
S10.5COMP2-iPod/USB
4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
/XN/ES1
Remarks
CD Mech. Module:Circuit Descriptions, Mech. Descriptions, Disassembly
ORDER NO.
CRT4301
/XN/ES
K-ZZZ. DEC. 2008 Printed in Japan
Advertisement
Table of Contents
Related Manuals for Pioneer DEH-P7150UB/XN/ES
Summary of Contents for Pioneer DEH-P7150UB/XN/ES
- Page 1 PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 PIONEER CORPORATION 2008 K-ZZZ.
-
Page 2: Exploded Views And Parts List
EXPLODED VIEWS AND PARTS LIST PACKING(Page 36) PACKING SECTION PARTS LIST *:Non spare part Mark Description DEH-P6050UB/XN/ES DEH-P7150UB/XN/ES DEH-P7150UB/XN/ES1 Polyethylene Bag CEG1116 Not used Not used Polyethylene Bag CEG1373 CEG-162 CEG-162 Unit Box CHG6392 CHG6778 CHG6779 Contain Box CHL6392 CHL6778... -
Page 3: Cd Mechanism Module
EXTERIOR(1)(Page 38) EXTERIOR(1) SECTION PARTS LIST DEH-P7150UB/XN/ES Mark Description DEH-P6050UB/XN/ES DEH-P7150UB/XN/ES1 Panel CNS9319 CNS9342 Detach Grille Assy CXC8931 CXE1458 Button Unit(DISP,S.Rtrv,RDM,SW) CXC9427 CAI2344 (Button) OEL Unit MXS8260 MXS8261 Grille Unit CXC8874 CXE1460 Knob Unit CXC8883 CXE1462 EXTERIOR(2)(Page 40) EXTERIOR(2) SECTION PARTS LIST... -
Page 4: Electrical Parts List
ELECTRICAL PARTS LIST(Page 73) Tuner Amp Unit DEH-P7150UB/XN/ES Circuit Symbol and No. Part Name DEH-P6050UB/XN/ES DEH-P7150UB/XN/ES1 D831 SMLE12BC7T(NP) CL-196HR-CD(AB) R151 Not used RS1/16S102J R152 Not used RS1/16S102J Page 51 Address 6C DEH-P7150UB/XN/ES... - Page 5 Keyboard Unit DEH-P7150UB/XN/ES Circuit Symbol and No. Part Name DEH-P6050UB/XN/ES DEH-P7150UB/XN/ES1 D1831 SMLE12BC7T(NP) NECWB205-5780 D1832 SMLE12BC7T(NP) NECWB205-5780 D1833 SMLE12BC7T(NP) NECWB205-5780 D1834 SMLE12BC7T(NP) NECWB205-5780 D1835 SMLE12BC7T(NP) NECWB205-5780 D1836 SMLE12BC7T(NP) NECWB205-5780 D1837 SMLE12BC7T(NP) NECWB205-5780 D1838 SMLE12BC7T(NP) NECWB205-5780 D1839 SMLE12BC7T(NP) NECWB205-5780 C1831 Not used...
-
Page 6: Schematic Diagram
SCHEMATIC DIAGRAM CD MECHANISM MODULE(GUIDE PAGE) PICKUP UNIT(P10.5)(SERVICE) SWITCHES: CD CORE UNIT(S10.5COMP2-iPod-C2) S901:HOME SWITCH..ON-OFF S903:DSCSNS SWITCH..ON-OFF S904:12EJ SWITCH....ON-OFF S905:8EJ SWITCH....ON-OFF The underlined indicates the switch position. M1 CXC7134 SPINDLE MOTOR M2 CXC4026 LOADING/CARRIAGE MOTOR ACTUATOR/ MOTOR DRIVER DEH-P7150UB/XN/ES... - Page 7 CD CORE UNIT(S10.5COMP2-iPod-C2) SIGNAL LINE FOCUS SERVO LINE TRACKING SERVO LINE CARRIAGE SERVO LINE SPINDLE SERVO LINE PE5675A CN701 341S2162 iPod AUTHENTICATION COPROCESSOR DEH-P7150UB/XN/ES...
- Page 8 DEH-P7150UB/XN/ES...
- Page 9 DEH-P7150UB/XN/ES...
- Page 10 DEH-P7150UB/XN/ES...
- Page 11 DEH-P7150UB/XN/ES...
-
Page 12: Pcb Connection Diagram
PCB CONNECTION DIAGRAM CD CORE UNIT(S10.5COMP2-iPod-C2) SIDE A PICKUP UNIT(P10.5) (SERVICE) CN701 REFO1 HOME LOADING/CARRIAGE MOTOR SPINDLE MOTOR DEH-P7150UB/XN/ES... - Page 13 CD CORE UNIT(S10.5COMP2-iPod-C2) SIDE B 12EJ DSCSNS DEH-P7150UB/XN/ES...
